Brand - Ricoh
BrandPartCode - PA03710-B001
Category - Scanners
Design - Built-in display - Yes
Design - Product colour - Grey, White
Design - Scanner type - ADF scanner
GTIN - 4939761308444
Input capacity - Auto document feeder (ADF) input capacity - 100 sheets
Logistics data - Cardboard packaging weight - 1.2 kg
Logistics data - Country of origin - Indonesia
Logistics data - Foil packaging weight - 15 g
Logistics data - Glass packaging weight - 0 g
Logistics data - Harmonized System (HS) code - 8471607000
Logistics data - Metal packaging weight - 0 g
Logistics data - Pallet gross length - 121.9 cm
Logistics data - Pallet gross width - 101.6 cm
Logistics data - Pallet height (air) - 114 cm
Logistics data - Pallet height (sea) - 180 cm
Logistics data - Paper packaging weight - 2.4 kg
Logistics data - Plastic packaging weight - 15 g
Logistics data - Polystyrene (EPS/EPP) packaging weight - 200 g
Logistics data - Products per pallet (air) - 24 pc(s)
Logistics data - Products per pallet (sea) - 40 pc(s)
Logistics data - Wood packaging weight - 0 g
LongDesc - fi-7480, Superior A3 format scanning technology distributed to the desktop- Versatile document capturing capability for any size document from A8 to A3, folded A2 and A1 and up to 5.5 meters in length - from plastic to paper, thick to thin, with surface quality variations- Retractable roller mechanism allows for scanning booklets and filled envelopes- A4 landscape at 300 dpi; 80ppm/160ipm, scan mixed batches up to 100 sheets- Uninterrupted scanning: Paper feeding and replenishment during operation- Uninterrupted capture routines: Collect diverse documents into a unified digital file- Compact dimensions: Base footprint only slightly larger than an A4 sheet of paper- Sensitive: Treats delicate documents with utmost care- Equipped with Intelligent Sonic Paper Protection that is based on acoustic sensors- Skew reducer - Independent pick rollers ensure a skewed document will not affect the alignment of following sheets- Integrated backlight LCD and Scanner Central Admin tools for hassle free monitoring and administering- PaperStream IP and PaperStream Capture; developed scanner driver and image enhancement plus batch capture software applicationThe fi-7480 is easy to set up, use and maintain and comes bundled with a user friendly and intuitive scanner driver PaperStream IP along with batch scanning automation and enhancement software PaperStream Capture. A4 landscape scanning speeds in both colour or black and white at up to 300 dpi is 80 pages per minute or 160 images per minute through the 100 page capacity ADF. The fi-7480 can scan a huge variety of material from plastic cards to booklets to even folded A1 in size.Intuitive feeding functionsThe fi-7480 scanner comes with a unique paper protection function that is based on acoustic sensors; iSOP (Intelligent Sonic Paper Protection), iSOP reduces the risk of having documents damaged by sensing the audible noise of paper movements and stopping the feeding of sheets when an irregular noise is encountered.The scanner additionally makes use of an ultrasonic sensor that accurately detects multifeed errors where two or more sheets are fed through the scanner at once plus intelligent multifeed function that is designed for documents that intentionally feature paper attachments of defined sizes or locations such as sticky notes or photos. The scanner can automatically recognise the location of the attachment and will then exclude that zone from triggering alert conditions.Skew Reducer helps ensure straight paper feedingShould you be scanning mixed batches of differing thicknesses of documents then the “skew reducer” eliminates the risk of physical skew being carried over from one sheet in a mixed batch to the next ensuring that each document is captured with the utmost precision and simplicity. Multi-segmented pick rollers that rotate independently ensure that if a document goes through skewed then this will not affect the alignment of the next document.Hassle free monitoring and administeringIntegrated within the operating panel a backlight enhanced LCD shows useful information such as current scanner settings, operating status and a paper counter, in addition the fi-7480 comes with Scanner Central Admin tools that includes functions that system administrators can use to manage the installation and operation of multiple scanners, monitor operation status and update drivers and software from one location. This ability dramatically reduces the cost and work that goes into setting up, operating and maintaining many scanners in an organisation and also in expanding the scanner network to multiple locations.PaperStream IP and PaperStream CaptureThe fi-7460 comes bundled with PaperStream IP, an integrated scanner driver and image enhancement module that is built on TWAIN/ISIS standards offering user friendly operability, intuitive high quality image creation and real time processing that will benefit post scan routines like OCR. PaperStream Capture enhances the document capture process from adjusting scanning settings to performing batch scanning, verifying data and releasing to directories, repositories or subsequent process routines. Users can complete data capture tasks easily with the extremely user-friendly graphical user interface (GUI). Moving scanned batches into a queue for later retrieval is possible as well.Service and SupportA one year Advance Exchange is offered as a standard warranty and this includes online support along with parts/labour and shipping costs. Advance Exchange involves the delivery of a refurbished scanner which replaces the faulty scanner.Service upgrades are available that extends the warranty period from between 1 to 5 years and additionally offers the possibility for items like onsite service with impressive response and repair times, accidental damage cover and remote desktop support.
LongProductName - ADF, 600 x 600 dpi, 2 x CCD, 24 bit, 80 ppm, 160 ipm (200 & 300 DPI), USB 3.0, 7.6 kg
LongSummaryDescription - Ricoh fi-7480. Maximum scan size: 304.8 x 5588 mm, Optical scanning resolution: 600 x 600 DPI, Output colour depth: 24 bit. Scanner type: ADF scanner, Product colour: Grey, White. Sensor type: Dual CCD, Light source: White LED (4x), Scan drivers: ISIS, TWAIN. Auto document feeder (ADF) input capacity: 100 sheets. Maximum ISO A-series paper size: A3, Scanning media types supported: Plastic Card, ISO A-series sizes (A0...A9): A3, A4, A8
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Other features - Background colours - Black, White
Other features - Compliance certificates - RoHS
Other features - Selectable background colour - Yes
Packaging content - AC adapter included - Yes
Packaging content - Bundled software - PaperStream IP, PaperStream Capture, Software Operation Panel, Error Recovery Guide, Scanner Central Admin tools, ScanSnap Manager, Scan to Microsoft SharePoint, ABBYY FineReader, 2D barcode for PaperStream
Packaging content - Cables included - AC
Packaging content - Drivers included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 302 mm
Packaging data - Package height - 330 mm
Packaging data - Package weight - 9.9 kg
Packaging data - Package width - 505 mm
Packaging data - Quantity per pack - 1 pc(s)
Paper handling - Auto Document Feeder (ADF) media weight - 27 - 413 g/m²
Paper handling - ISO A-series sizes (A0...A9) - A3, A4, A8
Paper handling - Maximum ISO A-series paper size - A3
Paper handling - Maximum scan area (ADF) - 304.8 x 431.8 mm
Paper handling - Maximum scan length - 5.588 mm
Paper handling - Maximum scan width - 30.5 cm
Paper handling - Media thickness (min) - 1.4 mm
Paper handling - Minimum scan area (ADF) - 50.8 x 69 mm
Paper handling - Multi feed detection - Yes
Paper handling - Plastic card media weight - 27 - 413 g/m²
Paper handling - Scanning media types supported - Plastic Card
Performance - Light source - White LED (4x)
Performance - Scan drivers - ISIS, TWAIN
Performance - Sensor type - Dual CCD
Ports & interfaces - Socket connector type - C5
Ports & interfaces - Standard interfaces - USB 3.2 Gen 1 (3.1 Gen 1)
Ports & interfaces - USB connector type - USB Type-B
Ports & interfaces - USB port - Yes
Ports & interfaces - USB version - 3.2 Gen 1 (3.1 Gen 1)
Power - Input voltage - 100-240 V
Power - Power consumption (off) - 0.35 W
Power - Power consumption (PowerSave) - 1.4 W
Power - Power consumption (standby) - 0.35 W
Power - Power consumption (typical) - 43 W
Power - Power supply type - AC
ProductName - fi-7480
Scanning - ADF scan speed (b/w, A4) - 80 ppm
Scanning - ADF scan speed (colour, A4) - 80 ppm
Scanning - Black/white scanning colour modes - Grayscale, Monochrome
Scanning - Colour scanning - Yes
Scanning - Duplex ADF scan speed (b/w, A4) - 160 ipm
Scanning - Duplex ADF scan speed (colour, A4) - 160 ipm
Scanning - Duplex scanning - Yes
Scanning - Film scanning - No
Scanning - Maximum scan size - 304.8 x 5588 mm
Scanning - Optical scanning resolution - 600 x 600 DPI
Scanning - Output colour depth - 24 bit
Scanning - Output greyscale depth - 8 bit
Scanning - Output monochrome depth - 1 bit
ShortSummaryDescription - Ricoh fi-7480, 304.8 x 5588 mm, 600 x 600 DPI, 24 bit, 8 bit, 1 bit, 80 ppm
Sustainability - Sustainability certificates - ENERGY STAR
System requirements - Server operating systems supported - Windows Server 2008, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012 R2 x64, Windows Server 2012 x64, Windows Server 2016 x64
System requirements - Windows operating systems supported - Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Professional x64
Title - Ricoh fi-7480 ADF scanner 600 x 600 DPI A3 Grey, White
URL - https://www.pfu-emea.ricoh.com/
WarrantyInfo - 1 year
Weight & dimensions - Depth - 209 mm
Weight & dimensions - Height - 168 mm
Weight & dimensions - Weight - 7.6 kg
Weight & dimensions - Width - 380 mm
