Accessories included - 4G LTE router Charger RJ45 Ethernet cable Quick Installation Guide
Aero2 support - No
Antenna - Built-in
Antenna - Antenna connector type - SMA
Antenna - Antenna design - Internal & external
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna - Detachable antenna(s) - Yes
Brand - Cudy
BrandPartCode - LT700E 1.0
Category - Wireless Routers
Category 1 - Netzwerk
Category 2 - Router
Certificates -
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC)
Color - White
Data Act - Link
Data transmission - HSDPA
Data transmission - HSUPA
Data transmission - LTE
Data transmission - UMTS
Description - Advanced 4G LTE Cat. 6 up to 300 Mbps DL Fast dual-band AC1200 Wi-Fi 4×gigabit ports 2× internal 4G antennas + 2× internal Wi-Fi antennas Nano SIM card slot VPN Zerotier, Wireguard, OpenVPN, IPSec, L2TP, PPTP
Design - LED indicators - System, WLAN
Design - Product colour - White
Design - Product type - Desktop/pole router
Design - Wall mountable - Yes
Designation - CE+WEEE
dimensionalWeight - 552
dimension depth - 60 mm
dimension height - 170 mm
Dimensions - 190 × 50 × 148.8 mm
dimension weight - 610 g
dimension width - 270 mm
ean - 6971690792879
EAN - 6971690792879
Environment requirements - Operating temperature: 0°C - 40°C Operating humidity: 10% - 90% non-condensing Storage temperature: -30°C - 70°C Storage humidity: 5% - 95%, non-condensing
Features - Flash memory - 16 MB
Features - Internal memory - 128 MB
GTIN - 6971690792879
guarantee - 24
guarantee_type - normal
LongDesc - A 4G LTE Advanced WiFi router with a nano-SIM slot, internal antennas, and four GbE, providing high-performance and flexible networks for home, office, surveillance, exhibitions, and RV scenarios.Responsive 4G up to 300 Mbps DownloadFeaturing Carrier Aggregation, the LT700E streams data on two carrier bands simultaneously, providing 2X available bandwidth to avoid congestion. Combined with 4x4 MIMO for improved signal quality, the LT700E delivers a more stable high-speed experience.A Powerful Connectivity HubReponsive AC1200 Wi-FiDual-band WiFi allows newer devices to stream on the less congested 5 GHz band, while IoT and legacy devices can connect to the 2.4 GHz band, making your video chatting, 4K playback, and light control, feel as smooth as possible.Full Gigabit PortsShare a wired network capable of speeds up to 1,000 Mbps, providing a high-bandwidth backbone, especially for NAS and creative PCs. The LAN/WAN port can be configured as a WAN port, connecting to another ISP and enabling WAN failover if the SIM card is also utilized.Abundant Features for Detailed TweakingOnline RedundancyWAN/Cellular backup provides robust network resilience, making it suitable for surveillance and other always-online scenarios.Band LockThe 4G Band Lock allows the user to lock the working frequency to one or several bands.TTL SettingsSupport manual sets TTL values to meet ISP's requirements (such as Verizon and Visible). Support set IPv4 TTL and IPv6 HL Values.DNS EncryptionAllow encrypting domain lookups, preventing eavesdropping and manipulation of DNS data from a man-in-the-middle attack.Easy Setup and Versatile ManagementPlug and PlayInsert your Nano SIM card with an active subscription plan, power on the router, and enjoy the Wi-Fi.Schedule and FilteringSet a bed time and a domain blacklist to regulate your children's online behavior.VPN Server and ClientZeroTier/WireGuard/OpenVPN/IPSec/L2TP/PPTP are available for boundless VPN applications.Fast RoamingWorks as Cudy a Mesh main node to enable fast roaming when using with other Cudy Mesh devices.Cudy AppManage your network from your phone. This model supports cloud remote control and local control via the Cudy App.
LongProductName - 4G Cat 6 AC1200 Wi-Fi Router, LT700E 1.0
LongSummaryDescription - Cudy 4G Cat 6 AC1200 Wi-Fi Router, LT700E 1.0. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Mobile network generation: 4G, 2G standards: Edge, GSM, 3G standards: WCDMA. Security algorithms: WPA, WPA2, WPA3
LTE network - 600 MHz
LTE network - 700 MHz
LTE network - 800 MHz
LTE network - 850 MHz
LTE network - 1500 MHz
LTE network - 1800 MHz
LTE network - 1900 MHz
LTE network - 2100 MHz
LTE network - 2300 MHz
LTE network - 2500 MHz
LTE network - 2600 MHz
LTE network - 3400 MHz
Management, monitoring, configuration - VPN VPN Server and Client Options: Zerotier, Wireguard, OpenVPN, IPSec, L2TP, PPTP DNS Override All Clients' DNS, Rebind Protection, DNS Over TLS, Manual DNS DNS over TLS Options: Cloudflare, Google, Quad9 Multi-Mode Router (4G/WAN), WISP (4G as Backup), WISP Clients Management Internet Block, Internet/Wi-Fi Schedule, VPN Block, Device Rename Network Management QoS, DDNS, WAN/LAN Switch Firewall SPI Firewall, DoS Protection, Block PING NAT Port Forwarding, Port Triggering, UPnP, DMZ TTL Extend, Spoof, Custom IPv6 Relay, Dynamic(SLAAC/DHCPv6), Staic (Fixed IP), Passthrough, MAP-E, DS-Lite DHCP Server, Client List, Address Reservation CWMP TR069, TR098, TR111, TR181, Support STUN
Management features - MIMO - Yes
Management features - MU-MIMO technology - Yes
Management features - Reset button - Yes
Management features - Wake-on-LAN ready - Yes
Management features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Management features - WPS push button - Yes
Manufacturer - Cudy
Max download speed - 300 Mbit/s
Max upload speed - 50 Mbit/s
Mobile network - 2G standards - Edge, GSM
Mobile network - 3G standards - WCDMA
Mobile network - 4G standard - LTE-TDD & LTE-FDD
Mobile network - Dual SIM support - No
Mobile network - Mobile network generation - 4G
Mobile network - Short Message Service (SMS) - Yes
Mobile network - SIM card type - NanoSIM
Model - LT700E
MPN - LT700E
Name - Cudy AC1200 Wi-Fi 4G LTE-Cat6 Gigabit Router
name - Router Gigabit AC1200 4G LTE SIM LT700E
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Port forwarding - Yes
Network - Port triggering - Yes
Network - VPN server - Yes
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Mounting kit - Yes
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 58 mm
Packaging data - Package height - 168 mm
Packaging data - Package weight - 595 g
Packaging data - Package width - 270 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB port - No
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Output current - 1 A
Power - Output voltage - 12 V
Power - Power consumption (typical) - 3.6 W
Power - Power source type - PoE
Power supply - DC 12 V 1.5 A
producer - Cudy
producerCode - LT700E
ProductName - 4G Cat 6 AC1200 Wi-Fi Router, LT700E 1.0
productName - Wireless Router Cudy LT700E WiFi 5 AC1200 4G LTE Cat6 3xLAN 1xWAN/LAN
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Supported network protocols - IPv4 / IPv6
Protocols - Universal Plug and Play (UPnP) - Yes
Security - WPA-PSK WPA2-PSK WPA-PSK/WPS2-PSK
Security - DMZ support - Yes
Security - DoS attack prevention - Yes
Security - Guest access - Yes
Security - IGMP snooping - Yes
Security - MAC address filtering - Yes
Security - Security algorithms - WPA, WPA2, WPA3
ShortSummaryDescription - Cudy 4G Cat 6 AC1200 Wi-Fi Router, LT700E 1.0, Wi-Fi 5 (802.11ac), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, 4G, White, Desktop/pole router
SIM card - Nano
sizeX - 271
sizeY - 170
sizeZ - 60
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Standards - IPv6
Supported operating systems - Linux
Supported operating systems - Mac OS
Supported operating systems - Novell NetWare
Supported operating systems - Unix
Supported operating systems - Windows
System Requirements -
System requirements - Linux operating systems supported - Yes
System requirements - Mac operating systems supported - Yes
System requirements - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 2000, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows 98SE, Windows Vista, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Title - Cudy 4G Cat 6 AC1200 Wi-Fi Router, LT700E 1.0 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
Type - GSM 3G/4G
UMTS network - 850 MHz
UMTS network - 900 MHz
UMTS network - 2100 MHz
URL - https://www.cudy.com/products/lt700e-1-0?_pos=1&_psq=LT700E&_ss=e&_v=1.0#features
vendpn - LT700E
WAN connection - DSL WAN - Yes
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - Yes
WAN connection - WAN connection type - RJ-45
WarrantyInfo -
warrantyLength - 24
warrantyType - F
Weight - 0.596
weight - 592
Weight & dimensions - Depth - 50 mm
Weight & dimensions - Height - 148.8 mm
Weight & dimensions - Weight - 300 g
Weight & dimensions - Width - 190 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (first band) - 300 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 867 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 867 Mbit/s
