Accessories included -
ARTIKEL1 - ST45 V3 (4C) AMD EPYC 4124P 16G
ARTIKEL2 - 2X960GB MICRON 5400 PRO SSD
Battery backup - No
Brand - Lenovo
BrandPartCode - 7DH5A007EA
Breite - 0
Category - Servers
Chipset type - AMD PROM21 Chipset: PRO-665
Color - Black
Controller - other information - Onboard 6 Gb SATA controller, supporting AHCI mode
CPU - other information - AMD EPYC 4124P
CPU frequency - 3.8 GHz
CPU model - 4124P
CPU series - AMD Epyc
Depth - 316 mm
Description - Serwer wieżowy jednogniazdowy Lenovo ThinkSystem ST45 V3 to podstawowy serwer idealny dla małych firm, biur domowych, handlu detalicznego, instytucji edukacyjnych oraz oddziałów firm. Serwer oparty jest na procesorze AMD EPYC z serii 4004.
Design - Chassis type - Tower
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 420 mm
dimension height - 535 mm
dimension weight - 8400 g
dimension width - 280 mm
Disk controller - SAS
Disk controller - SATA
ean - ABEAN-RS71734
EANCode - 0889488787319
Expansion slots - 1 x PCIe 3.0 x 1
Expansion slots - 1 x PCIe 3.0 x 16
Expansion slots - PCI Express x1 (Gen 3.x) slots - 1
Expansion slots - PCI Express x16 (Gen 3.x) slots - 1
Form factor (width) - 3,5'' (LFF)
Gewicht - 8.55
Graphics -
GRUPPE1 - Computer Systems
GRUPPE2 - Server
GTIN - 0889488787319
GTIN - 889488787319
GTIN - 5054444665078
guarantee - 36
guarantee_type - external
Height - 376 mm
HERSTELLER - LENOVO
Hoehe - 0
Hot-plug fans support - No
Hot-plug power supply support - No
Hot-swapping support - No
Housing - Tower
HSTNUMMER - 7DH5A007EA
I/O connectors - 1 x Audio out
I/O connectors - 1 x HDMI
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 3.2 Type-C Gen 1
I/O connectors - 2 x 3,5 mm minijack
I/O connectors - 2 x DisplayPort
I/O connectors - 2 x USB 3.2 Type-A Gen 1
I/O connectors - 2 x USB 3.2 Type-A Gen 2
I/O connectors - 4 x USB 2.0
Internal backup device support - No
Kind of memory - ECC
Laenge - 0
LongDesc - The Lenovo ThinkSystem ST45 V3 single-socket tower server is an entry level server ideal for small businesses, home offices, retail, educational institutions and branch offices. The server is based on the AMD EPYC 4004 Series processor (formerly codenamed "Raphael").This product guide provides essential presales information to understand the ThinkSystem ST45 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the ST45 V3 and consider its use in IT solutions.
LongProductName - AMD EPYC 4124P (16MB Cache, 3.8GHz), 16GB DDR5-SDRAM (5200MHz), 1920GB SSD, LAN (Realtek RTL8111FP), 500W, No OS
LongSummaryDescription - Lenovo ThinkSystem ST45 V3. Processor family: AMD EPYC, Processor frequency: 3.8 GHz, Processor model: 4124P. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM, Memory layout (slots x size): 1 x 16 GB. Total storage capacity: 1.92 TB. Ethernet LAN. Power supply: 500 W. Chassis type: Tower
Max. number of disks after server expansion - 4
Max. number of disks in current configuration - 2
Max. number of power supplies - 1
Max memory size - 64 GB
Max supported number of processors - 1
Memory - ECC - Yes
Memory - Internal memory - 16 GB
Memory - Internal memory type - DDR5-SDRAM
Memory - Maximum internal memory - 64 GB
Memory - Memory clock speed - 5200 MHz
Memory - Memory layout (slots x size) - 1 x 16 GB
Memory - Memory slots - 2x DIMM
Memory frequency - 5200 MHz
Memory type - DDR5
Model - ThinkSystem ST45 v3
Motherboard -
name - Server ThinkSystem ST45v3 AMD EPYC 4124P 2x960 GB Micron 7DH5A007EA
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - LAN controller - Realtek RTL8111FP
Network card - other information - 1x 1GbE Embedded (Realtek RTL8111FP)
Network interface - 1 x 10/100/1000 Mbit/s
Number of available memory slots - 1
Number of cores - 4C
Number of CPUs installed - 1
Number of fans - 3
Number of HDDs installed - 2
Number of memory slots used - 1
Number of power supplies installed - 1
Operational conditions - Operating altitude - 0 - 3050 m
Operational conditions - Operating relative humidity (H-H) - 8 - 80%
Operational conditions - Operating temperature (T-T) - 10 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 8 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Optical disk drive - None
Performance - Trusted Platform Module (TPM) - Yes
Performance - Trusted Platform Module (TPM) version - 2.0
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Power cables quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Power - Power supply - 500 W
Power - Power supply input voltage - 115 - 230 V
Power - Redundant power supply (RPS) support - No
Power supply output current - 500 W
Processor - Memory types supported by processor - DDR5-SDRAM
Processor - Number of processors installed - 1
Processor - Processor boost frequency - 5.1 GHz
Processor - Processor cache - 16 MB
Processor - Processor cores - 4
Processor - Processor family - AMD EPYC
Processor - Processor frequency - 3.8 GHz
Processor - Processor manufacturer - AMD
Processor - Processor model - 4124P
Processor - Processor threads - 8
Processor - Thermal Design Power (TDP) - 65 W
producer - Lenovo
ProductName - ST45 V3
RAM - other information -
RAM memory installed - 16 GB
ShortSummaryDescription - Lenovo ThinkSystem ST45 V3, 3.8 GHz, 4124P, 16 GB, DDR5-SDRAM, 1.92 TB, Tower
Software - Operating system installed - No
Stck_Kart - 1
Stck_Pal - 1
Storage - Internal drive bays - 2
Storage - Number of SSDs installed - 2
Storage - Optical drive type - No
Storage - RAID support - Yes
Storage - SSD capacity - 960 GB
Storage - SSD interface - SATA
Storage - SSD size - 3.5"
Storage - Total storage capacity - 1.92 TB
Storno - N
Technical details - Supported storage drives form factor (internal) - 3.5"
Title - Lenovo ThinkSystem ST45 V3 server 1.92 TB Tower AMD EPYC 4124P 3.8 GHz 16 GB DDR5-SDRAM 500 W
Total capacity of all disks installed - 1920 GB
Total number of memory slots - 2
Tower to rack conversion support - Yes
URL - https://lenovopress.lenovo.com/lp1994-lenovo-thinksystem-st45-v3-server
vendpn - 7DH5A007EA
Warranty -
WarrantyInfo -
Weight - 8.56 kg
Weight & dimensions - Depth - 316 mm
Weight & dimensions - Height - 376 mm
Weight & dimensions - Weight - 8.56 kg
Weight & dimensions - Width - 170 mm
Width - 170 mm
