MSI MEG X870E GODLIKE

Name: MSI MEG X870E GODLIKE
Brand: MSI
SKU: 1191105
Price: 1467.73 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 1191105 Product code: 7E48-001R

Can be ordered 10 units Availability: 14 days after order approval

Warranty: 2 years

Compare

Ready for dispatch

02.07.2025

starting from 0 €

Delivery options

Receiving goods at the Dateks office
0.00 €
DPD Pickup Parcel Cabinet
Within 1-2 working days
0.00 €
Parcel terminal
Within 1-2 working days
0.00 €
Post Office
Within 1-2 working days
0.00 €
Omniva parcel machine
Within 1-2 working days
0.00 €
SmartPosti parcel terminal
Within 1-2 working days
0.00 €
Delivery throughout Latvia.
Within 1-2 working days
4.99 €

Main product parameters All parameters

Series: MSI MEG
Plate size: E-ATX
Chipset: AMD X870E
Socket: AM5
Type: DDR5
RAM Slots: 4
Built-in Wi-Fi: Ir
M.2 ports: 7

Basic information

Series : MSI MEG

Plate size E-ATX

The physical size of the motherboard. Dateks.lv offers ATX (full size board), mATX (micro ATX) (a board of reduced size) and miniATX size motherboards. Within the housing of an ATX size computer it is possible to place both ATX and mATX motherboard, however, in the mATX housing it is not possible to place an ATX board.

The ATX board has at least 3 memory slots and at least 5 local slots PCI, which means that a well functioning powerful computer can be built on this board. However, a home or office computer does not need this high number of slots, therefore also microATX will be suitable.

The connector of the power supply unit of the motherboard is the power source socket which are currently of ATX and ATX2.0 standard. ATX is an older standard with a 20pin connector (20 "pins"), and ATX2.0 has 4 additional pins (20+4). The motherboards of ATX standard can operate with a ATX2.0 power supply unit (PSU), however the mother board of ATX2.0 standard requires an ATX2.0 power supply unit.

Form-factor is rather a recommendation. However, prior to buying a mother board you should verify the compatibility of the housing size to the motherboard size and its power supply connector.

Chipset AMD X870E

The chip bus is the most important criterion of selecting the motherboard (the system logic chips or the voltage transformers). The chip bus determines the CPUs, memory ports and other parameters that are supported by the motherboard.

Each chipset is directly related to a certain CPU platform which are divided based upon the family of CPUs or the connection point of the CPU.

For verifying which chip bus is suitable for your CPU, etc. you should ask our managers.

Socket AM5

The CPU socket is an important factor in selecting the board; the CPU board must be exactly compatible with the CPU that you want to install with the board. Irrespective of the fact that the CPU fits the socket of the motherboard also the support of this CPU has to be taken into account. For verifying which CPUs are supported by the selected motherboard you should visit the website of the manufacturer of the motherboard, find the CPU support section of the relevant motherboard and verify that the specification of this particular board provides for the support of the CPU that you have selected.

Random-access memory (RAM)

Type : DDR5

RAM Slots 4

The number of available memory slots indicates the number of memory modules (plates) that can be installed in the motherboard.

Memory support DDR5 5600MHz (9000MHz OC)

The RAM bus determines what type of RAM is supported by the relevant motherboard.

The bus marking contains the memory type DDRII or DDRIII as well as the maximum memory clock frequency that is supported by the mother board. The type of memory is the most important index, memories of different types are physically different, therefore DDRIII memory cannot be connected to the mother board that supports DDRII memory (except the cases when the motherboard supports both types of memory). However the motherboard that support 800Mhz DDRII memory can work with the memory speeds of DDII667 and DDRII533. The mother board with the memory bus speed below the speed of the memory module will be able to operate as fast as the specified bus speed only, i.e. if the memory bus of the motherboard is DDRII667 and the memory DDRII800 is installed it will operate with the speed of DDRII667.

Graphics card

VGA Port PCI-EXPRESS

VGA port or the video card plug. The VGA port must comply with the specification of the video card port you have selected. Older video cards have an AGP port, new cards are manufacturer with a PCI-EXPRESS (PCI-X) port.AGP and PCI-Xpress video cards are not mutually compatible. Prior to buying the motherboard you should verify the compliance of the video card port of both the motherboard and the video card.

Integrated graphics Only with iGPU-ready APU

The parameter that determines whether a video card has been integrated with the motherboard. An integrated video card is suitable for working with the office software, Internet, watching films and playing simple games. If you wish to use graphics applications, play 3D games and watch 3D animations you would need an additional video card.

An integrated video card uses a fraction of the memory included in the mother board, therefore, if your motherboard has 1Gb memory and in the settings of the video card of the mother board it is stated that it takes 256mb the operating system will display the available memory volume of approximately 700 Mb.
Prior to buying a motherboard with a built-in video card you should verify whether it has an additional video card port for further upgrades if these are required

Ports and equipment

D-Sub : 0

DisplayPort : 0

DVI : 0

HDMI : 0

Integrated sound card : Realtek ALC4082

PCI Ports 0

PCI ports present the most popular way of supplementing the computer functions with additional cards (sound, network, communications, video surveillance, etc.). Newer boards, thanks to the PCI-Express standard, have a small number of PCI extension ports, therefore, prior to buying the motherboard you should verify if the number of PCI ports allows the connection of all the PCI cards you need.

Wireless connections

Built-in Bluetooth : Ir

Built-in Wi-Fi : Ir

External ports

External USB 2.0 : Nav

External USB Type-C (USB 3.2 Gen2) : 5

External USB Type-C (USB 4.0) : 2

External USB 3.0 (USB 3.2 Gen1) : 0

External USB 3.1 (USB 3.2 Gen2) : Eight Core

Internal ports

Internal A-RGB 5V (3-pin) : 2

Internal RGB 12V (4-pin) : 0

Internal USB 2.0 : 2

Internal USB 3.0 : 2

Internal USB Type-C : 2

M.2 ports : 7

SATA3 ports : 4

More detailed specification

Additional information in manufacturers website MSI MEG X870E GODLIKE

Accessories included -
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Audio port Input/Output connectors - 2
BIOS -
BIOS - ACPI version - 6.5
BIOS - BIOS memory size - 256 Mbit
BIOS - BIOS type - UEFI AMI
BIOS - System Management BIOS (SMBIOS) version - 3.7
Bluetooth Interface - Yes
Brand - MSI
BrandPartCode - MEG X870E GODLIKE
Category - Motherboards
category - PC Components|Mainboards|AMD Mainboards|Socket AM5
Category 1 - Mainboards & Zubehör
Category 2 - Mainboards - AMD
Category Code - MBA
Chipset - AMD X870E
Chipset manufacturer - AMD
Chipset type - AMD X870E
code - 7E48-001R
Code - MEG X870E GODLIKE
COM connector / port - No
CPU socket - Socket AM5
Description - MEG X870E GODLIKE Built for unparalleled performance on the AMD X870E chipset and Ryzen 9000 processors, the MEG X870E GODLIKE equips true Wi-Fi 7, 10G Super LAN, high-speed USB4, Supplemental PCIe Power, and the revolutionary Dynamic Dashboard III. Dominate tournaments and immerse in extreme gaming with the MEG X870E GODLIKE. - Supports AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors - Supports DDR5 Memory, Dual Channel DDR5 9000+MT/s (OC) - Dynamic Dashboard III: A 3.99-inch LCD for real-time hardware monitoring, troubleshooting, BIOS updates, and personalized display options, enhancing the overall user experience. - M.2 XPANDER-Z SLIDER GEN5: The one-slot-thick M.2 expansion card features dual high-speed Gen5 M.2 slots, and the EZ Slide design makes SSD upgrades effortless. - Ultra Performance: 24+2+1 Duet Rail Power System, 110A SPS, OC Engine, dual 8-pin CPU power connectors, Core Boost, Memory Boost, 10-layer PCB made by 2oz thickened copper and server-grade level material. - Frozr Guard: Wavy fin design, Direct Touch Cross Heat-pipe, MOSFET Baseplate, 9W/mK thermal pads, Double-Sided M.2 Shield Frozr and Frozr AI software ensure the utmost performance with low temperature. - EZ DIY: EZ Link, EZ PCIe Release, EZ Magnetic M.2 Shield Frozr II, EZ M.2 Clip II and EZ Antenna. - Ultra Connect: 10G LAN + 5G LAN, Full-speed Wi-Fi 7 Solution and USB4 - The latest solution for professional and multimedia use, delivering secure, stable, and high-speed networking and data transmission. - Lightning Fast Game Experience: PCIe 5.0 slots, Lightning Gen 5 x4 M.2, Front USB 20G with 60W USB Power Delivery. - Audio Boost 5 HD: Ultimate audio solution with latest premium ALC4082 audio processor combining ESS audio DAC and amplifier deliver the breathtaking experience.
Description - Płyta główna MEG X870E Godlike Obsługuje procesory stacjonarne AMD Ryzen serii 9000 / 8000 / 7000 Obsługuje pamięć DDR5, dwukanałową pamięć DDR5 9000+MT/s (OC) Dynamic Dashboard III: 3,99-calowy wyświetlacz LCD do monitorowania sprzętu w czasie rzeczywistym, rozwiązywania problemów, aktualizacji BIOS-u i spersonalizowanych opcji wyświetlania, co poprawia ogólne wrażenia użytkownika. M.2 XPANDER-Z SLIDER GEN5: Karta rozszerzeń M.2 o grubości jednego gniazda ma dwa szybkie gniazda Gen5 M.2, a konstrukcja EZ Slide sprawia, że modernizacja dysków SSD jest bezproblemowa. Ultra wydajność: 24+2+1 Duet Rail Power System, 110 A SPS, OC Engine, dwa 8-pinowe złącza zasilania procesora, Core Boost, Memory Boost, 10-warstwowa płytka PCB wykonana z 2-uncjowej pogrubionej miedzi i materiału klasy serwerowej. Frozr Guard: falista konstrukcja żeber, rurka cieplna Direct Touch Cross Heat-pipe, płyta bazowa MOSFET, podkładki termiczne 9 W/mK, dwustronna osłona M.2 Frozr i oprogramowanie Frozr AI zapewniają najwyższą wydajność przy niskiej temperaturze. EZ DIY: EZ Link, EZ PCIe Release, EZ Magnetic M.2 Shield Frozr II, EZ M.2 Clip II i EZ Antenna. Ultra Connect: 10G LAN + 5G LAN, rozwiązanie Wi-Fi 7 o pełnej prędkości i USB4 najnowsze rozwiązanie do zastosowań profesjonalnych i multimedialnych, zapewniające bezpieczne, stabilne i szybkie sieciowanie oraz transmisję danych. Błyskawiczne wrażenia z gry: gniazda PCIe 5.0, Lightning Gen 5 x4 M.2, przednie USB 20G z zasilaniem USB 60 W. Audio Boost 5 HD: najlepsze rozwiązanie audio z najnowszym procesorem audio klasy premium ALC4082 łączącym przetwornik cyfrowo-analogowy ESS i wzmacniacz, które zapewniają zapierające dech w piersiach wrażenia.
Designation - CE+WEEE
Detailed data on disk/drive interfaces - 7x M.2 Źródło M.2_1 (z procesora) obsługuje do PCIe 5.0 x4, obsługuje urządzenia 2280/2260 Źródło M.2_2 (z procesora) obsługuje do PCIe 5.0 x4, obsługuje urządzenia 2280/2260 Źródło M.2_3 (z chipsetu) obsługuje do PCIe 4.0 x4, obsługuje urządzenia 22110/2280 Źródło M.2_4 (z chipsetu) obsługuje do PCIe 4.0 x2, obsługuje urządzenia 2280/2260 Źródło M.2_5 (z chipsetu) obsługuje do PCIe 4.0 x4, obsługuje urządzenia 2280/2260 4x SATA 6G Źródło M.2_1 (przez M.2 XPANDER-Z SLIDER GEN5) obsługuje do PCIe 5.0 x4, obsługuje 2280 urządzeń Źródło M.2_2 (za pośrednictwem M.2 XPANDER-Z SLIDER GEN5) obsługuje do PCIe 5.0 x4, obsługuje 2280 urządzeń M.2_1:
Obsługuje do PCIe 5.0 x4 (dla procesorów Ryzen serii 9000/7000)
Obsługuje do PCIe 4.0 x4 (dla procesorów Ryzen serii 8000)
M.2_2:
Obsługuje do PCIe 5.0 x4 (dla procesorów Ryzen serii 9000/7000)
Obsługuje do PCIe 4.0 x4 (dla procesorów Ryzen serii 8700/8600/8400)
Gniazdo M2_2 będzie niedostępne podczas korzystania z procesorów Ryzen serii 8500/8300.
M2_4:
Gniazdo PCI_E3 będzie działać z prędkością x2 podczas instalowania urządzenia w gnieździe M2_4. Możesz przełączyć gniazdo PCI_E3 na x4 w BIOS-ie, ale spowoduje to wyłączenie gniazda M2_4.
* Obsługuje wbudowane 5 gniazd M.2 i dodatkowe 2 gniazda M.2 za pośrednictwem karty M.2.
dimension depth - 130 mm
dimension height - 360 mm
Dimensions - 304.8 x 277 mm
dimension weight - 6300 g
dimension width - 380 mm
EAN - 4711377276221
ean - 4711377276221
Expansion slots - 1 x PCIe 5.0 x 16
Expansion slots - 1st M.2 highest PCI Express generation - 5.0
Expansion slots - 1st M.2 largest key size - 2280
Expansion slots - 2nd M.2 highest PCI Express generation - 5.0
Expansion slots - 2nd M.2 largest key size - 2280
Expansion slots - 3rd M.2 highest PCI Express generation - 4.0
Expansion slots - 3rd M.2 largest key size - 22110
Expansion slots - 4th M.2 highest PCI Express generation - 4.0
Expansion slots - 4th M.2 largest key size - 2280
Expansion slots - 5th M.2 highest PCI Express generation - 4.0
Expansion slots - 5th M.2 largest key size - 2280
Expansion slots - Number of M.2 (M) slots - 5
Expansion slots - PCI Express x16 (Gen 3.x) slots - 1
Expansion slots - PCI Express x16 (Gen 4.x) slots - 1
Expansion slots - PCI Express x16 (Gen 5.x) slots - 1
External connectors - 1 x Flash BIOS Button
External connectors - 1 x MIC (front)
External connectors - 1 x Przycisk Clear CMOS
External connectors - 1 x S/PDIF
External connectors - 1 x Smart Button
External connectors - 2 x RJ-45
External connectors - 2 x SMA
External connectors - 2 x USB 3.2 Gen 2 Type-C
External connectors - 8 x USB 3.1
Features - Audio output channels - 7.1 channels
Features - Component for - PC
Features - Motherboard chipset - AMD X870E
Features - Motherboard chipset family - AMD
Features - Motherboard form factor - Extended ATX
Features - PC health monitoring - CPU, Fan, Temperature, Voltage
Features - Product colour - Black
Features - Windows operating systems supported - Windows 11 x64
FireWire (IEEE 1394) - No
Form factor - E-ATX
Form Factor - EATX
Frequency speed - 4800/6400/8400/9000 MHz
Full Description Line - AMD X870E|SAM5|EATX|DDR5|9000/8400/6400/4800 MHz|Memory slots 4|1xPCI-Express 1x|2xPCI-Express 16x|7xM.2|1xAudio-In|1xAudio-Out|4xUSB 2.0|4xUSB 3.2|4xUSB-C|1xOptical S/PDIF|2xRJ45|2xAudio port|SATA|USB-C|USB 2.0|USB 3.2|Bluetooth|WiFi|Video Depending on CPU|Audio|LAN 10 Gigabit|RAID SATA 0, 1, 10; NVMe 0, 1, 10|TPM Header
Graphics - 2x Type-C DisplayPort
Port USB4, obsługujący DisplayPort 1.4 z HBR3 przez USB Type-C, maksymalna rozdzielczość 4K@60Hz
Graphics - On-board graphics card - No
GTIN - 4711377268721
GTIN - 4711377276221
guarantee - 36
guarantee_type - normal
Integrated audio - Yes
Integrated CPU - No
Integrated LAN - 10 Gigabit
Integrated video - Depending on CPU
Internal I/O - ATX Power connector (24-pin) - Yes
Internal I/O - CPU fan connector - Yes
Internal I/O - EPS power connector (8-pin) - Yes
Internal I/O - Number of SATA III connectors - 4
Internal I/O - Total number of SATA connectors - 4
Internal I/O - USB 2.0 connectors - 4
Internal I/O - USB 3.2 Gen 1 (3.1 Gen 1) connectors - 4
Internal I/O - USB 3.2 Gen 2 (3.1 Gen 2) connectors - 2
Internal I/O > Number of SATA connectors - 4
Internal I/O > Supported hard disk drive interfaces - SATA, M.2
Link - https://www.msi.com/Motherboard/MEG-X870E-GODLIKE
LongDesc - Built for unparalleled performance on the AMD X870E chipset and Ryzen 9000 processors, the MEG X870E GODLIKE equips true Wi-Fi 7, 10G Super LAN, high-speed USB4, Supplemental PCIe Power, and the revolutionary Dynamic Dashboard III. Dominate tournaments and immerse in extreme gaming with the MEG X870E GODLIKE.
LongProductName - AMD X870E, 4x DDR5, 9000 (OC) MT/s, 4x SATA, 2x Type-C DisplayPort, Wi-Fi 7, E-ATX
LongSummaryDescription - MSI MEG X870E GODLIKE. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series. Supported memory types: DDR5-SDRAM, Maximum internal memory: 256 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Ethernet interface type: 5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E.... Component for: PC, Motherboard form factor: Extended ATX, Motherboard chipset family: AMD
LPT connector / port - No
M.2 Expansion slots - 7
Manufacturer - MSI
Max. number of ATA devices - 0
Max. number of SATA devices - 4
Max memory size - 256 GB
Memory - ECC сompatibility - Non-ECC
Memory - Maximum internal memory - 256 GB
Memory - Memory channels - Dual-channel
Memory - Memory slots type - DIMM
Memory - Number of memory slots - 4
Memory - Supported memory clock speed (max) - 9000 MHz
Memory - Supported memory clock speeds - 4800,5600 MHz
Memory - Supported memory types - DDR5-SDRAM
Memory bus frequency - 4800 MHz
Memory bus frequency - 5600 MHz
Memory slots - 4
Memory type - DDR5
Memory type - DDR5
Model - MEG X870E GODLIKE
Model - MEG X870E Godlike
MPN - 7E48-001R
name - MEG X870E GODLIKE AM5 4DDR5 ATX
Name - MSI MEG X870E GODLIKE (AM5) (D)
name - MSI MEG X870E Godlike Mainboard, Sockel AM5, AMD X870E, E-ATX, DDR5
Name - MSI MEG X870E GODLIKE | Processor family AMD | Processor socket AM5 | Supported hard disk drive interfaces SATA, M.2 | Number of SATA connectors 4
Network - Bluetooth - Yes
Network - Bluetooth version - 5.4
Network - Ethernet interface type - 5 Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - Top Wi-Fi standard - Wi-Fi 7 (802.11be)
Network - Wi-Fi - Yes
Network - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Network interface - Bluetooth
Network interface - Wi-Fi 7 Obsługuje MU-MIMO TX/RX, 2,4 GHz/ 5 GHz/ 6 GHz* (320 MHz) do 5,8 Gb/s Obsługuje 802.11 a/ b/ g/ n/ ac/ ax/ be Obsługuje Bluetooth 5.4, MLO, 4KQAM
Network interface - Wi-Fi 802.11a/b/g/n/ac/ax/be
Number of DDR5 slots - 4
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports - 0
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports - 0
Onboard connectors - 1 x 4pin CPU fan
Onboard connectors - 1 x Chassis intrusion header
Onboard connectors - 1 x Front panel audio header
Onboard connectors - 2 x System panel header
Onboard connectors - 2 x USB C
Onboard connectors - 4 x USB 2.0/1.1
Onboard connectors - 4 x USB 3.0
Optical S/PDIF Input/Output connectors - 1
Other information -
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 280.00 mm
Package features > Gross height (mm) - 70.00 mm
Package features > Gross width (mm) - 272.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Paper/Pasteboard - 359.00 g
Package features > Plastic (No PET) - 90.00 g
Package features > Tare weight (kg) - 0.45 kg
Package features > TI weight (kg) - 0.02 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
PCI-Express 1x Expansion slots - 1
PCI-Express 16x Expansion slots - 2
Processor - Compatible processor series - AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor - Processor manufacturer - AMD
Processor - Processor socket - Socket AM5
Processor - Supported processor sockets - Socket AM5
Processor > Processor family - AMD
Processor > Processor socket - AM5
Processor family - AMD Ryzen
producer - MSI
ProductName - MEG X870E GODLIKE
Product Net Weight - 0.7 kg
RAID - SATA 0, 1, 10; NVMe 0, 1, 10
RAID - Yes
Rear panel I/O ports - Ethernet LAN (RJ-45) ports - 1
Rear panel I/O ports - HDMI version - 2.1
Rear panel I/O ports - Microphone in - Yes
Rear panel I/O ports - S/PDIF out port - Yes
Rear panel I/O ports - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 8
Rear panel I/O ports - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 5
Rear panel I/O ports - USB4 Gen 2x2 ports quantity - 2
RJ45 Input/Output connectors - 2
SATA Interface - Yes
Shipping Box Depth Shipping/Package Box Dimensions - 48 cm
Shipping Box Height Shipping/Package Box Dimensions - 46.2 cm
Shipping Box Weight Shipping/Package Box Dimensions - 15 kg
Shipping Box Width Shipping/Package Box Dimensions - 37 cm
ShortSummaryDescription - MSI MEG X870E GODLIKE, AMD, Socket AM5, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series, Socket AM5, DDR5-SDRAM, 256 GB
Socket - SAM5
Software -
Sound card - Kodek Realtek ALC4082 + ESS9219Q Combo DAC/HPA 7.1-kanałowy dźwięk USB o wysokiej wydajności Obsługuje wyjście S/PDIF Obsługuje odtwarzanie do 32-bitów/384 kHz na panelu przednim
Special functions -
Storage controllers - Number of HDDs supported - 4
Storage controllers - Number of storage drives supported - 9
Storage controllers - RAID levels - 0, 1, 10
Storage controllers - RAID support - Yes
Storage controllers - Supported storage drive interfaces - M.2, SATA III
Storage controllers - Supported storage drive types - HDD & SSD
Supported operating systems - None
Technical details > Gross weight - 2.12 kg
Technical details > Net weight - 1.67 kg
Technical details > Producer - MSI
Technical details > Producer product name - MEG X870E GODLIKE
Title - MSI MEG X870E GODLIKE motherboard AMD X870E Socket AM5 Extended ATX
TPM - Header
Unit Box Height - 0.131
Unit Box Length - 0.382
Unit Box Width - 0.362
Unit Calculated Volume - 0.04103 cubm
Unit Calculated Weight - 7.5 kg
Units per Shipping Box - 2
URL - https://www.msi.com/Motherboard/MEG-X870E-GODLIKE
USB-C Input/Output connectors - 4
USB-C Interface - Yes
USB 2.0 Input/Output connectors - 4
USB 2.0 Interface - Yes
USB 3.2 Input/Output connectors - 4
USB 3.2 Interface - Yes
USB ports at back panel - 15
USB ports on motherboard - 0
Vendor Homepage - www.msi.com/Motherboard/MEG-X870E-GODLIKE
vendpn - MEG X870E GODLIKE
Warranty - 24/12L months
Warranty - 36
Warranty - 36 month(s)
WarrantyInfo -
Weight - 6.42
Weight & dimensions - Depth - 277 mm
Weight & dimensions - Width - 304.8 mm
WiFi Interface - Yes
