Brand - ARCTIC
BrandPartCode - ACFAN00126A
Category - Computer Cooling Systems
Category_1 - Computer Cases and Cooling
Category_2 - Fans
Design - Fan connector - 4-pin + 4-pin
Design - Number of fan blades - 5
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
EAN_code - 4895213701570
GTIN - 0872767009516
GTIN - 872767009516
GTIN - 4895213701570
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - Our coolers have pushed the limits further every year - and all that at dropping noise levels. We have put our utmost effort into innovative technologies and fair prices, what made us well known for products with an unparalleled price/performance ratio. We provide you headroom for over-clocking and guarantee you lowest noise levels at affordable prices.
LongProductName - 140 mm, 200 - 1700 RPM, PWM, 72.8 CFM, 123.76 m3/h, 12 V DC, 4-pin + 4-pin, 194 g
LongSummaryDescription - ARCTIC P14 PWM PST CO Pressure-optimised 140 mm Fan with PWM PST for Continuous Operation. Type: Fan, Fan diameter: 14 cm, Rotational speed (min): 200 RPM, Rotational speed (max): 1700 RPM, Noise level: 0.3 sone, Airflow: 123.76 m³/h, Maximum air pressure: 2.4 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 140 mm, Depth: 140 mm, Height: 27 mm. Product colour: Black
Manufacturer - Arctic
Manufacturer_code - ACFAN00126A
Name - Arctic P14 PWM PST CO 140x140x25 - ACFAN00126A
Other features - Country of origin - China
Packaging content - Number of screws - 4
Packaging content - Package type - Box
Packaging content - Screws included - Yes
Performance - Airflow - 123.76 m³/h
Performance - Bearing type - Fluid Dynamic Bearing (FDB)
Performance - Compatible processor series - Not supported
Performance - Fan diameter - 14 cm
Performance - Maximum airflow - 72.8 cfm
Performance - Maximum air pressure - 2.4 mmH2O
Performance - Noise level - 0.3 sone
Performance - Noise level (high speed) - 24.5 dB
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Rotational speed (max) - 1700 RPM
Performance - Rotational speed (min) - 200 RPM
Performance - Suitable location - Computer case
Performance - Supported processor sockets - Not supported
Performance - Type - Fan
Power - Power consumption (typical) - 1.44 W
Power - Rated current - 0.12 A
Power - Starting voltage - 3.9 V
Power - Voltage - 12 V
ProductName - P14 PWM PST CO Pressure-optimised 140 mm Fan with PWM PST for Continuous Operation
ShortSummaryDescription - ARCTIC P14 PWM PST CO Pressure-optimised 140 mm Fan with PWM PST for Continuous Operation, Fan, 14 cm, 200 RPM, 1700 RPM, 0.3 sone, 123.76 m³/h
Title - ARCTIC P14 PWM PST CO Pressure-optimised 140 mm Fan with PWM PST for Continuous Operation
URL - https://www.arctic.ac/eu_en/p14-pwm-pst-co.html
WarrantyInfo - 10 years
Weight - 0,24
Weight & dimensions - Cable length - 0.4 m
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 27 mm
Weight & dimensions - Package depth - 143 mm
Weight & dimensions - Package height - 29 mm
Weight & dimensions - Package weight - 234 g
Weight & dimensions - Package width - 143 mm
Weight & dimensions - Weight - 194 g
Weight & dimensions - Width - 140 mm
