Brand - QNAP
BrandPartCode - QUCPE-3032-C3558R-8G
Category - Network Virtualization Premise Equipments
Category 1 - Netzwerk
Category 2 - NAS-Systeme
Design - Backlight display - Yes
Design - Built-in display - Yes
Design - Chassis type - Compact
Design - Cooling type - Active
Design - Display type - LCD
Design - LED indicators - Yes
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
EAN - 4711103080986
GTIN - 4711103080986
LongDesc - Network Virtualization Premise Equipment with an Intel® Atom Refresh quad-core processor, suitable for deploying virtual networks in multiple edge officesQNAP’s QuCPE-3032 Network Virtualization Premise Equipment is a universal virtualization platform specifically designed for SMBs. The QuCPE-3032 adopts the high-performance Intel® Atom Refresh quad-core processor that supports Intel® QAT, Smart NIC SR-IOV and DPDK hardware acceleration technologies while also providing eight 2.5GbE RJ45 ports and two 10GbE SFP+ ports. With enhanced bandwidth and computing performance for running VNFs and connecting SD-WAN (Supporting VPN/WireGuard), the QuCPE-3032 is suitable for multi-user and multi-tasking business applications. The QuCPE-3032 also features the QNE (QNAP Network Equipment) OS for chaining VNF services and AMIZ Cloud centralized deployment and management platform to realize flexible Zero Touch Provisioning.Build a multi-site network infrastructure for SMBs and Micro-enterprisesQNAP’s high-performance QuCPE integrates the QuWAN SD-WAN solution, AMIZ Cloud platform, and WireGuard VPN. Small businesses and micro-enterprises can flexibly build multi-site network infrastructure by deploying a QuCPE Series 7 in their headquarters, and QuCPE Series 3 in their branches and workplaces.Easily deploy virtual network environments with the 2-in-1 Premise EquipmentWhen deploying virtualized environments, Enterprises often choose to install costly enterprise-grade solutions on edge servers or free solutions with limited technical support – a hard decision for resource-constricted SMBs. In addition, simultaneously running multiple VMs can impact network performance. QNAP’s QuCPE Network Virtualization Premise Equipment combines hardware acceleration technologies, QNAP’s proprietary QNE Network operating system and the AMIZ Cloud centralized management platform to help SMBs build a highly-optimized virtual network infrastructure.The QNE Network Operating System completes your virtual network infrastructureQNAP’s proprietary QNE Network operating system supports the intuitive Network Service Composer and Software-Defined WAN (SD-WAN), allowing for flexible network deployment and multi-site network infrastructure expansion. By supporting Virtual Network Functions (VNF), Virtual Machines and Containers, QNE Network integrates network, computing, and application services to realize network virtualization, application virtualization and efficient management, greatly lowering management and maintenance complexity.AMIZ Cloud - powerful centralized VM management platformThe AMIZ Cloud centralized management platform enables HQ-based IT staff to centrally monitor all edge devices, virtual machines, and containers. Supporting troubleshooting, and remote management via the Account Center, the QuCPE-3032 helps enterprises achieve Zero Touch Provisioning, thus enhancing IT deployment efficiency and reducing maintenance costs.Efficient management via Service Composer with visualized topologyWith the visualized topology of the Network Service Composer, you can easily set up VNFs or VMs, create virtual switches, and allocate physical network resources for chained services by drag and drop. When settings change, you can directly add/remove individual VNFs using the service composer, greatly simplifying operational network combination.SD-WAN enables chaining network servicesQNE incorporates QNAP’s QuWAN SD-WAN solution (subscription-free) to form encrypted VPN tunnels with other QNAP devices based in multiple sites and achieve multi-site network services chaining. For example, you can automatically create a firewall network (using QuWAN and pfSense VNFs) to enhance WAN security in the Service Composer UI using drag-and-drop.Optimize LAN/WAN performanceService Composer also supports SR-IOV and QuWAN SD-WAN, which greatly improves the WAN transmission of the QuCPE-3032 that runs QuWAN, while also helping users to enjoy high-speed and secure LAN and WAN network transmission at the same time.Enhanced securityYou can automatically create a firewall network (using QuWAN and pfSense VNFs) to enhance WAN security in the Service Composer UI using drag-and-drop.Run your VM/VNF Directly on QuCPEQNE Network inherits versatile virtual applications from the QNAP QTS system. QuCPE can simultaneously run multiple virtual machines, software containers, and even bespoke user-made virtual machines in Virtualization Station and Container Station, assisting SMBs in improving deployment and management flexibility while streamlining hardware costs.Intel hardware acceleration technologies boost virtual network performanceSpecifically designed for running virtualization applications, the QuCPE-3032 Network Virtualization Premise Equipment adopts multiple Intel hardware acceleration technologies to allow direct hardware access, thus enhancing VM and virtual network transmission performance.DPDK (Data Plane Development Kit)Allows data to bypass the OS Kernel and directly enter user space to offer a double packet transmission rate (Total T/R x L2) and improve overall virtualization application performance.Smart NIC SR-IOV (Single Root I/O Virtualization)By installing an SR-IOV compatible PCIe SmartNIC, you can allocate bandwidth resources from a physical network card directly to VMs. With traffic bypassing the Hypervisor vSwitch, it helps enhance I/O throughout and network efficiency, ensuring reliable VM applications and reduced CPU overheads.Intel QAT (Intel QuickAssist Technology)Offloads computationally-intensive compression and improves IPsec cryptography VPN performance.Smart IT tools for network management efficiencyQNE Network provides comprehensive management features for Smart IT network management.Notification CenterConsolidates QTS system events and alerts, providing a single-app solution for notifications instead of having to configure individual settings in multiple apps. Notifications can be sent through email, SMS, and other communication apps.QuLog CenterCentralizes statistical rankings of error/warning events and access, assisting IT staff in monitoring and responding to potential system risks.Security CenterProvides security management for IT staff, including managing SSL certificates. Other features include automatically detecting history edits to prevent malicious edits.ZabbixZabbix is a third-party solution that automatically detects devices and monitors network status. Zabbix provides user-friendly topology and network reporting, suitable for enterprise network management.Supports third Party Virtual Network FunctionsThe Application Store and VM Marketplace provides multiple free and premium VNF and applications that users can install on demand.
LongProductName - Intel Atom C3558R 4-core 2.4 GHz, 8GB DDR4 2400MHz Non-ECC UDIMM, 8 x RJ-45, 2 x SFP+, 2 x M.2, USB, 285 x 237 x 46 mm
LongSummaryDescription - QNAP QuCPE-3032. Processor manufacturer: Intel, Processor family: Intel Atom®, Processor model: C3558R. Internal memory type: DDR4, Internal memory: 8 GB, Memory clock speed: 2400 MHz. Supported storage drive types: SSD, Supported storage drive interfaces: M.2. Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Fiber optic connector: SFP+, Console port: RJ-45
Manufacturer - QNAP
Memory - ECC - No
Memory - Internal memory - 8 GB
Memory - Internal memory type - DDR4
Memory - Maximum RAM supported - 128 GB
Memory - Memory clock speed - 2400 MHz
Memory - Memory form factor - UDIMM
Memory - Memory slots - 2 x 288pin
MPN - QUCPE-3032-C3558R-8G
Name - QNAP QuCPE-3032-C3558R-8G Intel Atom C3558R 8x2.5GbE RJ45 ports and 2x10GbE SFP+ ports 2xM.2 2280 NVMe slot 60W PS units
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000,2500 Mbit/s
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Packaging content - Cables included - AC, LAN (RJ-45)
Packaging content - Power cables quantity - 1
Packaging content - Rack mount kit - Yes
Ports & interfaces - AC (power) in - Yes
Ports & interfaces - Console port - RJ-45
Ports & interfaces - Ethernet LAN (RJ-45) ports - 8
Ports & interfaces - Fiber optic connector - SFP+
Ports & interfaces - Fiber ports quantity - 2
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB port - Yes
Power - Power consumption (typical) - 60 W
Processor - Number of processors supported - 1
Processor - Processor cache - 8 MB
Processor - Processor cores - 4
Processor - Processor family - Intel Atom®
Processor - Processor frequency - 2.4 GHz
Processor - Processor manufacturer - Intel
Processor - Processor model - C3558R
Processor - Processor threads - 4
Processor special features - Intel® AES New Instructions (Intel® AES-NI) - Yes
ProductName - QuCPE-3032
ShortSummaryDescription - QNAP QuCPE-3032, Intel, Intel Atom®, C3558R, 2.4 GHz, 8 MB, DDR4
Software - Data Plane Development Kit (DPDK) - Yes
Software - PCI-SIG* SR-IOV Capable - Yes
Storage - Number of storage drives supported - 2
Storage - Supported storage drive interfaces - M.2
Storage - Supported storage drive types - SSD
Title - QNAP QuCPE-3032
URL - https://www.qnap.com/en/product/qucpe-3032
WarrantyInfo -
Weight & dimensions - Depth - 237 mm
Weight & dimensions - Height - 46 mm
Weight & dimensions - Weight - 2.17 kg
Weight & dimensions - Width - 285 mm
