Incase 2-Port USB 3.0 4K HDMI Dual Display KVMP Switch | CS1842

Brand - ATEN
BrandPartCode - CS1842-AT-G
Category - KVM Switches
Code - CS1842-AT-G
Design - Hot keys - Yes
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Design - Push button - Yes
Display - Built-in display - No
EAN - 4710469340031
GTIN - 4710469340031
Link - https://www.aten.com/eu/en/products/kvm/desktop-kvm-switches/cs1842/
Logistics data - Harmonized System (HS) code - 85176200
Logistics data - Master (outer) case gross weight - 11.5 kg
Logistics data - Master (outer) case height - 258 mm
Logistics data - Master (outer) case length - 565 mm
Logistics data - Master (outer) case net weight - 8.25 kg
Logistics data - Master (outer) case width - 375 mm
Logistics data - Products per master (outer) case - 3 pc(s)
LongDesc - 1x CS1842 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch4x LIN6-19V1-V18G HDMI 2.0 Cables 2x LIN6-11C1-E12G USB 3.0 Cables2x LIN5-0205-21CG Speaker Cables2x LIN5-0205-21DG Microphone Cables 1x 0AD8-8012-33MG Power Adapter1x 2XRT-0016G Remote Port Selector1x User Instructions
LongProductName - 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch
LongSummaryDescription - ATEN 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: 4K Ultra HD, Maximum resolution: 4096 x 2160 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal. Power source: DC, Input voltage: 12 V, Power consumption (typical): 3.17 W. Width: 335 mm, Depth: 160.5 mm, Height: 44 mm
Name - Aten 2-Port USB 3.0 4K HDMI Dual Display KVMP Switch | CS1842
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 335 mm
Package features > Gross height (mm) - 44 mm
Package features > Gross width (mm) - 160.5 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 118 pc(s)
Package features > Paper/Pasteboard - 641.60 g
Package features > Plastic (No PET) - 160.40 g
Package features > Tare weight (kg) - 0.80 kg
Package features > Volume (m3) - 0.00236577 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Manual - Yes
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 540 mm
Packaging data - Package height - 233 mm
Packaging data - Package weight - 3.52 kg
Packaging data - Package width - 116 mm
Performance - HD type - 4K Ultra HD
Performance - Maximum resolution - 4096 x 2160 pixels
Performance - Scan interval - 1,5,99 s
Performance - Video bandwidth - 60 Hz
Ports & interfaces - Audio connections - Yes
Ports & interfaces - Console ports - 3.5mm headphone, HDMI, USB A
Ports & interfaces - Console USB ports quantity - 2
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Headphone outputs - 4
Ports & interfaces - Keyboard port type - USB
Ports & interfaces - Mouse port type - USB
Ports & interfaces - Number of computers controlled - 2
Ports & interfaces - Number of microphone inputs - 4
Ports & interfaces - USB 2.0 Type-A hub ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity - 2
Ports & interfaces - USB connector type - USB Type-A, USB Type-B
Ports & interfaces - USB hub - Yes
Ports & interfaces - Video port type - HDMI
Power - Input voltage - 12 V
Power - Power consumption (typical) - 3.17 W
Power - Power source - DC
ProductName - 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch
ShortSummaryDescription - ATEN 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch, 4096 x 2160 pixels, 4K Ultra HD, 3.17 W, Black
System requirements - Windows operating systems supported - Yes
Technical details > Gross weight - 2.402 kg
Technical details > Net weight - 1.6 kg
Technical details > Producer - Aten
Technical details > Producer product family - 2-Port USB 3.0 4K HDMI Dual Display KVMP Switch
Technical details > Producer product name - CS1842
Title - ATEN 2-Port USB 3.0 4K HDMI Dual Display KVMP™ Switch
URL - https://www.aten.com/eu/en/products/kvm/desktop-kvm-switches/cs1842/
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 160.5 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 2.75 kg
Weight & dimensions - Width - 335 mm
