Raidsonic IB-DK4070-CPD USB Docking Station

Accessories included -
Brand - ICY BOX
BrandPartCode - 60806
Category - Laptop Docks & Port Replicators
Category - Root/Accessories | Exploitation/Cables and adapters/adapter/USB
Code - IB-DK4070-CPD
Color - Anthracite
Color - Black
Compatible with -
Description - ICY BOX
IB-DK4070-CPD USB Type-C Notebook
DockingStation   Key features
  Premium aluminium enclosure with twelve additional interfaces
Data transfer, video/audio and Power Delivery via one Type-C cable
1x High Speed HDMI interface with up to 3840x2160@30 Hz
1x High Speed HDMI and 1x VGA interface with up to1920x1080@60 Hz
3x USB 3.0 Type-A interfaces and 1x USB 2.0 Type-A interface
1x Type-C charging port for Power Delivery with up to 100 W, no data transfer
1x Ethernet RJ45 interface with up to 1000 Mbit/s
1x SD 2.0 and microSD 2.0 card reader with up to 25 MB/s
Single-LUN - the card reader works with one memory card at a time
1x 3.5 mm stereo combo jack for headset connection
dimension depth - 25 mm
dimension height - 220 mm
Dimensions -
dimension weight - 179 g
dimension width - 100 mm
Docking connector - No
EAN - 4250078171409
ean - 4250078171409
Eans - 4250078171409
GTIN - 4250078171409
guarantee - 24
guarantee_type - normal
I/O ports - 1 x 3,5 mm minijack (Combo)
I/O ports - 1 x D-Sub
I/O ports - 1 x RJ-45 (LAN)
I/O ports - 1 x USB 2.0 Type A
I/O ports - 1 x USB power
I/O ports - 2 x HDMI Type A
I/O ports - 3 x USB 3.0 Type A
Link - https://www.raidsonic.de/en/standards/searchresults.php?we_objectID=6205#technical_data
Logistics data - Harmonized System (HS) code - 84733020
Logistics data - Master (outer) case gross weight - 11.2 kg
Logistics data - Master (outer) case height - 280 mm
Logistics data - Master (outer) case length - 440 mm
Logistics data - Master (outer) case width - 330 mm
Logistics data - Products per master (outer) case - 60 pc(s)
LongDesc - Slim and elegantDue to the low height, the IB-DK4070-CPD is very handy as well as flexible for many situations. The integrated USB Type-C® cable can‘t get lost and you will always get a connection with the latest PCs, notebooks or mobile devices.LAN port – faster & saferWireless devices are already useful and applicable in many situations, but there are better options when high data transfer rates are required. Wired connections are more secure than wireless connections, i.e. they offer a lower risk, especially if you don‘t want to or cannot take full advantage of the security measures available via WLAN. Thus, an Ethernet interface is the best way to transfer files between devices with maximum transfer rate and security.Always informed!With two HDMI® and one VGA connection, the IB-DK4070-CPD provides up to three video interfaces of different resolutions, allowing simultaneous connection of HDMI® and VGA display devices in expansion mode. This is made possible by combining several current technologies such as DisplayLink™ and DisplayPort™ Alt Mode.
LongProductName - 12-in-1 USB Type-C
LongSummaryDescription - ICY BOX IB-DK4070-CPD. Connectivity technology: Wired, Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C, USB Power Delivery up to: 100 W. Ethernet LAN data rates: 1000 Mbit/s. Product colour: Anthracite, Black, Compatible memory cards: MicroSDXC, SDXC, Maximum memory card size: 2 TB. Power source type: USB. Other operating systems supported: ChromeOS
Name - Icy Box 12w1
name - ICY BOX IB-DK4070-CPD 12in1,2xHDMI,AUDIO,CR,V
Name - Raidsonic | USB Type-C Notebook DockingStation | IB-DK4070-CPD | Docking station | USB 3.0 (3.1 Gen 1) ports quantity | USB 2.0 ports quantity | HDMI ports quantity
Network - Ethernet LAN - Yes
Network - Ethernet LAN (RJ-45) ports - 1
Network - Ethernet LAN data rates - 1000 Mbit/s
Other features -
Other features - Cable length - 0.2 m
Other features > Colour - Anthracite/black
Other features > Compatible operating systems - Windows, macOS, Chrome OS
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 100 mm
Package features > Gross depth master carton - 455 mm
Package features > Gross height (mm) - 200.00 mm
Package features > Gross height master carton - 287 mm
Package features > Gross width (mm) - 25 mm
Package features > Gross width master carton - 335 mm
Package features > Net weight master carton - 11.04 kg
Package features > Packing quantity - 60 pc(s)
Package features > Palette Qty - 2340 pc(s)
Package features > Paper/Pasteboard - 60.00 g
Package features > Plastic (No PET) - 12.00 g
Package features > Tare weight (kg) - 0.07 kg
Package features > Tare weight master carton - 0.437 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Interface adapters included - USB Type-A male - USB Type-C female
Packaging content - Manual - Yes
Packaging data - Package depth - 25 mm
Packaging data - Package height - 200 mm
Packaging data - Package weight - 172 g
Packaging data - Package width - 100 mm
Packaging data - Quantity per pack - 1 pc(s)
Performance - Card reader integrated - Yes
Performance - Compatible memory cards - MicroSDXC, SDXC
Performance - Country of origin - China
Performance - HD type - 4K Ultra HD
Performance - Housing material - Aluminium, Plastic
Performance - LED indicators - Power
Performance - Maximum analog resolution - 1920 x 1080 pixels
Performance - Maximum digital resolution - 3840 x 2160 pixels
Performance - Maximum memory card size - 2 TB
Performance - Maximum refresh rate - 60 Hz
Performance - Product colour - Anthracite, Black
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Host interface - USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ports & interfaces - Microphone in - No
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 3
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Ports & interfaces - USB Power Delivery - Yes
Ports & interfaces - USB Power Delivery up to - 100 W
Ports & interfaces - USB Type-C DisplayPort Alternate Mode - Yes
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Ports & interfaces > Interface - 3x USB 3.0 Type-A, 1x USB 2.0 Type-A, 1x Type-C, 2x HDMI, 1x VGA, 1x MicroSDXC, 1x SDXC, 1x audio input, 1x Ethernet RJ45
Ports & interfaces > Output connections - USB Type-C
Power - Power source type - USB
Power > Power supply - 100 W
producer - IcyBox
Producer - ICY Box
ProducerCode - IB-DK4070-CPD
Producer product family - USB Type-C Notebook DockingStation
Producer product name - IB-DK4070-CPD
ProductName - IB-DK4070-CPD
ShortDescription - Stacja dokująca IB-DK4070-CPD 12w1,2xHDMI,AUDIO,CR,VGA
ShortSummaryDescription - ICY BOX IB-DK4070-CPD, Wired, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 100 W, 1000 Mbit/s, Anthracite, Black, MicroSDXC, SDXC
Software - Mac operating systems supported - Yes
Software - Other operating systems supported - ChromeOS
Software - Windows operating systems supported - Yes
System Requirements - Windows, macOS, Chrome OS
USB Type-C enabled Windows / macOS / Chrome
OS computer
Power Delivery, DP Alt Mode and/or DisplayLink (driver
support required!)
No power supply included (only necessary for
PowerDelivery).
Single-LUN - the card reader can only work with one
memory card at a time
The device is compatible with Thunderbolt 3 equipped
computers
Technical details > Gross weight - 0.184 kg
Technical details > Net weight - 0.112 kg
Technical details > Other features - HDMI interface with up to 3840x2160@30 Hz; HDMI and VGA interface with up to1920x1080@60 Hz; Single-LUN - the card reader works with one memory card at a time
Technical details > Producer - Raidsonic
Technical details > Type - Docking station
Technical details > Warranty - 12 year(s)
Title - ICY BOX IB-DK4070-CPD Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Anthracite, Black
URL - https://icybox.de/en/product.php?id=234
vendpn - IB-DK4070-CPD
Warranty - 12
Warranty - 12 month(s)
WarrantyInfo -
Weight - 0.172 kg
Weight & dimensions - Depth - 55 mm
Weight & dimensions - Height - 16 mm
Weight & dimensions - Weight - 100 g
Weight & dimensions - Width - 120 mm
