Zalman GigaMax II, 550W, 80PLUS Bronze

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 926827 Product code: ZM550-GVII
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

Dateks.lv website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 3 years
Main product parameters All parameters
  • Producer: Zalman
  • Power output: 550W
  • 80 PLUS certification: 80 PLUS Bronze
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 1 x 8-pin(4+4) EPS
  • PCI-E: 2 X 6+2pin
Similar Products
This product Zalman GigaMax II, 550W, 80PLUS Bronze
Recommended Gigabyte GP-P550SS, 550W, 80PLUS Silver
Recommended ADATA XPG PYLON II, 650W, 80PLUS Bronze, ATX 3.1, PCIe 5.1
Recommended XPG PROBE, 700W, 80PLUS Bronze
Recommended XPG PROBE, 600W, 80PLUS Bronze
Show similar specs. Hide similar specs.
65.47 €
51.76 €
62.95 €
67.51 €
55.28 €
Basic information
Cybenetics Efficiency certification Nav Nav Nav Nav Nav
Cybenetics Noise level certification Nav Nav Nav Nav Nav
Power supply type ATX ATX ATX ATX ATX
Power output 550W 550W 650W 700W 600W
80 PLUS certification 80 PLUS Bronze 80 PLUS Silver 80 PLUS Bronze 80 PLUS Bronze 80 PLUS Bronze
Total amperage (+12V) 45A 54A 54A 46A
Fan size 120 mm 120 mm 120 mm 120 mm 120 mm
Functionality
Cable colour Melna Melna Melna Melna Melna
Lighting Nav Nav Nav Nav Nav
Color Melna Melna Melna Melna Melna
Modular cables Nav Nav Nav Nav Nav
Ports and equipment
PCI-E 5.0/5.1 Nav Nav 1 x 450W 12V-2X6 (5.1) Nav Nav
Processor plug-in 1 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 1 x 8-pin(4+4) EPS
Motherboard power 20+4pin 20+4pin 24-pin 20+4pin 20+4pin
PCI-E 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin 2 X 6+2pin
SATA cconnectors 5 5 6 5 5
4pin Molex 3 3 2 2 2
Description

This Zalman brand power supply unit has an 80 PLUS Bronze energy efficiency certificate and a power output of 550W.

With 550W power, it will be enough to run Office programs, browse the internet, and play simple computer games. It will be able to run a computer with a budget-level processor, integrated graphics card, small SSD, or HDD disk. If there is a desire to upgrade computer components in the future, it is definitely worth considering a more powerful power supply unit.

This power supply unit is equipped with a 120 mm fan, which is the industry standard for ensuring quiet operation in average computers. If you want an especially quiet unit, look for one with a fan diameter of 135 mm or 140 mm.

80 PLUS Bronze energy efficiency certificate, received by this power supply unit, guarantees at least 85% efficiency at 50% load. In other words, for every 100 W of energy the power supply unit receives from the electrical grid, at least 85 W goes to your computer components, while the remaining 15 W is lost as heat.

The color of the block is Melna. The block has flat cables, whose color is Melna.

This is a power supply that complies with ATX 2.0 requirements. The power supply has only 6-pin and 8-pin connectors, which can handle only 75 W and 150 W of power, respectively. Modern graphics cards' high power needs exceed the capabilities of ATX 2.0 connectors. When building a system with a very powerful GPU, such as an RTX 4070, you will need an ATX 3.* standard power supply.

The power supply unit does not have modular cables; all cables are attached to the power supply unit and are not removable. Despite this, it will work just as well as a power supply unit with modular cables.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 550W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Bronze
Total amperage (+12V) : 45A
Fan size : 120 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Nav
Ports and equipment
PCI-E 5.0/5.1 : Nav
Processor plug-in : 1 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 2 X 6+2pin
SATA cconnectors : 5
4pin Molex : 3
More detailed specification
8-pin 12V power connectors - 0
Accessories included - Podręcznik użytkownika Opaski zaciskowe dla kabli Kabel zasilający Zestaw śrub
ATX version - 2.31
Brand - Zalman
BrandPartCode - ZM550-GVII
Category - Power Supply Units
Certificates - Certification - 80 Plus, CB, CE, KC, EAC, RoHS
Certificates - Compliance certificates - RoHS
Certificates 80+ - 80 PLUS Bronze
Description - GigaMax 550 w
Gwarantowana maksymalna sprawność 88%. Minimalne straty mocy. Sprawność przetwarzania energii na poziomie 88% zmniejsza straty mocy i koszty konserwacji. Zapewnia wysoką efektywność energetyczną i stabilne środowisko obsługi systemu.
Wysokiej jakości części zaprojektowane dla długotrwałej i niezawodnej obsługi systemu.
Stabilne zasilanie komputera PC przy równoczesnym zmniejszeniu poboru mocy, dzięki zastosowaniu wysokiej jakości części, które są także trwałe i niezawodne.
Aktywy system PFC o maksymalnym współczynniku mocy do 99.5%
Aktywy system PFC o maksymalnym współczynniku mocy do 99.5% zapewnia spójne i stabilne wyjście oraz wysoką wydajność energetyczną. Wysoka wydajność energetycza zapewnia z kolei stabilną pracę systemu i niskie szumy elementów składowych, niski poziom generowanego ciepła i minimalne wahania napięcia zasilania.
Przetwornik 12V DC-DC z dostępnością 99%
Zasilacz obsługuje szeroką gamę różnorodych komponentów wchodzących w skład komputera PC minimalizując odchylenia napięcia wyjściowego, zwiększając napięcie wyjściowe szyny do 12V DC w celu zapewnienia stabilnej pracy systemu.
Wbudowany filtr EMI dla redukcji szumów
Filtr EMI tłumi częstotliwości powodujące szumy i zapewnia w ten sposób lepszą pracę systemu.
Kondensator 105°C
Kondensator 105°C zapewnia stabile zasilanie nawet dla wysokich wartości napięcia i temperatury. Wszystkie kondensatory zastosowane w zasilaczu są najwyższej jakości i niezawodne w zapewnianiu stabilnego zasilania nawet w najwyższych temperaturach.
Łożysko hydrodynamiczne (FDB)
Technologia chłodzenia  dla cichej pracy i długiego okresu eksploatacji. Łożysko hydrodynamiczne (FDB) charakteryzuje się niskimi szumami i długim okresem eksploatacji. Szybko odprowadza wewnętrzne ciepło i zapewnie odpowiednie chłodzenie przy niskich prędkościach obrotowych w celu zapewnienie stabilnego i bezpiecznego zasilania.
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 26 mm
dimension height - 135 mm
Dimensions - 150 x 140 x 86 mm
dimension weight - 880 g
dimension width - 135 mm
ean - 8809213769597
Fan - 12 cm
Floppy power connectors - 1
GTIN - 8809213769597
guarantee - 60
guarantee_type - normal
Logistics data - Country of origin - China
LongDesc - 80 Plus Bronze 230V EU certified Power Supply Unit. It supplies smooth power to the PC while reducing unnecessary power consumption by using high-performance parts that are very durable and reliable.
LongProductName - 550 W, 220-240 VAC, Active PFC, 50/60 Hz, max 50A
LongSummaryDescription - Zalman ZM550-GVII. Total power: 550 W, AC input voltage: 220 - 240 V, AC input frequency: 50 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
MB power connector - 20 + 4 pin
MOLEX power connectors - 2
name - Power supply GigaMax 550W 80+ BRONZE EU ZM550-GVII
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 2
Operational conditions - Operating relative humidity (H-H) - 5 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Packaging content - Cables included - AC, CPU, PCIe, Peripheral (Molex), SATA
Packaging data - Package type - Box
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - Bearing technology - FDB
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Supported motherboard form factors - ATX, micro ATX, Mini-ITX
PFC - Active
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 65 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 55 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 2
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power cable length - 50 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power cable length - 400 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 1
Ports & interfaces - SATA power cable length - 400 mm
Power - AC input frequency - 50 - 63 Hz
Power - AC input voltage - 220 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 540 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Input current - 6 A
Power - Max output current (+3.3V) - 18 A
Power - Max output current (+5V) - 15 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 45 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 99
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Short circuit, Under voltage
Power - Total power - 550 W
Power supply - 550 W
producer - Zalman
ProductName - ZM550-GVII
Safety regulation & standards - Safety - CB, CE, KC, EAC, RoHS
SATA power connectors - 2
ShortSummaryDescription - Zalman ZM550-GVII, 550 W, 220 - 240 V, 50 - 63 Hz, 6 A, Active, 100 W
Title - Zalman ZM550-GVII power supply unit 550 W 20+4 pin ATX ATX Black
URL - https://www.zalman.com/
vendpn - ZM550-GVII
WarrantyInfo - 5 years
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 1.95 kg
Weight & dimensions - Width - 140 mm
