ARTIKEL1 - DH610 S1700 H610 BLACK 120W
ARTIKEL2 - GLN HDMI DISPLAY-PORT COM-PORT
Audio - Built-in speaker(s) - No
Brand - Shuttle
BrandPartCode - DH610
Breite - 0.25
Category - PC/Workstation Barebones
Category_1 - Computers and Laptops
Category_2 - Computers - Computers All in One
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Chassis type - 1.3L sized PC
Design - Cooling type - Active
Design - LED indicators - HDD, Power
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product type - Mini PC barebone
Design - VESA mounting - Yes
EAN - 887993005119
EANCode - 0887993005119
EAN_code - 0887993005119
Expansion slots - Number of M.2 (M) slots - 2
Graphics - Graphics card family - Intel
Graphics - Maximum resolution - 3840 x 2160 pixels
Graphics - Number of displays supported - 3
Graphics - On-board graphics card - Yes
Gross Weight Kg - 2,39
GRUPPE1 - Computer Systems
GRUPPE2 - PC Barebone
GTIN - 887993005119
GTIN - 0887993005119
HERSTELLER - SHUTTLE
Hoehe - 0.14
HSTNUMMER - DH610
Laenge - 0.26
LongDesc - 12th Gen Hybrid Power Makes Multitask EasyShuttle XPC Slim series DH610 supports Intel® 12th Gen LGA1700 processors. With Intel® new performance hybrid architecture and UHD graphics 700 series integrated, the model computes performance along with the potential for powering AI deployment. Support up to three displays via one HDMI 2.0b and two DisplayPort for display productivity and flexibility. Moreover, the model provides comprehensive connectivity with multiple ports, including four USB 3.2 Gen1 (Including one Type-C), four USB 2.0, two RS232, Intel® 2.5GbE + Intel® 1GbE LAN, and two M.2 expansion slots. DH610 can perform a reliable operation suitable for Office, Digital Signage, Kiosks, and other Multi-platform AI deployment.Intel® 12th Gen processorBased on the H610 chipset, DH610 is designed for 12th Gen Intel® processors in the LGA1700 socket and supports up to 64GB (32GBx2) of DDR4-3200 memory, which delivers a performance improvement uplift of up to 28%, providing powerful computing capacity. In addition, with Intel® UHD Graphics 700 series integrated, DH610 is potential for multi-platform AI deployment.Triple-Display ProductivityWith one HDMI 2.0b and two DisplayPort outputs built-in, DH610 supports three independent displays, providing productivity benefits and dynamic visualization for multitasking and digital signage applications.Strong Expansion Capacity with M.2With a native M.2 2280/2260/2242 Type M slot and an M.2 2230 Type E slot, DH610 offers considerably faster storage performance and expansion capacity for M.2 SSD and Wi-Fi modules.*M.2 2280 key M supports SATA 3.0 and PCIe 3.0 x 4 storage interfaces.Rich Connectivity and High-speed Intel® 2.5GbE LANDH610 provides four USB 3.2 Gen1 (Including one Type-C), four USB 2.0, and two RS232 for flexible connectivity options. In addition, Intel® 2.5 GbE and Intel® 1GbE Lan are equipped to support Wake on LAN and Teaming Mode functions to provide high-speed data transfer capability and a better business networking integration.Exclusive Cooling TechnologyDH610 features Shuttle’s exclusive heat-pipe cooling system with an intelligent fan design. The clever ventilation design allows constant air circulation between the inside and outside of the machine resulting in high stability and low noise for 24/7 long-term operation.
LongProductName - 1.3 L, H610, LGA1700, 2x DDR4 SODIMM, 2x M.2, 2.5", HDMI, 2x DP, 2x USB 3.2 Gen1, 2x USB 2.0, RJ45 GbE, RJ45 2.5 GbE, RS232, 120 W
LongSummaryDescription - Shuttle Slim PC DH610 , S1700, 1x HDMI, 2x DP , 1x 2.5", 2x M.2, 2x LAN (Intel 1G + 2.5G), 2x COM, 24/7 permanent operation, incl. VESA. Chassis type: 1.3L sized PC, Product type: Mini PC barebone. Processor socket: LGA 1700. Supported memory types: DDR4-SDRAM, Number of memory slots: 2, Maximum internal memory: 64 GB. Supported storage drive types: HDD & SSD, Storage drive interface: M.2, Serial ATA, Serial ATA II, Serial ATA III. Ethernet LAN (RJ-45) ports: 2. Cooling type: Active. Power supply: 120 W
Manufacturer - Shuttle
Manufacturer Code - DH610
Manufacturer Name - Shuttle
Manufacturer_code - DH610
Memory - Internal memory installed - No
Memory - Maximum internal memory - 64 GB
Memory - Memory slots type - SO-DIMM
Memory - Number of memory slots - 2
Memory - Supported memory clock speeds - 3200 MHz
Memory - Supported memory types - DDR4-SDRAM
Name - Shuttle XPC slim DH610, Barebone (black, without operating system)
Network - Ethernet LAN - Yes
Network - Wi-Fi - No
Packaging content - AC adapter included - Yes
Packaging content - Drivers included - Yes
Packaging content - Power cord included - Yes
Packaging content - Quick start guide - Yes
Performance - Number of processors supported - 1
Performance - Processor socket - LGA 1700
Ports & interfaces - COM ports quantity - 2
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0b
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Microphone in - Yes
Ports & interfaces - Number of SATA III connectors - 1
Ports & interfaces - USB 2.0 ports quantity - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 3
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Power - AC adapter output current - 6.32 A
Power - AC adapter output voltage - 19 V
Power - AC input voltage - 100 - 240 V
Power - Power supply - 120 W
Power - Power supply type - External AC adapter
Processor - Built-in processor - No
ProductName - Slim PC DH610 , S1700, 1x HDMI, 2x DP , 1x 2.5", 2x M.2, 2x LAN (Intel 1G + 2.5G), 2x COM, 24/7 permanent operation, incl. VESA
Short description - Shuttle Barebone XPC slim DH610 Black
ShortSummaryDescription - Shuttle Slim PC DH610 , S1700, 1x HDMI, 2x DP , 1x 2.5", 2x M.2, 2x LAN (Intel 1G + 2.5G), 2x COM, 24/7 permanent operation, incl. VESA, 1.3L sized PC, Mini PC barebone, LGA 1700, DDR4-SDRAM, M.2, Serial ATA, Serial ATA II, Serial ATA III, 120 W
Software - Linux operating systems supported - Yes
Software - Windows operating systems supported - Windows 10 x64, Windows 11 x64
Stck_Kart - 4
Stck_Pal - 24
Storage - Storage drive interface - M.2, Serial ATA, Serial ATA II, Serial ATA III
Storage - Storage drives installed - No
Storage - Storage drive sizes supported - 2.5"
Storage - Supported storage drive types - HDD & SSD
Storno - Y
Title - Shuttle Slim PC DH610 , S1700, 1x HDMI, 2x DP , 1x 2.5", 2x M.2, 2x LAN (Intel 1G + 2.5G), 2x COM, 24/7 permanent operation, incl. VESA
URL - https://tr.shuttle.com/products/productsDetail?productId=2677
WarrantyInfo -
Weight - 2,55
Weight & dimensions - Depth - 190 mm
Weight & dimensions - Height - 43 mm
Weight & dimensions - Width - 165 mm
