AeroCool VX 500 PLUS, 500W

Name: AeroCool VX 500 PLUS, 500W
Brand: AeroCool
SKU: 472137
Price: 58.04 EUR
Availability: OutOfStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 472137 Product code: AEROPGSVX-500PLUS-80

Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

Dateks.lv website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years

Compare

Main product parameters All parameters

Producer: Aerocool
Power output: 500W
80 PLUS certification: None
Fan size: 120 mm
Modular cables: None
Processor plug-in: 1 x 8-pin(4+4) EPS
PCI-E: 1 X 6+2pin

Similar Products

Basic information
	This product AeroCool VX 500 PLUS, 500W	AeroCool VX PLUS 600, 600W	AeroCool LUX, 550W, 80PLUS Bronze	AeroCool VX-650 PLUS, 650W	Chieftec Core Series, 500W, 80PLUS Gold
Show similar specs. Hide similar specs.	58.04 €	57.27 €	65.09 €	68.33 €	71.93 €
Cybenetics Efficiency certification	There isn't	There isn't	There isn't	There isn't	There isn't
Cybenetics Noise level certification	There isn't	There isn't	There isn't	There isn't	There isn't
Power supply type	ATX	ATX	ATX	ATX	ATX
Power output	500W	600W	550W	650W	500W
80 PLUS certification	None	None	80 PLUS Bronze	None	80 PLUS Gold
Total amperage (+12V)	38A	46A	42A	50A	41A
Fan size	120 mm	120 mm	120 mm	120 mm	120 mm
Functionality
Cable colour	Raiba	Raiba	Black	Raiba	Raiba
Lighting	None	None	None	None	None
Color	Black	Black	Black	Black	Black
Modular cables	None	None	None	None	None
Ports and equipment
PCI-E 5.0/5.1	There is no	There is no	There is no	There is no	There is no
Processor plug-in	1 x 8-pin(4+4) EPS	1 x 8-pin(4+4) EPS	1 x 8-pin(4+4) EPS	1 x 8-pin(4+4) EPS	1 x 8-pin(4+4) EPS
Motherboard power	20+4-pin	20+4-pin	20+4-pin	20+4-pin	20+4-pin
PCI-E	1 X 6+2pin	2 X 6+2pin	1 X 6+2pin	2 X 6+2pin	1 X 6+2pin
SATA cconnectors	3	3	4	4	4
4pin Molex	3	2	2	3	3

Description

120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.

The color of this power supply is Melna. The cable color is Raiba and they are flat.

ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.

This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.

Basic information

Cybenetics Efficiency certification : There isn't

Cybenetics Noise level certification : There isn't

Power supply type : ATX

Power output 500W

The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.

80 PLUS certification : None

Total amperage (+12V) : 38A

Fan size : 120 mm

Functionality

Cable colour : Raiba

Lighting : None

Color : Black

Modular cables : None

Ports and equipment

PCI-E 5.0/5.1 : There is no

Processor plug-in : 1 x 8-pin(4+4) EPS

Motherboard power : 20+4-pin

PCI-E : 1 X 6+2pin

SATA cconnectors : 3

4pin Molex : 3

More detailed specification

Additional information in manufacturers website AeroCool VX 500 PLUS, 500W

Brand - Aerocool
BrandPartCode - AEROPGSVX-500PLUS-80
Category - Power Supply Units
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Fan speed - 700 - 1700 RPM
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
dimensionalWeight - 920
GTIN - 4718009159341
Logistics data - Country of origin - China
LongDesc - Focused on delivering the best value power supply unit, the VX PLUS allows for easy installation while delivering reliable quality and excellent performance, making this the perfect PSU for entry-level system builders. Comes equipped with an upgraded transformer and a 12cm fan with optimized thermal fan speed control.UNBEATABLE VALUEVX PLUS offers the best value you could ask for in a power supply with easy installation and top-notch performance, making this the perfect starting PSU for entry-level system builders.IMPROVED DESIGNEquipped with a unique, top cover design, the VX PLUS looks better than ever and enhances the entire look and feel of any proper gaming setup.UPGRADED TRANSFORMERUpgraded transformer improves balance between 12V, 3.3V, and 5V voltage regulations and enhances the stability, allowing for heavy 12V loading system support.OPTIMIZED FAN RPMSilent 12cm fan with optimized smart fan speed control. Fan runs in startup speed before reaching 50% load at 25℃ ambient temperatures.
LongProductName - 500 W, 230 V, ATX 12V 2.3
LongSummaryDescription - Aerocool VX Plus 500. Total power: 500 W, AC input voltage: 230 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 50 cm, SATA power cable length: 300 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: CPU, PATA, PCIe, SATA
Packaging content - Cables included - CPU, PATA, PCIe, SATA
Performance - 80 PLUS certification - 80 PLUS
Performance - ATX power connector (20+4 pin) - Yes
Performance - ATX version - 2.3
Performance - Connector(s) - FDD
Performance - CPU power connector (4+4 pin) - Yes
Performance - Number of SATA power connectors - 3
Performance - PCI Express power connectors (6+2 pin) - 1
Performance - Peripheral (Molex) power connectors (4-pin) - 3
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Supported motherboard form factors - ATX
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 55 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Floppy disk drive cable length - 75 cm
Ports & interfaces - Floppy disk drive connector - Yes
Ports & interfaces - Floppy drive power connector - 1
Ports & interfaces - Motherboard power cable length - 50 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 3
Ports & interfaces - Number of SATA power connectors - 3
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power cable length - 40 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 450,600 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 6
Ports & interfaces - SATA power cable length - 300 mm
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 115 - 230 V
Power - AC input voltage - 230 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 456 W
Power - Combined power (-12V) - 3.6 W
Power - Input current - 4 - 8 A
Power - Input current - 4 A
Power - Max output current (+3.3V) - 18 A
Power - Max output current (+5V) - 16 A
Power - Max output current (+5Vsb) - 2.4 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 38 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 500 W
producerCode - AEROPGSVX-500PLUS-80
productName - Aerocool VX-500W ATX power supply module Black
ProductName - VX Plus 500
productSize - Normal
ShortSummaryDescription - Aerocool VX Plus 500, 500 W, 230 V, 47 - 63 Hz, 4 A, 120 W, 456 W
sizeX - 230
sizeY - 200
sizeZ - 100
Title - Aerocool VX Plus 500 power supply unit 500 W 20+4 pin ATX ATX Black
URL - https://aerocool.io/product/vx-plus-500/
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 1276
