Asus TS100-E11-PI4 Intel C256 LGA 1200 (Socket H5) Tower Black

Brand - ASUS
BrandPartCode - 90SF02N1-M000Z0
Category - Server Barebones
Design - Certification - BSMI, CE, FCC(Class B)
Design - Chassis type - Tower
Design - LED indicators - Yes
Design - Product colour - Black
Design - Reset button - Yes
dimensionalWeight - 21674
Expansion slots - Number of M.2 (M) slots - 2
Expansion slots - PCI Express slots version - 4.0
GTIN - 4711081886457
LongDesc - Intel® Xeon® E workload-optimized server flexible storage expandabilityIntel Xeon E-2300 processorsSmall businesses require reliability and security to support their critical business and customer data needs. Available with up to eight cores and featuring a TDP of up to 95 watts, Intel Xeon E-2300 processors deliver essential server performance, expandability and reliability small businesses to support critical business and customer data needs.PCIe 4.0 ReadyPCI Express® (PCIe®) 4.0 delivers 16 GT/s bandwidth, which is double the speed of PCIe 3.0, offering lower power consumption, better lane scalability and backwards compatibility. ASUS TS100-E11-PI4 servers are PCIe 4.0 ready to support a diverse array of graphics, storage and networking – enabling flexible scalability for demanding or increasing workloads.Enhanced securityASUS TS100-E11-PI4 servers integrate PFR FPGA as the platform Root-of-Trust solution for firmware resiliency to prevent from hackers from gaining access to infrastructure. ASUS security solutions are fully compliant with the 2018 National Institute of Standards and Technology (NIST) SP 800 193 specification.In addition, all TS100-E11-PI4 servers also include support Trusted Platform Module 2.0 (TPM 2.0) to secure hardware through integrated cryptographic keys and offer regular firmware update for vulnerabilities.* Platform Firmware Resilience (PFR) module must be specified at time of purchase and is factory-fitted. It is not for sale separately.High-resolution HDMI monitoringTS100-E11-PI4 features a HDMI 1.4 port directed from CPU to offer higher-resolution monitoring and easier maintenance for IT administrators in business environments. A VGA port directed from BMC is also available for dual-display monitoring.Dual Ethernet BandwidthFeaturing dual onboard LAN ported by Intel I210-AT Ethernet Controller, TS100-E11-PI4 servers provide server-grade connectivity and supports high-density, high-bandwidth, low-latency access-layer networks to ensure faster transfers of large-size files used in data-intensive applications.Server-management SolutionASUS ASMB10-iKVMASUS ASMB10-iKVM is the latest server-management solution from ASUS, built upon the ASPEED 2600 chipset running on the latest AMI MegaRAC SP-X. The module provides various interfaces to enable out-of-band server management through WebGUI, Intelligent Platform Management Interface (IPMI) and Redfish® API.ASUS Control CenterASUS Control Center (ACC) is a centralized and integrated IT-management platform for monitoring and controlling ASUS servers, workstations and mini PCs. ACC enables remote BIOS updates, monitoring of multiple systems via mobile devices, and one-click software updates and dispatching, allowing easier server management for any IT infrastructure.
LongProductName - Socket LGA1200, Intel C256, max 128GB UDIMM, 2 x Intel I210AT + 1 x Mgmt LAN, 11.56 kg, 300W
LongSummaryDescription - ASUS TS100-E11-PI4. Motherboard chipset: Intel C256, Processor socket: LGA 1200 (Socket H5), Processor manufacturer: Intel. Supported memory types: DDR4-SDRAM, Supported DIMM module capacities: 8GB, 16GB, 32GB, Maximum internal memory: 128 GB. Storage drive sizes supported: 2.5,3.5,M.2, Supported storage drive types: HDD & SSD, SSD form factor: M.2. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Chassis type: Tower, Product colour: Black, Certification: BSMI, CE, FCC(Class B)
Memory - Buffered memory type - Unregistered (unbuffered)
Memory - ECC - Yes
Memory - Maximum internal memory - 128 GB
Memory - Memory channels - Dual-channel
Memory - Number of DIMM slots - 4
Memory - Supported DIMM module capacities - 8GB
Memory - Supported DIMM module capacities - 8GB, 16GB, 32GB
Memory - Supported DIMM module capacities - 16GB
Memory - Supported DIMM module capacities - 32GB
Memory - Supported memory types - DDR4-SDRAM
Memory - Supported UDIMM clock speeds - 3200 MHz
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet interface type - Fast Ethernet, Gigabit Ethernet
Network - Ethernet interface type - Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000 Mbit/s
Operational conditions - Operating temperature (T-T) - 10 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 20 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging data - Package weight - 14.7 kg
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Microphone in - Yes
Ports & interfaces - Number of SATA III connectors - 8
Ports & interfaces - PS/2 ports quantity - 1
Ports & interfaces - USB 2.0 ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 4
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 2
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC input frequency - 50 - 60 Hz
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power supply - 300 W
Processor - Built-in processor - No
Processor - Motherboard chipset - Intel C256
Processor - Number of processors supported - 1
Processor - Processor family - Intel® Xeon®
Processor - Processor manufacturer - Intel
Processor - Processor socket - LGA 1200 (Socket H5)
producerCode - 90SF02N1-M000Z0
productName - ASUS TS100-E11-PI4 Intel C256 LGA 1200 (Socket H5) Tower Black
ProductName - TS100-E11-PI4
productSize - Normal
ShortSummaryDescription - ASUS TS100-E11-PI4, Intel C256, LGA 1200 (Socket H5), Intel, Intel® Xeon®, DDR4-SDRAM, 8GB, 16GB, 32GB
sizeX - 650
sizeY - 585
sizeZ - 285
Storage - Number of 2.5" bays - 1
Storage - Number of 3.5" bays - 3
Storage - SSD form factor - M.2
Storage - Storage drive sizes supported - 2.5
Storage - Storage drive sizes supported - 2.5,3.5,M.2
Storage - Storage drive sizes supported - 3.5"
Storage - Storage drive sizes supported - M.2
Storage - Supported storage drive types - HDD & SSD
Title - ASUS TS100-E11-PI4 Intel C256 LGA 1200 (Socket H5) Tower Black
URL - https://servers.asus.com/products/servers/tower-servers/TS100-E11-PI4#Features
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 13370
Weight & dimensions - Depth - 423 mm
Weight & dimensions - Height - 435 mm
Weight & dimensions - Weight - 11.6 kg
Weight & dimensions - Width - 190 mm
