Brand - ARCTIC
BrandPartCode - ACFRE00158A
Category - Computer Cooling Systems
category_en - Computers & Components > Computer components > Cooling systems
category_lv - Datortehnika > Datoru komponentes > Dzesēšanas sistēmas
category_ru - Datortehnika > Datoru komponentes > Dzesēšanas sistēmas
description_en - The ARCTIC Freezer 4U-SP5 cooler (model ACFRE00158A) is designed for effective cooling of processors with an SP5 socket, ensuring reliable operation of high-performance systems.
Technical Specifications: Cooling Type: Air
Socket: SP5
Compatibility: AMD
Maximum Thermal Design Power (TDP): 360 W
Radiator Material: Aluminum with 10 copper heat pipes
Cooler Dimensions: 124 x 147 x 145 mm
Fan Dimensions: 120 mm
Number of Fans: 2
Bearing Type: Ball Bearing
Speed Control: PWM
Fan Speed: 300–3300 RPM
Airflow: 81.04 CFM
Noise Level: up to 45.3 dBa
Cable Length: 400 mm
Operating Voltage: 12 V DC
Connector Type: 4-pin
Power Consumption: 1.44 W
description_lv - ARCTIC Freezer 4U-SP5 dzesētājs (modelis ACFRE00158A) ir paredzēts efektīvai procesora dzesēšanai ar SP5 ligzdu, nodrošinot uzticamu darbību augstas veiktspējas sistēmās.
Tehniskās specifikācijas: Dzesēšanas veids: Gaisa
Ligzda: SP5
Saderība: AMD
Maksimālā siltuma izkliede (TDP): 360 W
Radiatora materiāls: Alumīnijs ar 10 vara siltuma caurulēm
Dzesētāja izmēri: 124 x 147 x 145 mm
Ventilatoru izmēri: 120 mm
Ventilatoru skaits: 2
Gultņa tips: Lodīšu gultnis
Ātruma regulēšana: PWM
Griešanās ātrums: 300–3300 apgr./min
Gaisa plūsma: 81,04 CFM
Troksnis līmenis: līdz 45,3 dBa
Kabeļa garums: 400 mm
Barošanas spriegums: 12 V DC
Savienojuma tips: 4-pin
Patērētā jauda: 1,44 W
description_ru - Кулер ARCTIC Freezer 4U-SP5 (модель ACFRE00158A) предназначен для эффективного охлаждения процессоров с сокетом SP5, обеспечивая надежную работу высокопроизводительных систем.
Технические характеристики: Тип охлаждения: Воздушное
Сокет: SP5
Совместимость: AMD
Максимальное тепловыделение процессора (TDP): 360 Вт
Материал радиатора: Алюминий с 10 медными тепловыми трубками
Размеры кулера: 124 x 147 x 145 мм
Размеры вентиляторов: 120 мм
Количество вентиляторов: 2
Тип подшипника: Кульковый
Регулировка оборотов: PWM
Скорость вращения вентиляторов: 300–3300 об/мин
Воздушный поток: 81,04 CFM
Уровень шума: до 45,3 дБа
Длина кабеля: 400 мм
Напряжение питания: 12 В DC
Тип подключения: 4-pin
Потребляемая мощность: 1,44 Вт
Design - Fan connector - 4-pin
Design - Fins material - Aluminium
Design - Number of fans - 2 fan(s)
Design - Number of fins - 62
Design - Number of heat pipes - 10
Design - Product colour - Aluminium, Black
Design - Rack capacity - 4U
EAN - 4895213704656
gross_weight - 0.45 kg
GTIN - 0840033402422
GTIN - 840033402422
GTIN - 4895213704656
LongDesc - Efficient, reliable, durable and quiet – the demands on server cooling are high. ARCTIC has developed specialised solutions for continuous operation that ensure the reliable performance of servers and workstations. Our fans deliver high performance and set new standards in energy efficiency.
LongProductName - AMD, 4U, 300-3300 RPM, 2x 120 mm PWM, 45.3 dBA, 124 x 147 x 145 mm, 1512 g
LongSummaryDescription - ARCTIC Freezer 4U-SP5 - 4U Server Cooler for AMD SP5. Type: Air cooler, Fan diameter: 12 cm, Airflow: 137.69 m³/h, Bearing type: Dual ball bearing. Width: 147 mm, Depth: 124 mm, Height: 145 mm. Product colour: Aluminium, Black
Model - 4U-SP5
Packaging content - Package type - Box
Performance - Airflow - 137.69 m³/h
Performance - Bearing type - Dual ball bearing
Performance - Fan diameter - 12 cm
Performance - Fan noise level (max) - 45.3 dB
Performance - Fan speed (max) - 3300 RPM
Performance - Fan speed (min) - 300 RPM
Performance - Fan static pressure - 4.35 mmH2O
Performance - Maximum airflow - 81.04 cfm
Performance - Operating temperature (T-T) - 0 - 40 °C
Performance - Suitable location - Processor
Performance - Supported processor sockets - Socket SP5
Performance - Type - Air cooler
Power - Fan current - 0.29 A
Power - Fan voltage - 12 V
Power - Starting voltage - 3.1 V
Power - Thermal Design Power (TDP) - 360 W
Producer - Arctic
ProductName - Freezer 4U-SP5 - 4U Server Cooler for AMD SP5
ShortSummaryDescription - ARCTIC Freezer 4U-SP5 - 4U Server Cooler for AMD SP5, Air cooler, 12 cm, 137.69 m³/h, Aluminium, Black
Title - ARCTIC Freezer 4U-SP5 - 4U Server Cooler for AMD SP5
title_en - Arctic 4U-SP5 CPU Cooler
title_lv - Arctic 4U-SP5 CPU Dzesētājs
title_ru - Arctic 4U-SP5 CPU Кулер
URL - https://www.arctic.de/en/Freezer-4U-SP5/ACFRE00158A
WarrantyInfo -
weight - 0.35 kg
Weight & dimensions - Cable length - 0.2 m
Weight & dimensions - Depth - 124 mm
Weight & dimensions - Heat pipes diameter - 6 mm
Weight & dimensions - Height - 145 mm
Weight & dimensions - Package depth - 206 mm
Weight & dimensions - Package height - 141 mm
Weight & dimensions - Package weight - 1.56 kg
Weight & dimensions - Package width - 160 mm
Weight & dimensions - Weight - 1.51 kg
Weight & dimensions - Width - 147 mm
