Alarm In Input/Output connectors - 1
Alarm Out Input/Output connectors - 1
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Camera design - Bullet
Category Code - FNC
Colour - White
Description - > 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition image. > Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688 × 1520 (2688 × 1520) @25/30 fps. > H.265 codec, high compression rate, ultra-low bit rate. > Built-in IR LED, and the max. illumination distance is 60 m. > ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments. > Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. > Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human). > Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection. > Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports); supports max. 256 G Micro SD card; built in MIC. > 12 VDC/PoE power supply, easy for installation. > IP67, IK10 (optional) protection. > SMD Plus.
Dimensions - 238.5 mm × 90.7 mm × 90.7 mm
Effective pixels - 2960 (H) × 1668 (V)
Electronic Shutter Speed - Auto/Manual 1/3 s–1/100,000 s
Environment - Outdoor
Focal Length - 2.7 mm–13.5 mm
IR Illumination - Yes
Lens Mount - M14
Min. Illumination - 0.0007 Lux
Model - IPC-HFW2541T-ZAS27135S2
Network Camera Type - HDTV/Megapixel/Outdoor
Operating temperature range - –30 °C to +60 °C
Power consumption - 3.1 Watts
Power options - 12V/PoE
Power supply requirements - 12 VDC/PoE (802.3af)
Product Net Weight - 0.77 kg
Resolution - 5 Mega Pixel
RJ45 Input/Output connectors - 1
Sensor size - 1/2.7"
Supports card capacities up to - 256GB
Unit Box Height - 0.14
Unit Box Length - 0.31
Unit Box Width - 0.16
Unit Calculated Volume - 0.006944 cubm
Unit Calculated Weight - 1.03 kg
Units per Shipping Box - 1
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/Network-Cameras/WizSense-Series/2-Series/5MP/IPC-HFW2541T-ZAS=S2
Warranty - 36 months
