Accessories included - BSH01 Monitor arm Reinforcement plate Warranty card Quick start guide Regulation sheet Spare parts
Brand - BenQ
BrandPartCode - 9H.A3ADD.LWW
Category - Monitor Mounts & Stands
Color - White
Corner mount - No
Description - BenQ Ergo Arm Board Compatibility: Fits screens up to 45 inches and 4 to 44 lbs, VESA compatibility for 75x75mm and 100x100mm patterns. Consistent Sturdiness: Built with an optimized tilt structure and gas spring tested for 25,000 cycles, ensures reliable support and prevents sagging for long-lasting performance. Desk Protection: Steel Monitor Mount Reinforcement Plate for Thin, Glass and Other Fragile Tabletop, Steel Bracket Plate protects desk from scratches and deformation, providing long-term surface protection
Design - Easy to install - Yes
Design - Product colour - White
Designation - CE+WEEE
dimension depth - 140 mm
dimension height - 440 mm
Dimensions -
dimension weight - 5000 g
dimension width - 135 mm
ean - 4718755096785
Ergonomics - Angle of rotation - 180°
Ergonomics - Cable management - Yes
Ergonomics - Height adjustment - Yes
Ergonomics - Height adjustment range - 220.98 - 474.98 mm
Ergonomics - Height adjustment type - Manual
Ergonomics - Rotating - Yes
Ergonomics - Swivel angle range - -90 - 90°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -20 - 50°
GTIN - 4718755096785
guarantee - 24
guarantee_type - external
Load (max) - 20 kg
LongDesc - Handles Any Monitor, Any Weight4 to 44 lbs Weight Capacity to Support Your Monitor, Even with a Webcam and Light BarThe Wrong Monitor Arm Could BackfireSinkingMonitor slips downwardSaggingMonitor won’t stay at the angleDesk DamageRisk of scratches and cracksHold Monitors from 4 to 44 lbsA Gas Spring Monitor Stand Ensure Steady, Long-Lasting Support for Monitors and Additional GearAdvanced Tilt StructureThe Premium spring mechanism keeps your screen securely in place unlike standard locking features.Thin or Glass Tabletops? We Got YouA Reinforcement Plate prevents desk damage and Helps reduce scratches and deformation on tabletopsThoughtful Design for Seamless Setup2-Way InstallationC Clamp or grommet Mounting based on desk type, both ways are top mounting!Preset TensionPre-adjusted weight settings ensure stability during initial setupCable ManagementIntegrated cable management to keep desk setup neat and organizedWe Keep it Sturdy, You Enjoy it SimplyFrom Trusted Monitor Experts, Offering Universal Monitor Arm With Full Protection and SupportA New Desk Space in 3 StepsMount with EaseTop mounting on desks makes setup easyAssemble QuicklyPre-installed components for faster installationAttach Your Monitor FastQuick-release VESA allows swift screen mounting
LongProductName - Max 45", 2 - 20 kg, VESA 100x100/75x75, 4.43Kg, White
LongSummaryDescription - BenQ Ergo Arm BSH02. Mounting: Clamp/Grommet, Maximum weight capacity: 20 kg, Minimum screen size: 43.2 cm (17"), Maximum screen size: 114.3 cm (45"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 100 x 100 mm. Height adjustment, Swivel angle range: -90 - 90°, Tilt angle range: -20 - 50°. Product colour: White
Mounting - Desk thickness (max) - 5 cm
Mounting - Desk thickness (min) - 1.7 cm
Mounting - Extension arm (max) - 48.2 cm
Mounting - Maximum screen size - 114.3 cm (45")
Mounting - Maximum VESA mount - 100 x 100 mm
Mounting - Maximum weight capacity - 20 kg
Mounting - Maximum weight capacity (per display) - 20 kg
Mounting - Minimum screen size - 43.2 cm (17")
Mounting - Minimum VESA mount - 75 x 75 mm
Mounting - Mounting - Clamp/Grommet
Mounting - Mounting type - Desk
Mounting - Number of displays supported - 1
name - Uchwyt BSH02 9H.A3ADD.LWW
Other features -
Packaging data - Quantity per pack - 1 pc(s)
producer - Benq
ProductName - BenQ Ergo Arm BSH02
Range (max) - 56.8 cm
Range adjustment - Yes
rotation - 180 °
Screen size (max) - 45 ''
ShortSummaryDescription - BenQ Ergo Arm BSH02, Clamp/Grommet, 20 kg, 43.2 cm (17"), 114.3 cm (45"), 100 x 100 mm, White
Stuff - Steel
Title - BenQ Ergo Arm BSH02 114.3 cm (45") Desk White
Type - Desk
URL - https://www.benq.eu/en-eu/desk-tech/monitorarm/bsh02/buy.html
Usage - Monitors
vendpn - 9H.A3ADD.LWW
Vertical adjustment - 50 °
VESA - 75 x 75
VESA - 100 x 100
WarrantyInfo -
Weight & dimensions - Depth - 573 mm
Weight & dimensions - Height - 548 mm
Weight & dimensions - Weight - 4.43 kg
Weight & dimensions - Width - 130 mm
