Brand - Aerocool
BrandPartCode - CYLON3HARGBPWM4P
category - Aircooling|Coolers|CPU Coolers|AMD|Socket FM1/FM2+
Category - Computer Cooling Systems
code - CYLON3HARGBPWM4P
Design - Base plate material - Aluminium
Design - Fan connector - 4-pin
Design - Fins material - Aluminium
Design - Illumination LED - Yes
Design - Number of heat pipes - 3
Design - Product colour - Black
ean - 4711099470235
GTIN - 4711099470235
LongDesc - PWM air cooling solution with a stylish Addressable RGB LED design. Powered by Heat Core Touch Technology (HCTT) with 3 ultra-efficient thermal heat pipes. Top Down Cooling design allows for more efficient heat dissipation. Black coating on fins increase heat dissipation area and improves efficiency of dissipation. Compatible with Addressable RGB motherboards or hubs (H66F).STYLISH ADDRESSABLE RGB RING DESIGNComes equipped with an ARGB Ring around the fan of the cooler, adding a stylish and dynamic touch to your rig.ADDRESSABLE RGB COMPATIBLEAccess 16.8 million colors using compatible Addressable RGB motherboards including ASUS Aura Sync and MSI Mystic Light Sync as well as Gigabyte RGB Fusion motherboards using 3-Pin XWD connector.TOP DOWN COOLING DESIGNTop Down Cooling design allows heat to dissipate more quickly and efficiently while offering higher compatibility with cases.HEAT CORE TOUCH TECHNOLOGY (HCTT)3 Heatpipes provide a perfectly flat and smooth surface to maximize contact surface area.This allows for minimal heat transfer loss while in direct contact with the CPU to increase the efficiency of heat dissipation.PWM HIGH-PRESSURE FAN120mm high-pressure fan provides a stronger airflow to push heat away from the aluminum fins faster.HIGH EFFICIENCY FINSUpgraded high efficiency fins for maximum thermal performance.Black coating on fins allows for faster heat absorption, improving cooling efficiency.COMPATIBILITY Compatible with most current motherboard designs.Socket compatibility:LGA 1200/1156/1155/1151/1150/775AM4/AM3+/AM3/AM2+/AM2/FM2/FM1
LongProductName - 0.63-1.48 mm-H2O, 24.1-60.8 CFM, 13.3-24.3 dBA, 600-1800 rpm, 126 x 138 x 98mm
LongSummaryDescription - Aerocool Cylon 3H. Type: Cooler, Fan diameter: 12 cm, Rotational speed (min): 600 RPM, Rotational speed (max): 1800 RPM, Minimum air pressure: 0.63 mmH2O, Maximum air pressure: 1.48 mmH2O, Bearing type: Hydraulic. Width: 126 mm, Depth: 138 mm, Height: 98 mm. Product colour: Black
name - Aerocool Cylon 3H CPU-Kühler, ARGB - 120mm
Performance - Bearing type - Hydraulic
Performance - Fan diameter - 12 cm
Performance - Maximum airflow - 60.8 cfm
Performance - Maximum air pressure - 1.48 mmH2O
Performance - Mean time between failures (MTBF) - 60000 h
Performance - Minimum airflow (imperial) - 24.1 cfm
Performance - Minimum air pressure - 0.63 mmH2O
Performance - Noise level (high speed) - 24.3 dB
Performance - Noise level (low speed) - 13.3 dB
Performance - Rotational speed (max) - 1800 RPM
Performance - Rotational speed (min) - 600 RPM
Performance - Suitable location - Processor
Performance - Supported processor sockets - LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 775 (Socket T), Socket AM2, Socket AM2+, Socket AM3, Socket AM3+, Socket AM4, Socket FM1, Socket FM2
Performance - Type - Cooler
Power - Power consumption (typical) - 6.84 W
Power - Rated current - 0.57 A
Power - Rated voltage - 12 V
Power - Starting voltage - 7 V
Power - Thermal Design Power (TDP) - 125 W
ProductName - Cylon 3H
ShortSummaryDescription - Aerocool Cylon 3H, Cooler, 12 cm, 600 RPM, 1800 RPM, Black
Title - Aerocool Cylon 3H Processor Cooler 12 cm Black
URL - https://aerocool.io/product/cylon-3h/
WarrantyInfo -
Weight & dimensions - Depth - 138 mm
Weight & dimensions - Fan dimensions (W x D x H) - 120 x 120 x 25 mm
Weight & dimensions - Heat pipes diameter - 6 mm
Weight & dimensions - Height - 98 mm
Weight & dimensions - Width - 126 mm
