Dahua NET VIDEO RECORDER 4CH 4POE/NVR2104-P-4KS3

Audio - Audio codecs - PCM; G711A; G711U; G726
Audio - Emergency call - Yes
Audio formats supported Performance - G.711 A-law, G.711 μ-law, G.726
Audio RCA inputs Ports & interfaces - 1
Audio RCA outputs Ports & interfaces - 1
Backup function Performance - Yes
Brand - Dahua Technology
BrandPartCode - NVR2104-P-4KS3
Browser supported System requirements - Chrome, IE, Safari, Edge, Firefox
Built-in processor Processor - Yes
Category - Network Video Recorders (NVR)
Category Code - NVR
DC-in jack Ports & interfaces - Yes
Depth Weight & dimensions - 206.4 mm
Description - The NVR2000-4KS3 model of the Lite Series NVR is favored for its outstanding performance. It supports 4K resolution for scenes that require highly detailed images, and can serve as the edge, central, or backup storage with an intuitive shortcut menu for remote management and control. This NVR also features Smart Motion Detection (SMD) by recorder, which can distinguish target vehicles and humans from ordinary ones in real-time. This NVR is both cost- effective and easy-to-install, making it ideal for a wide range of applications such as villas, shops and other small and medium-sized scenes. SMD Plus
With intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and ilter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm. Perimeter Protection by Camera
Automatically ilters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formatsMax. decoding capability: 6 × 1080p@30 fpsMax. 80/80/60 Mbps incoming/recording/outgoing bandwidthSupports IP cameras with a resolution up to 12 MPAI by Recorder supports 4-channel SMDAI by Camera supports perimeter protection and SMDSupports one-click arming and disarming
dimensionalWeight - 1731
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN data rates Ports & interfaces - 10,100 Mbit/s
Features - Product colour - White
GTIN - 6923172573520
Hard drive - HDD interface - SATA
Hard drive - Maximum storage capacity - 20 TB
Hard drive - Number of HDDs supported - 1
HDD interface Hard drive - SATA
HDMI output Ports & interfaces - Yes
HDMI ports quantity Ports & interfaces - 1
Height Weight & dimensions - 45.6 mm
Input bandwidth Performance - 80 Mbit/s
LongDesc - The NVR2000-4KS3 model of the Lite Series NVR is favored for its outstanding performance. It supports 4K resolution for scenes that require highly detailed images, and can serve as the edge, central, or backup storage with an intuitive shortcut menu for remote management and control. This NVR also features Smart Motion Detection (SMD) by recorder, which can distinguish target vehicles and humans from ordinary ones in real-time. This NVR is both cost- effective and easy-to-install, making it ideal for a wide range of applications such as villas, shops and other small and medium-sized scenes.SMD PlusWith intelligent algorithm, Dahua Smart Motion Detection technology can categorize the targets that trigger motion detection and ilter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.Perimeter Protection by CameraAutomatically ilters out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improves alarm accuracy.
LongProductName - 4-ch, 80 Mbps/60 Mbps, 12 MP, HDMI, VGA, RCA in, RCA out, 1 x SATA, 2 x USB 2.0, RJ-45, 4 x PoE, 480 g
LongSummaryDescription - Dahua Technology Lite NVR2104-P-4KS3. Video input channels: 4 channels, Maximum resolution: 3840 x 2160 pixels, Number of simultaneously playbacked channels: 4 channels. Maximum storage capacity: 20 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports.... Product colour: White. Power consumption (max): 36 W, Power consumption (typical): 10 W, Output current: 1.22 A
Maximum resolution Performance - 3840 x 2160 pixels
Maximum storage capacity Hard drive - 20 TB
Mobile operating systems supported System requirements - Android, iOS
Model - NVR2104-P-4KS3
Model name - NVR2104-P-4KS3
Networking standards Ports & interfaces - IEEE 802.3af, IEEE 802.3at
Number of HDDs supported Hard drive - 1
Number of simultaneously playbacked channels Performance - 4 channels
Operating relative humidity (H-H) Operational conditions - -20 - 60%
Operating system installed Performance - Embedded LINUX
Operating temperature (T-T) Operational conditions - -10 - 55 °C
Operational conditions - Operating relative humidity (H-H) - -20 - 60%
Operational conditions - Operating relative humidity (H-H) - 10 - 93%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage temperature (T-T) - 10 - 93 °C
Output bandwidth Performance - 60 Mbit/s
Output current Power - 1.22 A
Output voltage Power - 53 V
Package depth Weight & dimensions - 96 mm
Package height Weight & dimensions - 261 mm
Package weight Weight & dimensions - 1.42 kg
Package width Weight & dimensions - 364 mm
Performance - Audio formats supported - G.711 A-law, G.711 μ-law, G.726
Performance - Backup function - Yes
Performance - Input bandwidth - 80 Mbit/s
Performance - Maximum resolution - 3840 x 2160 pixels
Performance - Number of simultaneously playbacked channels - 4 channels
Performance - Operating system installed - Embedded LINUX
Performance - Output bandwidth - 60 Mbit/s
Performance - Playback modes - Instant playback, general playback, event playback, tag playback, smart playback
Performance - Recording modes - Motion detection, manual recording, smart recording, alarm
Performance - SMD Plus - Yes
Performance - Video formats supported - H.264+, H.265, H.265+, M-JPEG
Performance - Video input channels - 4 channels
Performance - Video motion detection - Yes
Ports & interfaces - Audio RCA inputs - 1
Ports & interfaces - Audio RCA outputs - 1
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Ethernet LAN data rates - 10
Ports & interfaces - Ethernet LAN data rates - 10,100 Mbit/s
Ports & interfaces - Ethernet LAN data rates - 100
Ports & interfaces - HDMI output - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Networking standards - IEEE 802.3af, IEEE 802.3at
Ports & interfaces - PoE Port - 4*10/100Mbps
Ports & interfaces - PoE standard - IEEE 802.3af/at
Ports & interfaces - Power over Ethernet (PoE) - Yes
Ports & interfaces - Power over Ethernet (PoE) ports quantity - 4
Ports & interfaces - Supported network protocols - HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - VGA (D-Sub) output ports - 1
Power - Input voltage - 53 V
Power - Output current - 1.22 A
Power - Output voltage - 53 V
Power - Power consumption (max) - 36 W
Power - Power consumption (typical) - 10 W
Power - Power over Ethernet (PoE) power per port - 25.5 W
Power consumption (max) Power - 36 W
Power consumption (typical) Power - 10 W
Power over Ethernet (PoE) Ports & interfaces - Yes
Power over Ethernet (PoE) ports quantity Ports & interfaces - 4
Power over Ethernet (PoE) power per port Power - 25.5 W
Processor - Built-in processor - Yes
producerCode - NVR2104-P-4KS3
Product colour Features - White
productName - DAHUA NVR2104-P-4KS3 IP RECORDER
ProductName - NVR2104-P-4KS3
productSize - Normal
Safety warning - Warnings - Do not expose the device to moisture or extreme temperatures.
Safety warning - Warnings - The appliance should be installed by a qualified professional.
Safety warning - Warnings - The product must be disposed of properly in accordance with local regulations for the disposal of electronics.
ShortSummaryDescription - Dahua Technology Lite NVR2104-P-4KS3, 4 channels, 3840 x 2160 pixels, 4 channels, G.711 A-law, G.711 μ-law, G.726, H.264+, H.265, H.265+, M-JPEG, Embedded LINUX
sizeX - 370
sizeY - 260
sizeZ - 90
Storage temperature (T-T) Operational conditions - 10 - 93 °C
Summary - Dahua Technology Lite NVR2104-P-4KS3. Video input channels: 4 channels, Maximum resolution: 3840 x 2160 pixels, Number of simultaneously playbacked channels: 4 channels. Maximum storage capacity: 20 TB, HDD interface: SATA. Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.3af, IEEE 802.3at, Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports.... Product colour: White. Power consumption (max): 36 W, Power consumption (typical): 10 W, Output current: 1.22 A
Supported network protocols Ports & interfaces - HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration
System requirements - Browser supported - Chrome, IE, Safari, Edge, Firefox
System requirements - Browser supported - IE, Edge, Chrome, Firefox, Safari
System requirements - Mobile operating systems supported - Android
System requirements - Mobile operating systems supported - Android, iOS
System requirements - Mobile operating systems supported - iOS
Title - Dahua Technology Lite NVR2104-P-4KS3 network video recorder White
Unit Box Height - 0.26
Unit Box Length - 0.36
Unit Box Width - 0.09
Unit Calculated Volume - 0.01102 cubm
Unit Calculated Weight - 1.51 kg
Units per Pallet - 0
Units per Shipping Box - 10
URL - https://www.dahuasecurity.com/products/All-Products/Network-Recorders/Lite-Series/NVR2-4KS3-Series/1HDD/NVR2104-P-4KS3
USB 2.0 ports quantity Ports & interfaces - 2
Vendor Homepage - https://www.dahuasecurity.com/products/All-Products/Network-Recorders/Lite-Series/NVR2-4KS3-Series/1HDD/NVR2104-P-4KS3
VGA (D-Sub) output ports Ports & interfaces - 1
Video - Maximum resolution (HDMI) - 3840 x 2160 pixels
Video - Video codecs - Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Video formats supported Performance - H.264+, H.265, H.265+, M-JPEG
Video input channels Performance - 4 channels
Video motion detection Performance - Yes
Warranty - 36 months
WarrantyInfo -
warrantyLength - 36
warrantyType - F
weight - 1380
Weight & dimensions - Depth - 206.4 mm
Weight & dimensions - Height - 45.6 mm
Weight & dimensions - Package depth - 96 mm
Weight & dimensions - Package height - 261 mm
Weight & dimensions - Package weight - 1.42 kg
Weight & dimensions - Package width - 364 mm
Weight & dimensions - Weight - 480 g
Weight & dimensions - Width - 204.6 mm
Weight Weight & dimensions - 480 g
Wi-Fi Wireless LAN features - No
Width Weight & dimensions - 204.6 mm
Wireless LAN features - Wi-Fi - No
