ARTIKEL1 - EASY UPS 3S 10 KVA 400V 3:1 UPS
ARTIKEL2 - 1 INT. 7AH MODULAR BATT STRING
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 240 V
Brand - APC
BrandPartCode - E3SUPS10K3IB1
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Compliance certificates - RoHS
Design - Form factor - Tower
Design - International Protection (IP) code - IP20
Design - Product colour - White
EANCode - 0731304428138
Features - Crest factor - 3:1
Features - ECO mode - Yes
Features - Input current Total Harmonic Distortion (THD) - 4%
Features - Input frequency - 45/65 Hz
Features - Input operation voltage (max) - 477 V
Features - Input operation voltage (min) - 304 V
Features - Input power factor - 0.99
Features - Noise level - 60 dB
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 10000 W
Features - Output power capacity - 10 kVA
Features - Output voltage Total Harmonic Distortion (THD) - 5.5%
Features - Power protection features - Overload
Features - UPS topology - Double-conversion (Online)
Gewicht - 280
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 0731304428138
GTIN - 731304428138
HERSTELLER - APC
HSTNUMMER - E3SUPS10K3IB1
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - Easy to install fastQuickly roll the compact and lightweight UPS into position.ECO ModeOperating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protectionEasy Loop TestVerifies UPS performance before you connect your load, without the need for a load bank.Straightforward installationIncluding the input, output, and bypass breakers, as well as the Emergency Power Off (EPO) switch, simplifies installation planning and speeds up deployment.Front-access servicingSimplifies installation and UPS maintenance while minimizing space requirements.Intuitive user interfaceThe intuitive graphical user interface allows for easy system configuration.Replaceable dust filtersprotect the UPS in harsh environments.Optional SNMP CardWhen you purchase the SNMP card, you can monitor and manage UPS status remotely through the UPS Web interface or through EcoStruxure IT's cloud-based and on-premise software suites. Click here for more information about EcoStruxure IT.Wide Input Voltage WindowSaves your battery power for when you really need it - during power cuts!Parallel capabilityMultiple units can be placed in parallel to meet power capacity and redundancy requirements
LongProductName - 10 kVA, 10 kW, 220-240V, 50/60Hz, 60 dB, IP20
LongSummaryDescription - APC E3SUPS10K3IB1. UPS topology: Double-conversion (Online), Output power capacity: 10 kVA, Output power: 10000 W. Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 240 V. Form factor: Tower, Product colour: White, International Protection (IP) code: IP20. Compliance certificates: RoHS. Width: 380 mm, Depth: 907 mm, Height: 14000 mm
Operational conditions - Non-operating altitude - 0 - 15240 m
Operational conditions - Operating altitude - 0 - 1000.05 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -15 - 40 °C
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 1014 mm
Packaging data - Package height - 1640 mm
Packaging data - Package width - 563 mm
ProductName - E3SUPS10K3IB1
ShortSummaryDescription - APC E3SUPS10K3IB1, Double-conversion (Online), 10 kVA, 10000 W, 304 V, 477 V, 45/65 Hz
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Title - APC E3SUPS10K3IB1 uninterruptible power supply (UPS) Double-conversion (Online) 10 kVA 10000 W
URL - https://www.apc.com/shop/pk/en/products/Easy-UPS-3S-10-kVA-400V-3-1-UPS-1-internal-7Ah-modular-battery-string-expandable-to-3/P-E3SUPS10K3IB1
WarrantyInfo -
Weight & dimensions - Depth - 907 mm
Weight & dimensions - Height - 14000 mm
Weight & dimensions - Weight - 157 kg
Weight & dimensions - Width - 380 mm
