FSP Hyper Pro, 555W, 80PLUS Bronze

Brand - FSP
BrandPartCode - 9PA5509407
Category - Power Supply Units
Category 1 - Netzteile
Certificates - Certification - IEC 62368
Code - HYPER 80+PRO550 BKB
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Illumination - No
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
EAN - 4711498480569
GTIN - 4711498480569
Link - https://www.fsplifestyle.com/en/product/HYPER80plusPRO550W.html
LongDesc - 80 Plus® 230V EU Bronze CertificationHYPER 80+ PRO series, 80 PLUS® 230V EU Bronze certified, saves energy through its high efficiency up to 88%.DC-to-DC Module DesignWith a 12V SR circuit and the DC to DC structure, HYPER 80+ PRO series ensure you outstanding conversion efficiency and provides stable output voltage.450V 105C, Heavy-duty capacitorThe bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.Energy Related ErP/Eup 2013Green Power! The total AC power consumption of the completed system is less than 5Vsb rail to support the new EU Regulation ErP 2013 for modern day systems.Keep in Compliance IEC 62368FSP Group provides a full kinds of additional safety approvals to keep designs ahead of the changing regulations. FSP has upgraded the majority of power supplies to the new IEC 62368 standard for your gaming rigs.Intelligent Fan Speed ControlAn advanced thermal control fan makes optimal cooling and reduces noise under maximum operation.120mm fan and heat dissipation design to spin quietly and keep cooling under maximum operation.All Black Round CablesThe all black coating round cables give your system a superior look rather so many entry-level power supplies.For gaming enthusiast, the HYPER 80+ PRO series features with dual CPU power connectors to support high-end motherboard and provide CPU stable power.
LongProductName - HYPER 80+ PRO 550W, ATX, 120mm Sleeve Fan, 80 Plus Bronze
LongSummaryDescription - FSP H3-550. Total power: 550 W, AC input voltage: 200 - 240 V, Input current: 4.5 A. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Certification: IEC 62368
Manufacturer - FSP
MPN - 9PA5509407
Name - 550W FSP Hyper PRO 80+ Bronze
Name - FSP Power Supply | HYPER 80+PRO550 BKB | 550 W
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 140.00 mm
Package features > Gross height (mm) - 90.00 mm
Package features > Gross width (mm) - 150.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 286 pc(s)
Package features > Paper/Pasteboard - 400.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.50 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 2.4
Performance - EPS version - 2.92
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - Floppy disk drive connector - Yes
Ports & interfaces - Floppy drive power connector - 1
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 5
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 85 W
Power - Combined power (+5V) - 85 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 549.6 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Hold time - 17 ms
Power - Input current - 4.5 A
Power - Max output current (+3.3V) - 16 A
Power - Max output current (+5V) - 16 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 45.8 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.9
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Short circuit
Power - Total power - 550 W
Power > Nominal power - 550 W
ProductName - H3-550
ShortSummaryDescription - FSP H3-550, 550 W, 200 - 240 V, 4.5 A, Active, 85 W, 549.6 W
Technical details - Sustainability certificates - ErP
Technical details - Sustainability compliance - Yes
Technical details > Gross weight - 3.50 kg
Technical details > Net weight - 3.00 kg
Technical details > Producer - FSP
Technical details > Producer product family - Power Supply
Technical details > Producer product name - HYPER 80+PRO550 BKB
Title - FSP H3-550 power supply unit 550 W 24-pin ATX ATX Black
URL - https://www.fsplifestyle.com
Warranty - 60
Warranty - 60 month(s)
WarrantyInfo -
Weight - 1.44
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 1.25 kg
Weight & dimensions - Width - 150 mm
