MikroTik mAP

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 270568 Product code: RBmAP2nD
In stock >50 units
Warranty: 2 years (Warranty for business entities 1 year)
48.13 €
39.78 € w/o VAT
Ready for dispatch
on Wednesday, 23.09.2026
starting from 0 € with VAT
Delivery options
  • Receiving goods at the Dateks office
    0.00 €
  • DPD Pickup Parcel Cabinet
    Within 1-2 working days
    0.00 €
  • Parcel terminal
    Within 1-2 working days
    0.00 €
  • Post Office
    Within 1-2 working days
    0.00 €
  • Omniva parcel machine
    Within 1-2 working days
    0.00 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    0.00 €
  • Unisend parcel terminal
    Within 1-2 working days
    0.00 €
  • Delivery throughout Latvia.
    Within 1-2 working days
    4.99 €
Main product parameters All parameters
  • Speed index: N/A
  • Type of device: Access Point
Basic information
Speed index : N/A
Type of device Access Point

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Functionality
3G/4G support None

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode N/A

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 10/100

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.



Ports and equipment
LAN ports : 0
Wireless
More detailed specification
2.4 GHz Features - Yes
5 GHz Features - No
AC adapter included Packaging content - Yes
Antenna - Antenna gain level (max) - 1.2 dBi
Antenna gain level (max) Antenna - 1.2 dBi
Auto MDI/MDI-X Features - Yes
brand - MikroTik
Built-in processor Performance - Yes
Cables included Packaging content - USB
category - MikroTik > Wi-Fi mājai un ofisam > mAP
Category - Root/Electronics/Networks and communication/Access points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Code - RBmAP2nD
Dane techniczne: Częstotliwość - 2.4 GHz
Dane techniczne: Gwarancja - 1 rok w serwisie sprzedawcy
Dane techniczne: Głębokość - 68 mm
Dane techniczne: LAN 10/100 Mb/s - tak (2 sz.)
Dane techniczne: Obsługiwane protokoły - IEEE 802.3af
Dane techniczne: Obsługiwane protokoły - IEEE 802.3at
Dane techniczne: Producent - MikroTik
Dane techniczne: Prędkość transmisji - 300 Mbps
Dane techniczne: Rodzaj - wolnostojący
Dane techniczne: Standard - Wi-Fi 4 (802.11b/g/n)
Dane techniczne: Szerokość - 68 mm
Dane techniczne: Wysokość - 19 mm
Dane techniczne: Zarządzanie - RouterOS
Dane techniczne: Zasilanie - zasilacz | PoE | microUSB
DC-in jack Ports & interfaces - Yes
Depth Weight & dimensions - 68 mm
Description - The mAP (micro Access Point) is a tiny size wireless Dual-Chain 2.4GHz Access Point with full RouterOS capabilities. It is very portable, since it accepts power from a wide variety of sources - USB, Passive PoE and power jack. It also works as a PoE injector - the second Ethernet port provides up to 500mA of power to another device, for example, you can connect a SXT CPE device to it.
Design - Internal - No
Design - LED indicators - Yes
Design - Placement - Table
Design - Product colour - Black
Design - Product colour - White
dimensionalWeight - 156
EAN - 2000001037492
EAN - 4752224004291
Eans - 4752224004291
Ethernet LAN (RJ-45) ports Ports & interfaces - 2
Ethernet LAN data rates Features - 10,100 Mbit/s
Features - 2.4 GHz - Yes
Features - 5 GHz - No
Features - Auto MDI/MDI-X - Yes
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 100
Features - Networking standards - IEEE 802.3af
Features - Networking standards - IEEE 802.3at
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features > MU-MiMO - No
Flash memory Performance - 16 MB
Gross weight - 0.38 kg
Harmonized System (HS) code Logistics data - 85176990
height - 0.067 m
Height Weight & dimensions - 19 mm
Internal Design - No
Internal memory Performance - 64 MB
LED indicators Design - Yes
length - 0.18 m
Logistics data - Harmonized System (HS) code - 85176990
Manufacturer - MikroTik
Model name - mAP // RBmAP2nD
mpn - RBmAP2nD
MPN - RBMAP2ND
Name - MikroTik RBMAP2ND
Name - MikroTik RBmAP2nD
Name - MikroTik | mAP RBmAP2nD | 802.11n | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 2 | MU-MiMO No
Networking standards Features - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, IEEE 802.3at
Operating relative humidity (H-H) Operational conditions - -10 - 70%
Operating system installed Performance - Linux
Operational conditions - Operating relative humidity (H-H) - -10 - 70%
Output current Power - 0.8 A
Output voltage Power - 24 V
Package features > Gross depth (mm) - 176 mm
Package features > Gross height (mm) - 55 mm
Package features > Gross width (mm) - 73 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 1223 pc(s)
Package features > Paper/Pasteboard - 100 g
Package features > Tare weight (kg) - 0.1 kg
Package features > Volume (m3) - 0.00070664 m³
Package features > WEE classification - CL109:6:2017-04-01
Packaging content - AC adapter included - Yes
Packaging content - Cables included - USB
Performance - Built-in processor - Yes
Performance - Flash memory - 16 MB
Performance - Internal memory - 64 MB
Performance - Operating system installed - Linux
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Placement Design - Table
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB connector type - USB Type-B
Ports & interfaces > Ethernet LAN (RJ-45) ports - 2
Ports & interfaces > POE - PoE in/out
Power - Output current - 0.8 A
Power - Output voltage - 24 V
Power - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) Power - Yes
Producer - MikroTik
producerCode - RBmAP2nD
ProducerCode - RBMAP2ND
Producer product name - mAP RBmAP2nD
Product colour Design - Black, White
productName - Mikrotik mAP Black, White Power over Ethernet (PoE)
productSize - Normal
Safety warning - Warnings - Do not open the appliance - risk of electric shock.
Safety warning - Warnings - Do not use in damp conditions.
Safety warning - Warnings - Make sure the unit is stably mounted and ventilated.
ShortDescription -
sizeX - 180
sizeY - 75
sizeZ - 58
Summary - Mikrotik mAP. 2.4 GHz, Ethernet LAN data rates: 10,100 Mbit/s. Power over Ethernet (PoE). Product colour: Black, White
Technical details > Net weight - 0.28 kg
Technical details > Producer - MikroTik
Technical details > Software type - RouterOS (Level 4)
title - MikroTik mAP
Unit Box Height - 0.055
Unit Box Length - 0.175
Unit Box Width - 0.075
Unit Calculated Volume - 0.001057 cubm
Unit Calculated Weight - 0.267 kg
Units per Pallet - 0
Units per Shipping Box - 20
USB 2.0 ports quantity Ports & interfaces - 1
USB connector type Ports & interfaces - USB Type-B
Vendor Homepage - https://mikrotik.com/product/RBmAP2nD
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
warrantyLength - 12
warrantyType - G
Weight - 0.24
weight - 0.265 kg
weight - 250
Weight & dimensions - Depth - 68 mm
Weight & dimensions - Height - 19 mm
Weight & dimensions - Width - 68 mm
width - 0.08 m
Width Weight & dimensions - 68 mm
Wireless LAN features > Wi-Fi band - 802.11n
