ID: 1188936
Product code: TACANIMA-APB550
Can be ordered 75 units Availability: 14 days after order approval
Warranty: 2 years
Tacens Anima APB550, 550W, 80PLUS Bronze
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Receiving goods at the Dateks office0.00 € -
DPD Pickup Parcel CabinetWithin 1-2 working days0.00 € -
Parcel terminalWithin 1-2 working days0.00 € -
Post OfficeWithin 1-2 working days0.00 €
-
Omniva parcel machineWithin 1-2 working days0.00 € -
SmartPosti parcel terminalWithin 1-2 working days0.00 € -
Unisend parcel terminalWithin 1-2 working days0.00 € -
Delivery throughout Latvia.Within 1-2 working days4.99 €
Main product parameters All parameters
- Producer: Tacens
- Power output: 550W
- 80 PLUS certification: 80 PLUS Bronze
- Fan size: 120 mm
- Modular cables: Nav
- Processor plug-in: 1 x 8-pin(4+4) EPS
- PCI-E: 1 X 6+2pin
Description
This Tacens brand power supply unit has an 80 PLUS Bronze energy efficiency certificate and a power output of 550W.
The power of 550W is sufficient for basic computer gaming, web browsing, and Office applications use. The unit is designed for a computer with a budget processor, integrated graphics card, small SSD or hard drive. If you decide to upgrade your computer in the future, you should definitely consider purchasing a more powerful power supply.
This power supply unit is equipped with a 120 mm fan, which is the industry standard for ensuring quiet operation in average computers. If you want an especially quiet unit, look for one with a fan diameter of 135 mm or 140 mm.
The power supply has received the 80 PLUS Bronze energy efficiency certificate, which guarantees at least 85% efficiency at 50% load. This means that for every 100W of power the power supply draws from the electrical grid, at least 85W is delivered to your computer components, while the remaining 15W is lost as heat.
The color of the block is Melna. The block has flat cables, whose color is Melna.
This power supply unit has been assigned the ATX 2.0 standard. This means that the unit is equipped only with 6-pin and 8-pin connectors, providing 75W and 150W power respectively. It's important to note that this unit will be compatible with RTX 4070 and more powerful cards, but you will need to use the 2x8-pin to 16-pin 12VHPWR adapter included with the graphics card. ATX 2.0 power connectors are not designed to handle the high power fluctuations of modern graphics cards; therefore, if you are building a system with a powerful GPU, such as the RTX 4070, we recommend choosing a power supply unit with the ATX 3.* standard and 12VHPWR (PCIe 5.0) connector.
This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.
Basic information
Cybenetics Efficiency certification
: Nav
Cybenetics Noise level certification
: Nav
Power supply type
: ATX
Power output
550W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Bronze
Total amperage (+12V)
: 40A
Fan size
: 120 mm
Functionality
Cable colour
: Melna
Lighting
: Nav
Color
: Melna
Modular cables
: Nav
Ports and equipment
PCI-E 5.0/5.1
: Nav
Processor plug-in
: 1 x 8-pin(4+4) EPS
Motherboard power
: 20+4pin
PCI-E
: 1 X 6+2pin
SATA cconnectors
: 3
4pin Molex
: 2
Case
More detailed specification
8-pin 12V power connectors - 0
Accessories included -
Brand - Tacens
Brand - Tacens Anima
BrandPartCode - APB550
BrandPartCode - APB550B
Category - Power Supply Units
Certificates 80+ - 80 PLUS Bronze
Description - Anima APB550W power supply with 80 Plus Bronze certificate
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
dimensionalWeight - 1279
dimension depth - 220 mm
dimension height - 165 mm
Dimensions - 150 x 85 x 140mm
dimension weight - 1280 g
dimension width - 100 mm
ean - 4710700957998
Fan - 12 cm
Floppy power connectors - 0
GTIN - 4710700957998
GTIN - 8435693102496
guarantee - 24
guarantee_type - normal
LongDesc -
LongDesc - The APB550 power supply is designed to deliver up to 550W of power safely and efficiently, boosting your equipment's performance to the maximum. The 80 Plus Bronze certification guarantees full and long-lasting operation, in addition to its multiple tests carried out by renowned European testing laboratories.
LongProductName - 550W, 1x20+4pin, 1x12V 4+4pin, 1xPCI-e 6+2pin, 3xSATA, 2xPATA
LongProductName - 550W, 1x20+4pin, 1x 12V 4+4pin, 1x PCI-e 6+2pin, 3x SATA, 2x PATA, 220-240 V, 4.5 A, 50-60 Hz, Black
LongSummaryDescription - Tacens Anima APB550. Total power: 550 W, AC input voltage: 220 - 240 V, AC input frequency: 50 - 60 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular. Purpose: PC, 80 PLUS certification: 80 PLUS Bronze, Noise level: 14 dB. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 85 mm
LongSummaryDescription - Tacens APB550B. Total power: 550 W, AC input voltage: 220 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Fan diameter: 12 cm, Number of fans: 1 fan(s). Width: 150 mm, Depth: 140 mm, Height: 85 mm
MB power connector - 20 + 4 pin
Modular power supply - No
MOLEX power connectors - 2
name - ANIMA APB550W 80PLUS
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 1
Other features -
Packaging data - Package depth - 165 mm
Packaging data - Package depth - 218 mm
Packaging data - Package height - 100 mm
Packaging data - Package height - 165 mm
Packaging data - Package type - Box
Packaging data - Package weight - 1.4 kg
Packaging data - Package weight - 1.5 kg
Packaging data - Package width - 100 mm
Packaging data - Package width - 207 mm
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - Noise level - 14 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 2
Ports & interfaces - Number of SATA power connectors - 3
Ports & interfaces - PCI Express power connectors (6+2 pin) - 1
Power - AC input frequency - 47 - 63 Hz
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 220 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+3.3V) - 180 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5V) - 180 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 360 W
Power - Combined power (+12V) - 480 W
Power - Combined power (-12V) - 3.6 W
Power - Combined power (-12V) - 6 W
Power - Efficiency - 85%
Power - Input current - 4.5 A
Power - Input current - 5 A
Power - Max output current (+3.3V) - 18 A
Power - Max output current (+3.3V) - 24 A
Power - Max output current (+5V) - 18 A
Power - Max output current (+5V) - 25 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 30 A
Power - Max output current (+12V) - 40 A
Power - Max output current (-12V) - 0.3 A
Power - Max output current (-12V) - 0.5 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over power
Power - Power protection features - Over power, Over voltage, Short circuit, Under voltage
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 550 W
Power supply - 550 W
producer - TACENS
producerCode - TACANIMA-APB550
ProductName - APB550
ProductName - APB550B
productName - Tacens APB550B power supply unit 550 W 20+4 pin ATX ATX Black
productSize - Normal
SATA power connectors - 3
ShortSummaryDescription - Tacens Anima APB550, 550 W, 220 - 240 V, 50 - 60 Hz, 4.5 A, Active, 180 W
ShortSummaryDescription - Tacens APB550B, 550 W, 220 - 240 V, 47 - 63 Hz, 5 A, 100 W, 480 W
sizeX - 240
sizeY - 205
sizeZ - 130
Title - Tacens Anima APB550 power supply unit 550 W 20+4 pin ATX Black
Title - Tacens APB550B power supply unit 550 W 20+4 pin ATX ATX Black
Unboxing -
URL - https://www.tacens-anima.com/
URL - https://www.tacens-anima.com/power-supplies/apb550/
vendpn - TACANIMA-APB550
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 1415
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Weight - 1.28 kg
Weight & dimensions - Weight - 1.35 kg
Weight & dimensions - Width - 150 mm
