Dell USB-C Mobile Adapter DA310

15pin D-sub Input/Output connectors - 1
Brand - DELL
Brandcompatibility - Dell
BrandPartCode - DELL-DA310
Cablelockslot -
Cardreaderintegrated - No
Category - Laptop Docks & Port Replicators
Category Code - NBA
Code - 470-AEUP
Comboheadphonemicport -
Compatibility - - Latitude 7420 2-in-1, - Latitude 5520, - Latitude 7520, - Latitude 7320 2-in-1, - Latitude 5320 2-in-1, - Latitude 9410 2-in-1, - Precision 7550, - Precision 7750, - Latitude 5420 2-in-1, - Latitude 3310, - Precision 3560, - Latitude 7310, - Latitude 3310 2-in-1, - Latitude 9510, - Latitude 7210 2-in-1, - Latitude 7410, - XPS 13 (9310)
Connectivitytechnology - Wired
Countryoforigin -
Depth - 69.8 mm
Depth Retail box Dimensions - 24.5 mm
Description - Dell USB-C Mobile Adapter – DA310 Featuring the widest variety of ports available, the compact 7-in-1 Dell USB-C Mobile Adapter – DA310 offers video, network, data connectivity, and up to 90W power pass-through for your laptop. The Dell USB-C Mobile Adapter is a compact and portable multiport 7-in-1 adapter that can connect to just about any device you have. Its downstream USB-C port supports power pass through and is ideal when your laptop does not have any more USB-C charging ports. Widest variety of ports: Featuring the widest range of ports available that includes 2 USB-A ports, 1 USB-C, 1 HDMI, 1 DisplayPort, 1 VGA and 1 RJ-45 port. The mobile adapter offers seamless connectivity to various devices like monitorsi, projectors, headsets, keyboard, mouse, flash drives and other accessories. Multi-functional USB-C port: With a USB-C downstream port that supports power pass through, video and data, you can connect to a monitor at up to 4K resolution at 30Hz, get up to SuperSpeed USB 10Gbps data transfer and 90W power pass throughi to your laptop. Crisp 4K resolution at 60Hz: Connect to high-resolution displays without compromising on performance, as the adapter supports 4K resolution at 60Hzi. Simply connect your monitor or projector to your PC via DisplayPort or HDMI 2.0 port on your adapter. SuperSpeed data transfers: Two USB-A and one USB-C downstream ports let you connect to other supported peripherals and enjoy fast file transfers up to 10 Gbps SuperSpeed
dimensionalWeight - 79
DisplayPort Input/Output connectors - 1
DisplayPortsquantity - 1
EAN - 5397184513637
EthernetLAN - Yes
EthernetLANRJ45ports - 1
GTIN - 0884116383482
GTIN - 884116383482
GTIN - 5397184513637
GTIN - 5704174403326
GTIN - 5704174403920
GTIN - 5704174934301
HDMI Input/Output connectors - 1
HDMIportsquantity - 1
HDMIversion - 2.0
Height - 24.5 mm
Height Retail box Dimensions - 69.8 mm
HighLights -
Hostinterface - USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Link - https://www.dell.com/en-uk/work/shop/dell-usb-c-mobile-adapter-da310/apd/470-aeup/pc-accessories#techspecs_section
Logistics data - Harmonized System (HS) code - 84733020
LongDesc -
LongDesc - Featuring the widest variety of ports available, the compact 7-in-1 Dell USB-C Mobile Adapter – DA310 offers video, network, data connectivity, and up to 90W power pass-through for your laptop.
LongProductName - Pro 7-in-1 USB-C Travel Hub - DA310
LongSummaryDescription - DELL Pro 7-in-1 USB-C Travel Hub - DA310. Connectivity technology: Wired, Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Silver, Maximum digital resolution: 3840 x 2160 pixels, Maximum analog resolution: 1920 x 1080 pixels. Power supply: 90 W, Power cable length: 0.12 m. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10...
Macoperatingsystemssupported - Yes
ManufDatasheet -
Microphonein - No
Model name - DA310
Name - Dell | USB-C Mobile Adapter | DA310
Network -
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Wake-on-LAN ready - Yes
Otheroperatingsystemssupported -
Packagedepth -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 86 mm
Package features > Gross depth master carton - 450 mm
Package features > Gross height (mm) - 131 mm
Package features > Gross height master carton - 275 mm
Package features > Gross width (mm) - 38 mm
Package features > Gross width master carton - 305 mm
Package features > Net weight master carton - 11.28 kg
Package features > Packing quantity - 60 pc(s)
Package features > Palette Qty - 2700 pc(s)
Package features > Paper/Pasteboard - 48.00 g
Package features > Plastic (No PET) - 12.00 g
Package features > Tare weight (kg) - 0.06 kg
Package features > Tare weight master carton - 0.377 kg
Package features > Volume (m3) - 0.000428108 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packageheight -
Packageweight -
Packagewidth -
Packaging content > Cables included - 1 x USB-C cable - integrated - 12 cm
Packagingdata -
Packaging data - Quantity per pack - 1 pc(s)
Performance -
Performance - Brand compatibility - Dell
Performance - Card reader integrated - No
Performance - Compatibility - - Latitude 7420 2-in-1
- Latitude 5520
- Latitude 7520
- Latitude 7320 2-in-1
- Latitude 5320 2-in-1
- Latitude 9410 2-in-1
- Precision 7550
- Precision 7750
- Latitude 5420 2-in-1
- Latitude 3310
- Precision 3560
- Latitude 7310
- Latitude 3310 2-in-1
- Latitude 9510
- Latitude 7210 2-in-1
- Latitude 7410
- XPS 13 (9310)
Performance - Maximum analog resolution - 1920 x 1080 pixels
Performance - Maximum digital resolution - 3840 x 2160 pixels
Performance - Plug and Play - Yes
Performance - Product colour - Silver
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - Host interface - USB 3.2 Gen 2 (3.1 Gen 2) Type-C
Ports & interfaces - Microphone in - No
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Ports & interfaces > Interface - Interfaces: 1 x USB; 1 x USB-C; 1 x display / video - HDMI; 1 x display / video - VGA; 1 x display / video - DisplayPort; 1 x network - Ethernet 1000 - RJ-45
Portsinterfaces -
Power -
Power - Power cable length - 0.12 m
Power - Power supply - 90 W
Powerconnector -
Powersourcetype -
Powersupply - 90 W
ProdDesc - Dell DA310 USB-C Mobile Adapter
producerCode - 470-AEUP
Producer product family - USB-C Mobile Adapter
Producer product name - DA310
Productcolour - Silver
Productcondition - Original
ProductHighLights -

• Wired
• Host interface: USB 3.2 Gen 2 (3.1 Gen 2) Type-C
• Ethernet LAN 10,100,1000 Mbit/s Wake-on-LAN ready
• Plug and Play

productName - DELL USB-C Mobile Adapter – DA310
ProductName - Pro 7-in-1 USB-C Travel Hub - DA310
Product Net Weight - 0.08 kg
ProductPicture - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_4.jpg
ProductPicture4 - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_5.jpg
ProductPicture5 - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_6.jpg
ProductPicture6 - https://www.tdbaltic.ee/images/products/DELL/470-AEUP_7.jpg
productSize - Normal
RJ45 Input/Output connectors - 1
Safety warning - Warnings - Do not block the ventilation of the appliance.
Safety warning - Warnings - Do not open the housing of the appliance.
ShortSummaryDescription - DELL Pro 7-in-1 USB-C Travel Hub - DA310, Wired, USB 3.2 Gen 2 (3.1 Gen 2) Type-C, 10,100,1000 Mbit/s, Silver, 3840 x 2160 pixels, 1920 x 1080 pixels
sizeX - 130
sizeY - 36
sizeZ - 85
Software -
Software - Linux operating systems supported - Yes
Software - Mac operating systems supported - Yes
Software - Windows operating systems supported - Windows 10
Software - Windows operating systems supported - Windows 10 Education
Software - Windows operating systems supported - Windows 10 Education x64
Software - Windows operating systems supported - Windows 10 Enterprise
Software - Windows operating systems supported - Windows 10 Enterprise x64
Software - Windows operating systems supported - Windows 10 Home
Software - Windows operating systems supported - Windows 10 Home x64
Software - Windows operating systems supported - Windows 10 IOT Core
Software - Windows operating systems supported - Windows 10 IoT Enterprise
Software - Windows operating systems supported - Windows 10 Pro
Software - Windows operating systems supported - Windows 10 Pro x64
Software - Windows operating systems supported - Windows 10 x64
Software - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64
Technical details > Gross weight - 0.188 kg
Technical details > Net weight - 0.128 kg
Technical details > Producer - Dell
Technical details > Type - USB-C Dock
Title - DELL Pro 7-in-1 USB-C Travel Hub - DA310
Unit Box Height - 0.035
Unit Box Length - 0.13
Unit Box Width - 0.085
Unit Calculated Volume - 0.0003867 cubm
Unit Calculated Weight - 0.19 kg
Units per Shipping Box - 1
URL - https://www.dell.com/
USB-C Input/Output connectors - 1
USB-C Interface - Yes
USB 3.1 Input/Output connectors - 2
USB32Gen131Gen1TypeAportsquant -
USB32Gen131Gen1TypeCportsquant -
Vendor Homepage - www.dell.com/en-uk/work/shop/dell-usb-c-mobile-adapter-da310/apd/470-aeup/pc-accessories
Warranty - 12
Warranty - 12 month(s)
Warranty - 36 months
Warrantyandmisc -
WarrantyInfo - 3 Years
warrantyLength - 36
warrantyType - F
Weight - 80 g
weight - 180
Weight & dimensions - Depth - 69.8 mm
Weight & dimensions - Height - 24.5 mm
Weight & dimensions - Weight - 80 g
Weight & dimensions - Width - 69.8 mm
Weightdimensions -
Width - 69.8 mm
Width Retail box Dimensions - 69.8 mm
Windowsoperatingsystemssupport - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64
