ID: 1237107
Product code: PPA25A0102
Can be ordered 5 units Availability: 14 days after order approval
Warranty: 3 years
FSP Cannon Pro, 2500W, 80PLUS Platinium, ATX 3.1, PCIe 5.1
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Receiving goods at the Dateks office0.00 € -
DPD Pickup Parcel CabinetWithin 1-2 working days0.00 € -
Parcel terminalWithin 1-2 working days0.00 € -
Post OfficeWithin 1-2 working days0.00 €
-
Omniva parcel machineWithin 1-2 working days0.00 € -
SmartPosti parcel terminalWithin 1-2 working days0.00 € -
Unisend parcel terminalWithin 1-2 working days0.00 € -
Delivery throughout Latvia.Within 1-2 working days4.99 €
Main product parameters All parameters
- Producer: FSP
- Power output: 2500W
- 80 PLUS certification: 80 PLUS Platinum
- Fan size: 135 mm
- Modular cables: Fully-Modular
- Processor plug-in: 3 x 8-pin(4+4) EPS
- PCI-E: 11 x 6+2pin
Description
Available for purchase is a power supply produced by FSP with a power output of 2500W. The product has been awarded an 80 PLUS Platinum energy efficiency certificate.
This power supply is equipped with an exceptionally large 135 mm fan. Thanks to the larger blade size, it provides better airflow at lower speeds and quieter operation compared to standard 120 mm fans.
80 PLUS Platinum energy efficiency certificate, received by this power supply unit, guarantees at least 92% efficiency at 50% load. In other words, for every 100 W of energy that the power supply unit receives from the power grid, at least 92 W reaches your computer components, while the remaining 8 W is lost as heat.
The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.
Thanks to the fact that this power supply has modular cables, you can add hard drives, video cards, and other components as needed, using the various cables included in the package. This way, there are fewer wires in the computer, which improves ventilation and appearance (especially useful for those who choose a partially transparent case).
Basic information
Cybenetics Efficiency certification
: There isn't
Cybenetics Noise level certification
: There isn't
Power supply type
: ATX
Power output
2500W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Platinum
Total amperage (+12V)
: 208.3A
Fan size
: 135 mm
Functionality
Cable colour
: Melna
Lighting
: Nav
Color
: Melna
Modular cables
: Fully-Modular
Ports and equipment
PCI-E 5.0/5.1
: 4 x 600W 12V-2X6 (5.1)
Processor plug-in
: 3 x 8-pin(4+4) EPS
Motherboard power
: 20+4pin
PCI-E
: 11 x 6+2pin
SATA cconnectors
: 10
4pin Molex
: 2
More detailed specification
Brand - FSP
BrandPartCode - PPA25A0102
Category - Power Supply Units
Category 1 - Netzteile
Design - Fan diameter - 13.5 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
EAN - 4711498480286
GTIN - 4711498480286
GTIN - 4711498480446
LongDesc - The Future is Now：ATX 3.1 & PCIe Gen 5.1 ReadyFollowing the latest ATX 3.1 & PCIe Gen 5.1 regulation, this series supports 2 x total power excursion and 3 x GPU excursion to provide peak performance with modern hardware or future upgrades.High efficiency in Platinum-certifiedCertified by world-class organizations 80 PLUS® 230 EU platinum certification for lower power loss, less heat, and quieter operation.Ready to Build Your Own AI PC Station4 x PCIe 12V-2x6 and 3x PCIe 8 pin connectorsSupports four 12V-2x6 connectors and three 6+2 pin connectors, providing the power needed for high-end gaming, rendering, and multi-GPU setups.Fully Modular Cabling DesignTo make power supply installation easy and allows users to use only the needed cables, improving airflow and reducing system clutter.+5V & 3.3V DC to DC Circuit DesignBoth of +3.3V and +5V DC – DC module combined +12V SR circuit offers supreme efficiency, voltage stability and high system compatibility especially in cross regulation(unbalance load) mode.105℃ Japanese Bulk CapacitorThe bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.Powerhouse Yet Energy-savingHigh energy conversion up to 94% and 70% efficiency at 2% loading, with less than 0.5W consumption in standby mode, ensures an energy-efficient, cost-effective system that is also eco-friendly.The Premium Quality FDB FanBuilt with optimized thermal solution and an advanced 135mm fluid dynamic bearing fan for cooler components and quieter operation.Industrial – design: Conformal Coating for Rigorous Computing EnvironmentsProvide power stably under rigorous, high-speed computing environments that need to operate 24 hours a day without interruptions.Fortress-level ProtectionOur comprehensive circuit shields your valuable components from harm.
LongProductName - 2500W, ATX12V V3.1, 200-240V, 50/60Hz, 200 x 150 x 86 mm
LongSummaryDescription - FSP CANNON PRO(ATX3.1) 2500W. Total power: 2500 W, AC input voltage: 200 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, SATA power cable length: 965 mm, Peripheral (Molex) power cable length: 965 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Fan diameter: 13.5 cm, Number of fans: 1 fan(s). Width: 150 mm, Depth: 200 mm, Height: 86 mm
Manufacturer - FSP
Manufacturer Code - PPA25A0102
Manufacturer Name - Fortron
MPN - PPA25A0102
Name - 2500W FSP CANNON PRO 2500 80+ Platin ATX 3.1
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - ATX version - 3.1
Performance - Bearing technology - FDB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power cables - 2
Ports & interfaces - Number of SATA power connectors - 8
Ports & interfaces - PCI Express power connectors (6+2 pin) - 3
Ports & interfaces - PCI Express power connectors (8-pin) - 8
Ports & interfaces - Peripheral (Molex) power cable length - 965 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 965 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 125 W
Power - Combined power (+5V) - 125 W
Power - Combined power (+5Vsb) - 20 W
Power - Combined power (+12V) - 2499.6 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 94%
Power - Input current - 15 - 12 A
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 25 A
Power - Max output current (+5Vsb) - 4 A
Power - Max output current (+12V) - 208.3 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.9
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - No load operation, Over current, Over power, Over voltage, Short circuit, Surge and inrush, Under temperature, Under voltage
Power - Total power - 2500 W
ProductName - CANNON PRO(ATX3.1) 2500W
Short description - Netzteil FSP ATX 3.1 2500W 80+ Platinum FSP2500-57APB CANNON PRO 2500
ShortSummaryDescription - FSP CANNON PRO(ATX3.1) 2500W, 2500 W, 200 - 240 V, 50/60 Hz, 15 - 12 A, Active, 125 W
Title - FSP CANNON PRO(ATX3.1) 2500W power supply unit 20+4 pin ATX ATX Black
URL - https://www.fsplifestyle.com/en/product/CANNONPRO2500W_12V2X6.html
WarrantyInfo - 3 Years
Weight - 5.64
Weight & dimensions - Depth - 200 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
