Accessories included -
ARTIKEL1 - RACK PDU 2G METERED ZEROU
ARTIKEL2 - 22.0KW 17.3KW 230V C13 C19
Brand - APC
BrandPartCode - AP8886
Cable length - 1.83 m
Cable length, m - 1.83
Category - Power Distribution Units (PDUs)
Certification - EN 55022 Class A, EN 55024, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Class A, ICES-003, VCCI Class A, VDE
Color - Black
Depth, mm - 51
Description -
Description - APC RACK PDU 2G, METERED, ZEROU, 22.0KW(32A), 230V, (30) C13 & (12) C19
Design - Mounting - Vertical
Design - PDU types - Metered
Design - Product colour - Black
Design - Rack capacity - 0U
dimension depth - 2060 mm
dimension height - 115 mm
Dimensions - 5,6 x 5,1 x 182,9 cm
dimension weight - 9800 g
dimension width - 170 mm
ean - 731304289937
EANCode - 0731304289937
Features - Cable length - 1.83 m
Features - Certification - EN 55022 A,EN 55024, EN 61000-3-2, EN 61000-3-3, FCC 15 A, ICES-003, VCCI A, VDE
REACH: No SVHCs
Features - LED indicators - Yes
Gewicht - 23
GRUPPE1 - Power Protection
GRUPPE2 - Power Product Cpnt
GTIN - 0731304289937
GTIN - 731304289937
guarantee - 24
guarantee_type - external
Height - 170.000000
Height, mm - 1829
HERSTELLER - APC
HSTNUMMER - AP8886
Input connection - IEC 309 32A 3P+N+E
Input current, A - 32
Input frequency, Hz - 50/60
Length - 120.000000
LongDesc - APC Metered Rack Power Distribution Units (PDUs) provide active metering to enable energy optimization and circuit protection. User-defined alarm thresholds mitigate risk with real-time local and remote alerts to warn of potential circuit overloads. Metered Rack PDUs provide power utilization data to allow Data Center Managers to make informed decisions on load balancing and right sizing IT environments to lower total cost of ownership. Metered Rack PDUs include real power monitoring, a temperature/humidity sensor port, locking IEC receptacles, and ultra low profile circuit breakers. Users can access and configure Metered Rack PDUs through secure Web, SNMP, or Telnet Interfaces which are complimented by APC Centralized Management platforms using InfraStruxure Central, Operations, Capacity, and Energy Efficiency.Includes: Installation guide, Rack Mounting brackets, Safety guide, Serial configuration cable
LongProductName - Rack PDU 2G, Metered, ZeroU, 22.0kW(32A) 17.3kW(24A), 230V, (30) C13 & (12) C19
LongSummaryDescription - APC AP8886. PDU types: Metered, Rack capacity: 0U, Mounting: Vertical. AC outlets quantity: 42 AC outlet(s), AC outlet types: C13 coupler, C19 coupler, Power plug: IEC309. Cable length: 1.83 m, Certification: EN 55022 A,EN 55024, EN 61000-3-2, EN 61000-3-3, FCC 15 A, ICES-003, VCCI A, VDE REACH: No SVHCs. Monitoring: Current, Power, Voltage. Nominal input voltage: 400 V, Maximum current: 32 A, AC input frequency: 50 - 60 Hz
Management features - Monitoring - Current, Power, Voltage
Manufacturer - APC
ManufacturerPartNumber - AP8886
Mounting - Rack
name - Power strip AP8886 Rack PDU 2G Metered 0U 22kW/32A 30c13 12c19
No. of C13 sockets - 30
No. of C19 sockets - 12
Nominal input voltage, V - 400V 3PH
Nominal output voltage, V - 230
Operating relative humidity range, % - 5 - 95
Operating temperature range (T-T), °C - -5 - 45
Operational conditions - Non-operating altitude - 0 - 15000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 55 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -25 - 65 °C
Other features -
Output interface - (30) IEC 320 C13,
(12) IEC 320 C19
Packaging data - Package dimensions (WxDxH) - 170 x 112 x 2050 mm
Packaging data - Package weight - 11.6 kg
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 42 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - Output connections - 30 x IEC 320 C13
12 x IEC 320 C19
Ports & interfaces - Power plug - IEC309
Power - AC input frequency - 50 - 60 Hz
Power - Load capacity - 22080 VA
Power - Maximum current - 32 A
Power - Maximum input current per phase - 32 A
Power - Maximum power - 22000 W
Power - Nominal input voltage - 400 V
Power - Nominal output voltage - 230 V
Power - Power protection features - Overload
producer - APC
ProductName - AP8886
Rack dimensions - 0U
ShortSummaryDescription - APC AP8886, Metered, 0U, Vertical, Black, 42 AC outlet(s), C13 coupler, C19 coupler
Stck_Kart - 1
Stck_Pal - 1
Storage temperature range (T-T), °C - -25 - 65
Storno - Y
Technical details - Sustainability certificates - RoHS
Title - APC AP8886 power distribution unit (PDU) 42 AC outlet(s) 0U Black
URL - https://www.apc.com/products/resource/include/techspec_index.cfm?base_sku=AP8886
vendpn - AP8886
WarrantyInfo - 2 years
Weight - 8.72 kg
Weight - 9.500000
Weight & dimensions - Dimensions (WxDxH) - 56 x 51 x 1829 mm
Weight & dimensions - Weight - 8.72 kg
Weight, kg - 8.72
Width - 2005.000000
Width, mm - 56
