Accessories included -
ARTIKEL1 - 4MP IR TURRET NETWORK CAMERA
ARTIKEL2 - MOTORIZED VARIFOCAL
Audio - Audio formats supported - G.711 A-law
Audio - Audio input channels - 1.0 channels
Audio - Audio output channels - 1.0 channels
Audio - Audio system - 2-way
Audio - Bit rate range - 0 - 64 Kbit/s
Audio - Built-in microphone - Yes
Audio - Number of microphones - 1
Audio - Sample rate - 8 kHz
Audio - Signal-to-Noise Ratio (SNR) - 52 dB
Brand - TP-Link
BrandPartCode - INSIGHT S445ZI
Breite - 0
Camera - Angle of rotation - 360°
Camera - Camera shutter speed - 1/3 to 1/10000
Camera - Lens viewing angle, diagonal - 34.1–122.8
Camera - Lens viewing angle, horizontal - 29.6–102
Camera - Lens viewing angle, vertical - 16.8–53.8
Camera - Minimum illumination - 0 lx
Camera - Number of Privacy masking areas - 4
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 77°
Category - Security Cameras
Category 1 - Netzwerk
Category 2 - Netzwerkkameras
Certificates - CE, NTRA, VCCI, KC, BSMI, FCC, IP67, IK10, ONVIF
Color - White
Connectors - RJ-45
Description - InSight S445ZI
Zmotoryzowana, zmiennoogniskowa kamera sieciowa, podczerwień, rozdzielczość 4MP 5x optyczny Zoom ułatwiający monitoring Rozdzielczość 4MP Super HD i zasięg podczerwieni do 60m Klasyfikacja ludzi i pojazdów Wykrywanie Smart Inteligentna korekcja wideo Dostępny interfejs Audio i Alarmu Klasa szczelności IP67 i klasa wytrzymałości mechanicznej IK10 Kodowanie H.265+
Design - Form factor - Turret
Design - Housing material - Metal
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling
Design - Product colour - White
Design - Protection features - Waterproof
Design - Weatherproof - Yes
Designation - CE+WEEE
dimension depth - 160 mm
dimension height - 160 mm
Dimensions - 112.3 x 112.3 x 92.5 mm
dimension weight - 990 g
dimension width - 160 mm
ean - 8885020623550
EAN - 8885020623550
EANCode - 8885020623550
Environment requirements - Dopuszczalna temperatura pracy: -30-60 °C Dopuszczalna temperatura przechowywania: -40-60 °C Dopuszczalna wilgotność powietrza: 95% lub mniej (bez kondensacji) Dopuszczalna wilgotność przechowywania: 95% lub mniej (bez kondensacji)
Frames per second - 30
Gewicht - 0
GRUPPE1 - Network
GRUPPE2 - Network Camera
GTIN - 1210002606318
GTIN - 8885020623550
guarantee - 36
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - INSIGHT S445ZI
Image sensor - Optical sensor size - 25.4 / 2.9 mm (1 / 2.9")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Impact protection - IK10
Laenge - 0
Lens - Typ: Zmotoryzowany zmiennoogniskowy obiektyw Długość ogniskowej: 2,7-13,5 mm (5x optyczny Zoom) Przysłona: F1.6
Lens system - Auto focus - Yes
Lens system - Detect distance (tele) - 207 m
Lens system - Detect distance (wide) - 66 m
Lens system - Focal length range - 2.7 - 13.5 mm
Lens system - Focus - Motorized
Lens system - Identify distance (tele) - 21 m
Lens system - Identify distance (wide) - 7 m
Lens system - Maximum aperture number - 1.6
Lens system - Number of lenses - 1
Lens system - Observe distance (tele) - 86 m
Lens system - Observe distance (wide) - 28 m
Lens system - Optical zoom - 5x
Lens system - Recognize distance (tele) - 41 m
Lens system - Recognize distance (wide) - 13 m
Lens system - Zoom capability - Yes
LongDesc - Motorized VarifocalBy adjusting the field of view (FOV), this feature assists you in concentrating on areas of interest, minimizing invalid detection zones, and enhancing target clarity.Human & Vehicle ClassificationDistinguish humans and vehicles from other objects and receive more accurate event notifications.True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.Efficient H.265+ Compression TechnologyH.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
LongProductName - InSight S445ZI VIGI 4MP IR Motorized Varifocal Turret Network Camera
LongSummaryDescription - TP-Link VIGI InSight S445ZI. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Angle of rotation: 360°, Lens viewing angle, horizontal: 29.6–102, Lens viewing angle, vertical: 16.8–53.8. Sensor type: CMOS, Optical sensor size: 25.4 / 2.9 mm (1 / 2.9"). Optical zoom: 5x, Focal length range: 2.7 - 13.5 mm, Focus: Motorized
Management, monitoring, configuration -
Management features - Cloud-managed - Yes
Management features - Reset button - Yes
Management features - Web browser - Yes
Manufacturer - TP-Link
Memory card reader - Yes
Memory standard - SD
Memory standard - SDHC
Memory standard - SDXC
Microphone - Yes
Min. illuminance - 0.005 lx
Motion detection - Yes
MPN - INSIGHT S445ZI(UN)
name - InSight S445ZI VIGI 4MP IR Motorized Varifocal Turret Network Camera
Name - TP-Link Omada IPCam InSight S445ZI 4MP IR Motorized Varifocal Turret
Network - Bluetooth - No
Network - Ethernet LAN - Yes
Network - Live view - Yes
Network - Networking standards - IEEE 802.3af, IEEE 802.3at
Network - Number of simultaneous live view channels - 6 channels
Network - Supported network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Network - Wi-Fi - No
Network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Night mode - Yes
Night vision - Infra-red wavelength - 850 nm
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 60 m
Night vision - Number of illumination LEDs - 4
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Other features -
Packaging content - Drilling template included - Yes
Packaging content - Manual - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of cameras - 1
Packaging content - Screws included - Yes
Packaging data - Package type - Box
Packaging data - Package weight - 960 g
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Dynamic range - 120 dB
Performance - Infrared (IR) cut-off filter - Yes
Performance - Placement supported - Outdoor
Performance - Remote viewing - Yes
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 10.8 W
Power - Power consumption (Power over Ethernet (PoE)) - 12 W
Power - Power source type - DC, PoE
Power supply - Gniazdo zasilania DC
producer - TP-LINK
ProductName - InSight S445ZI
Protection class - IP67
Resolution - 2688 x 1520
Security - Ochrona hasłem, Szyfrowanie HTTPS, Filtr adresów IP, Autoryzacja Digest
Security - Alarm input channels - 1
Security - Alarm output channels - 1
Security - Alert notification type - Push notification
Security - Built-in siren - Yes
Security - Digest authentication - Yes
Security - HTTPS encryption - Yes
Security - Human and vehicle targets classification - Yes
Security - IP address filtering - Yes
Security - Mirror - Yes
Security - Motion sensor - Yes
Security - Password protection - Yes
Security - Privacy protection - Yes
Security - Video motion detection - Yes
Sensor - 1/2.9" Progressive Scan CMOS
ShortSummaryDescription - TP-Link VIGI InSight S445ZI, IP security camera, Outdoor, Wired, 120 dB, Ceiling, White
Speakers built-in - No
Special functions -
Stck_Kart - 12
Stck_Pal - 0
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Maximum memory card size - 512 GB
Storno - N
System Requirements -
Title - TP-Link VIGI InSight S445ZI Turret IP security camera Outdoor 2688 x 1520 pixels Ceiling
Two-way transmission - Yes
type - fixed dome camera
URL - https://www.tp-link.com/uk/business-networking/vigi-network-camera/insight-s445zi/#highlights
vendpn - InSight S445ZI
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate - Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 512 Kbps to 1024 Kbps
Video - Bit rate control - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video - Digital Wide Dynamic Range (DWDR) - Yes
Video - Highlight Compensation (HLC) - Yes
Video - Image quality adjustment - Brightness, Contrast, Mirror, Saturation, Sharpness
Video - Maximum resolution - 2688 x 1520 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Region of Interest (ROI) encoding - Yes
Video - Smart IR - Yes
Video - Supported graphics resolutions - 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video - Total megapixels - 4 MP
Video - Video compression formats - H.264, H.264+, H.265, H.265+
Video - Video recording - Yes
Video - Video streaming - Yes
Video compression - H.264
Video compression - H.264+
Video compression - H.265
Video compression - H.265+
Viewing angle, horizontal - 102 °
Viewing angle, vertical - 53 °
Visual angle diagonal - 122 °
WarrantyInfo -
Weight - 0.71 kg
Weight - 0.978
Weight & dimensions - Diameter - 11.2 cm
Weight & dimensions - Height - 92.5 mm
Weight & dimensions - Weight - 710 g
Wireless communication - No
