Be Quiet SFX Power 3, 300W, 80PLUS Bronze

Brand - be quiet!
BrandPartCode - BN320
category - Energy Power Supplies
Category - Power Supply Units
Category 1 - Netzteile
Category_1 - Power
Category_2 - Computer Power Supplies
code - BN320
Design - Cooling type - Active
Design - Fan diameter - 8 cm
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 599
ean - 4260052188262
EAN - 4260052188262
EAN_code - 4260052188262
GTIN - 4260052188262
Logistics data - Harmonized System (HS) code - 84733020
Logistics data - Products per shipping (inner) case - 6 pc(s)
Logistics data - Shipping (inner) case gross weight - 7.91 kg
Logistics data - Shipping (inner) case height - 23.3 cm
Logistics data - Shipping (inner) case length - 45.7 cm
Logistics data - Shipping (inner) case width - 26.5 cm
LongDesc - SFX Power 3 300W, the compact PSU from be quiet! that gives you more for your mini or media PC. It provides enough power to support powerful PCIe graphics cards while offering the ideal combination of power, quietness and reliability. That makes it the perfect choice for compact PC systems that perform beyond the ordinary.
LongProductName - 300W, ATX SFX12V V3.42, EPS 2.92, 1x 80mm (1979RPM), 80 PLUS Bronze
LongSummaryDescription - be quiet! SFX POWER 3 300W. Total power: 300 W, AC input voltage: 100 - 240 V, Peak power: 350 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 35 cm, SATA power cable length: 300,450,600 mm. Purpose: PC, Power supply unit (PSU) form factor: SFX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 8 cm. Width: 125 mm, Depth: 100 mm, Height: 64 mm
Manufacturer - Be quiet
Manufacturer - Be Quiet!
Manufacturer_code - BN320
MPN - BN320
Name - be quiet! SFX Power 3 300W SFX - BN320
name - be quiet! SFX Power 3 Netzteil, 80 PLUS Bronze - 300 Watt
Name - SFX 300W BeQuiet! SFX Power 3 |80+ Bronze
Packaging data - Package depth - 75 mm
Packaging data - Package height - 207 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.19 kg
Packaging data - Package width - 197 mm
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 3.42
Performance - Bearing technology - Rifle
Performance - EPS version - 2.92
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 29.4 dB
Performance - Power supply unit (PSU) form factor - SFX
Performance - Purpose - PC
Performance - Safety - CE, CB, TÜV, CU
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU P4 connector (4-pin) - 1
Ports & interfaces - CPU power cable length - 40 cm
Ports & interfaces - Floppy disk drive cable length - 60 cm
Ports & interfaces - Floppy drive power connector - 1
Ports & interfaces - Motherboard power cable length - 35 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 3
Ports & interfaces - PCI Express power cable length - 40 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 300 mm
Ports & interfaces - Peripheral (Molex) power cable length - 300,450 mm
Ports & interfaces - Peripheral (Molex) power cable length - 450 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Ports & interfaces - SATA power cable length - 300 mm
Ports & interfaces - SATA power cable length - 300,450,600 mm
Ports & interfaces - SATA power cable length - 450
Ports & interfaces - SATA power cable length - 600
Power - AC input frequency - 50 - 60 Hz
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 85 W
Power - Combined power (+5V) - 85 W
Power - Combined power (+12V) - 300 W
Power - Efficiency - 88.1%
Power - Hold time - 26.8 ms
Power - Input current - 5/2 A
Power - Maximum input current (@110V) - 5 A
Power - Maximum input current (@220V) - 2 A
Power - Max output current (+3.3V) - 16 A
Power - Max output current (+5V) - 16 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V1) - 25 A
Power - Max output current (-12V) - 0.3 A
Power - Peak power - 350 W
Power - Power factor - 0.98
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 300 W
producerCode - BN320
productName - be quiet! SFX POWER 3 300W power supply unit 20+4 pin ATX Black
ProductName - SFX POWER 3 300W
productSize - Normal
ShortSummaryDescription - be quiet! SFX POWER 3 300W, 300 W, 100 - 240 V, 350 W, 50 - 60 Hz, 5/2 A, 5 A
sizeX - 75
sizeY - 195
sizeZ - 205
Technical details - Sustainability certificates - ENERGY STAR
Technical details - Sustainability certificates - ENERGY STAR, ErP, RoHS, WEEE
Technical details - Sustainability certificates - ErP
Technical details - Sustainability certificates - RoHS
Technical details - Sustainability certificates - WEEE
Technical details - Sustainability compliance - Yes
Title - be quiet! SFX POWER 3 300W power supply unit 20+4 pin ATX Black
URL - https://www.bequiet.com/en/download/powersupply/2308?utm_source=newsletter
WarrantyInfo - 3 Years
warrantyLength - 24
warrantyType - G
Weight - 1,20
Weight - 1.22
weight - 1195
Weight & dimensions - Depth - 100 mm
Weight & dimensions - Height - 64 mm
Weight & dimensions - Weight - 840 g
Weight & dimensions - Width - 125 mm
