MikroTik Chateau LTE6

3G - Yes
4G - Yes
10Base-T / 100Base-TX / 1000Base-T Ports - 5
Accessories included -
Antenna - Built-in
Antenna - Antenna design - Internal
Antenna - Antennas quantity - 6
Antenna gain - 4 dBi
Category Code - WAP
Certificates - CE, EAC, ROHS
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - EAC
Certificates - Compliance certificates - RoHS
Color - White
Data transmission speed - 1200 Mbps
Description - Chateau is a fast, dual-band home access point that adapts to your needs. It has a powerful quad-core ARM processor, a fast, reliable and responsive LTE CAT6 modem ensuring excellent mobile connectivity, and the most advanced network software on the market - RouterOS. Chateau has been designed to serve the most diverse user groups: IT professionals can make the most of it, while ordinary households can simply plug it in and forget it exists. With Chateau you will always have a choice.
Description - Chateau LTE6 Your best friend when it comes to affordable mobile networks. Amazing in the hands of seasoned system administrators. Or in a household with zero IT skills. Chateau can do it all. For mobile operators who want the best for their clients without breaking the bank. Are you tired of those suspicious, low-quality default routers from your service providers? So many households are switching to mobile internet, but those default routers can really ruin the experience. Not only do they lack features, speed, and power, the designs can get weird with all the black boxes and spiky antennas. That’s why we decided to take everything we’ve learned over the last 20 years of networking excellence and create a single device that will make most households happy: the MikroTik Chateau. It features a purposeful balance of extensive features, accessible pricing, and classy design that will fit right in. Chateau is a high-speed, dual-band home access point that adapts to your needs. It features a powerful quad-core ARM CPU, a fast, reliable, and responsive CAT6 LTE modem for excellent mobile connectivity, and the most advanced networking software on the market – RouterOS. But don’t worry – it can be as simple or as complex as you want. Chateau is designed to serve the most diverse user groups: IT professionals can push it to its limits, regular households can plug it in and forget it exists. With Chateau, you will always have options. 5x Gigabit Ethernet ports can be useful to connect all your home devices (media servers, PC towers, TV’s). You can also keep the LTE as a backup and use the Gigabit Ethernet to connect to a wired ISP for even higher speeds!
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product colour - White
Design - Product type - Tabletop router
Designation - CE+WEEE
dimensionalWeight - 693
dimension depth - 60 mm
dimension height - 330 mm
Dimensions - 240 x 156 x 44 mm
dimension weight - 1000 g
dimension width - 160 mm
ean - 4752224008879
Environment requirements -
Features - Built-in processor - Yes
Features - Firmware upgradeable - Yes
Features - Processor cores - 4
guarantee - 12
guarantee_type - normal
I/O ports - 1 x USB 2.0
I/O ports - 5 x 10/100/1000 Mbit/s
IEEE 802.11 b/g Network standard - Yes
IEEE 802.11ac Network standard - Yes
IEEE 802.11n Network standard - Yes
Included Accessories - 24 V 1.2 A power adapter; UTP Flat
Cable (1.5m)
Management, monitoring, configuration -
Management features - Reset button - Yes
Management features - Web-based management - Yes
Micro-SIM card tray - 1
Model - D53G-5HACD2HND-TC&FG621-EA
Model name - Chateau LTE6
name - Access point ChateauLTE6 D53 G-5HacD2HnD-TC&FG621-EA
Network - Built-in FTP server - No
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Media server - Yes
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Number of guest networks (2.4 GHz) - 2
Network - Number of guest networks (5 GHz) - 2
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating temperature (T-T) - -40 - 70 °C
Other features - Operating system: RouterOS v7 RAM size: 256MB
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 5
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB port - Yes
Power - Output current - 1.75 A
Power - Output voltage - 12 V
Power - Power source type - DC
Power supply - Number of DC inputs: 1 (DC socket) DC Jack Input Voltage: 12-28V Maximum power consumption: 21 W
Power supply requirements - 24 V 1.2 A
producer - MikroTik
producerCode - D53G-5HacD2HnD-TC&FG621-EA
productName - Mikrotik Chateau LTE6 WiFi 5 LTE Router
Product Net Weight - 0.8 kg
productSize - Normal
Security -
Security - Firewall - Yes
Security - Security algorithms - WPA3
sizeX - 340
sizeY - 170
sizeZ - 60
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Sustainability - Sustainability compliance - Yes
System Requirements -
Unit Box Height - 0.06
Unit Box Length - 0.33
Unit Box Width - 0.16
Unit Calculated Volume - 0.003511 cubm
Unit Calculated Weight - 0.938 kg
Units per Shipping Box - 20
USB 2.0 Ports - 1
Vendor Homepage - mikrotik.com/product/chateau_lte6
vendpn - D53G-5HacD2HnD-TC&FG621-EA
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - Yes
WAN connection - WAN connection type - RJ-45
Warranty - 12 months
warrantyLength - 12
warrantyType - G
weight - 900
Weight & dimensions - Depth - 44 mm
Weight & dimensions - Height - 156 mm
Weight & dimensions - Width - 240 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - 2,4 GHz, 5 GHz
Wireless LAN features - Wi-Fi standards - 802.11 ac
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11n
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (first band) - 300 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 5400 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 867 Mbit/s
