MSI MEG CoreLiquid S280

Air flow rates - 82.27 cfm
Brand - MSI
BrandPartCode - MEG CORELIQUID S280
Category - Computer Cooling Systems
Category - Root/Electronics/PC parts/Cooling/Processor fans
category - Watercooling All in One Sets - internal
code - 9S6-6A0431-001
Cooling technology - Liquid
CPU socket - LGA1150
CPU socket - LGA1151
CPU socket - LGA1155
CPU socket - LGA1156
CPU socket - LGA1200
CPU socket - LGA1700
CPU socket - LGA2011
CPU socket - LGA2066
CPU socket - Socket AM2
CPU socket - Socket AM2+
CPU socket - Socket AM3
CPU socket - Socket AM3+
CPU socket - Socket AM4
CPU socket - Socket FM1
CPU socket - Socket FM2
CPU socket - Socket FM2+
Description - MEG SILENT GALE P14 FAN The MEG SILENT GALE P14 is an innovatively quiet fan from MSI that is designed to generate the least noisy airflow possible. CONCENTRATED COOLING PERFORMANCE A 60mm fan is housed in the water block assembly to help dissipate heat from the M.2 SSD drives, the VRMs powering the CPU, and other components on the motherboard and installed PC components. 2.4-INCH CUSTOMISABLE IPS DISPLAY The MEG CORELIQUID S series water-cooling system features a 2.4-inch customisable IPS display that can show hardware information, play GIFs, MP4 files, display photos, text and continuously updated weather information. FULL CONTROL IN YOUR HANDS Everything from the fan speed of the MEG CORELIQUID S series water cooling system to the IPS display can be set and adjusted from the MSI Center app. LGA 1700 COMPATIBLE The MAG CORELIQUID S series water cooling system is factory compatible with the new LGA 1700 CPU socket standard.
Design - Material - Aluminium
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
dimensionalWeight - 2760
dimension depth - 160 mm
dimension height - 230 mm
Dimensions - Fan dimensions: 140 x 140 x 25 mm Heatsink dimensions (L x W x H): 314.8 x 140 x 27 mm  Dimensions of cooling block (L x W x H): 95 x 95 x 54 mm
dimension weight - 2600 g
dimension width - 375 mm
ean - 4719072858230
Eans - 4719072858230
Fan - 14 cm
Fan speed (max) - 1800 rpm
GTIN - 4719072858230
guarantee - 36
guarantee_type - normal
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - The MEG CORELIQUID S Series is here to provide the ultimate silence cooling. It is equipped with MSI's innovative MEG SILENT GALE P14 silent gaming fan and supports 0 rpm fan mode. The 2.4” IPS display can also help you see a conglomerate of hardware information or customizable graphics and videos. The MEG CORELIQUID S Series descends from the top, and you just can’t hear it coming.SILENT COOLINGMSI’s MEG SILENT GALE P14 provides sufficient airflow to the radiator for cooling while maintaining low noise levels.MEG SILENT GALE P14The MEG SILENT GALE P14 is MSI’s innovative silent fan designed to generate the most silent airflow.CONCENTRATED COOLING PERFORMANCEA 60mm fan is placed within the water block to help dissipate heat for the M.2 SSD, CPU VRMs, and surrounding components.FAN 0 RPMThe MEG SILENT GALE P14 and the water block fan support 0% RPM to ensure zero noise under low temperatures.2.4” CUSTOMIZABLE IPS DISPLAYThe MEG CORELIQUID S Series comes with a 2.4” IPS display capable of displaying hardware information, GIF, MP4, photos, texts, and live weather information.TOTAL CONTROL IN YOUR HANDSEverything ranging from MEG CORELIQUID S Series’ fan speed to the IPS display can be adjusted through the MSI Center.LGA 1700 COMPATIBLEThe MEG CORELIQUID S Series liquid cooler provides out of box support for LGA 1700.EVAPORATION PROOF TUBINGConstructed with three layers of netted plastic tubing and a reinforced mesh exterior.
LongProductName - MSI MEG CORELIQUID S280 Liquid CPU Cooler '280mm Radiator, 2.4'' IPS Display with fan, 2x 140mm Silent PWM Fan, MSI Center, Supports Intel and AMD Platforms, Latest LGA 1700 ready, Cooled by ASETEK'
LongSummaryDescription - MSI MEG CORELIQUID S280 Liquid CPU Cooler '280mm Radiator, 2.4'' IPS Display with fan, 2x 140mm Silent PWM Fan, Center, Supports Intel and AMD Platforms, Latest LGA 1700 ready, Cooled by ASETEK'. Type: All-in-one liquid cooler, Maximum airflow: 82.27 cfm. Product colour: Black
name - MEG CORELIQUID S280 280 MM IPS LCD CPU COOLER
Name - MSI MEG CORELIQUID S280
name - MSI MEG CoreLiquid S280 Komplett-Wasserkühlung - 280mm
Noise - 24.9 dB
Number of fans - 2
Other features - Fan specifications Pressure of the air discharged by the fan: 2.2 mm-H2O Fan bearing: Hydrodynamic bearing (HDB) Expected fan service life: 50,000 hours, 40°C Rated fan current: 0.5 A (max.) Fan power consumption: 6 W (max.) PWM mode: Yes Cable length (PWM cable): 350 mm; 13.78 in.
Other features - Country of origin - China
Other features - Harmonized System (HS) code - 84733080
Other features - Noise level - 21.2 dB
Performance - Fan's mean time to failure (MTTF) - 50000 h
Performance - Fan bearing technology - Hydro Dynamic Bearing (HDB)
Performance - Fan noise level (max) - 24.9 dB
Performance - Fan noise level (min) - 21.2 dB
Performance - Fan speed (max) - 1800 RPM
Performance - Fan static pressure - 2.2 mmH2O
Performance - Maximum airflow - 82.27 cfm
Performance - Pulse-width modulation (PWM) support - Yes
Performance - Pump motor speed - 2800 RPM
Performance - Suitable location - Processor
Performance - Supported processor sockets - LGA 1150 (Socket H3)
Performance - Supported processor sockets - LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 2011 (Socket R), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2, Socket FM2+
Performance - Supported processor sockets - LGA 1151 (Socket H4)
Performance - Supported processor sockets - LGA 1155 (Socket H2)
Performance - Supported processor sockets - LGA 1156 (Socket H)
Performance - Supported processor sockets - LGA 1200 (Socket H5)
Performance - Supported processor sockets - LGA 2011 (Socket R)
Performance - Supported processor sockets - Socket AM2
Performance - Supported processor sockets - Socket AM2+
Performance - Supported processor sockets - Socket AM3
Performance - Supported processor sockets - Socket AM3+
Performance - Supported processor sockets - Socket AM4
Performance - Supported processor sockets - Socket FM1
Performance - Supported processor sockets - Socket FM2
Performance - Supported processor sockets - Socket FM2+
Performance - Type - All-in-one liquid cooler
Power - Fan current - 0.5 A
Power - Fan power consumption - 6 W
Power - Pump current - 0.33 mA
Power - Pump power consumption - 4 W
producer - MSI
Producer - MSI
producerCode - 9S6-6A0431-001
ProducerCode - 9S6-6A0431-001
productName - MSI MEG CORELIQUID S280 Liquid CPU Cooler '280mm Radiator, 2.4'' IPS Display with fan, 2x 140mm Silent PWM Fan, Center, Supports Intel and AMD Platforms, Latest LGA 1700 ready, Cooled by ASETEK'
ProductName - MSI MEG CORELIQUID S280 Liquid CPU Cooler '280mm Radiator, 2.4'' IPS Display with fan, 2x 140mm Silent PWM Fan, MSI Center, Supports Intel and AMD Platforms, Latest LGA 1700 ready, Cooled by ASETEK'
productSize - Normal
Radiator - Aluminium
ShortDescription - wentylator CPU - chłodzenie wodne |
ShortSummaryDescription - MSI MEG CORELIQUID S280 Liquid CPU Cooler '280mm Radiator, 2.4'' IPS Display with fan, 2x 140mm Silent PWM Fan, Center, Supports Intel and AMD Platforms, Latest LGA 1700 ready, Cooled by ASETEK', All-in-one liquid cooler, 82.27 cfm, Black
sizeX - 375
sizeY - 160
sizeZ - 230
Title - MSI MEG CORELIQUID S280 Liquid CPU Cooler '280mm Radiator, 2.4'' IPS Display with fan, 2x 140mm Silent PWM Fan, Center, Supports Intel and AMD Platforms, Latest LGA 1700 ready, Cooled by ASETEK'
Type of cooling - Active
URL - https://www.msi.com/Liquid-Cooling/MEG-CORELIQUID-S280/Overview
vendpn - MEG CORELIQUID S280
WarrantyInfo - 3 years
warrantyLength - 24
warrantyType - G
weight - 2640
Weight & dimensions - Fan dimensions (W x D x H) - 140 x 140 x 25 mm
Weight & dimensions - Radiator depth - 2.7 cm
Weight & dimensions - Radiator height - 14 cm
Weight & dimensions - Radiator width - 31.5 cm
Weight & dimensions - Tube length - 40 cm
Weight & dimensions - Waterblock depth - 5.4 cm
Weight & dimensions - Waterblock height - 9.5 cm
Weight & dimensions - Waterblock width - 9.5 cm
