Startech P4AD122-KVM-SWITCH 4-PORT DISPLAYPORT KVM SWITCH

ARTIKEL1 - P4AD122-KVM-SWITCH
ARTIKEL2 - 4-PORT DISPLAYPORT KVM SWITCH
Brand - StarTech.com
BrandPartCode - P4AD122-KVM-SWITCH
Breite - 0
Category - KVM Switches
Design - Hot keys - Yes
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Mean time between failures (MTBF) - 130000 h
Design - Product colour - Black
Design - Push button - Yes
Design - Rack mounting - Yes
Display - Built-in display - No
Display - On Screen Display (OSD) - No
EANCode - 0065030903264
GRUPPE1 - Network
GRUPPE2 - KVM Switch Entry Level
GTIN - 0065030903264
GTIN - 065030903264
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - P4AD122-KVM-SWITCH
Laenge - 0
Logistics data - Master (outer) case height - 300 mm
Logistics data - Master (outer) case length - 322 mm
Logistics data - Master (outer) case width - 516 mm
Logistics data - Products per master (outer) case - 6 pc(s)
LongDesc - Share a mouse, keyboard, USB 5Gbps hub, audio output device, and 4K 60Hz DisplayPort display between four DisplayPort-enabled computersThis DisplayPort KVM Switch enables users to switch between four desktops equipped with USB-A and DisplayPort. It facilitates sharing a 4K 60Hz DisplayPort monitor, a keyboard, mouse, two USB 5Gbps devices, a stereo audio output device, and four USB 2.0 devices.High-Resolution 4K 60Hz VideoThis KVM supports resolutions up to 4K 60Hz, making it ideal for applications such as CAD/CAM, video editing, and content creation. In addition, its support for High Dynamic Range (HDR) enhances contrast, brightness, color, and overall vibrancy.Customizable SwitchingThis universal KVM switch offers hotkey and push-button switching. Hotkeys allow independent switching of audio and video, enabling audio playback from one computer while controlling another. An audible buzzer confirms hotkey inputs, and LEDs provide visual status feedback for the selected host.Universal CompatibilityThe TAA-compliant KVM Switch offers universal compatibility and works with all operating systems, including Windows, macOS, ChromeOS, and Linux. The KVM provides BIOS/UEFI control and is compatible with all hardware platforms, including Intel, AMD, and Apple Silicon (M1/M2/M3).Reliable PerformanceThe rugged metal case helps prevent electromagnetic interference (EMI). 8kV Air/6kV Contact ESD protection enhances the reliability and longevity of the KVM. The included set of rubber feet protect the work surface from scratches and keep KVM in place during operation.Rackmount your KVM switchIf you'd like to mount this KVM switch to your server rack, we offer a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.
LongProductName - StarTech 4-Port DisplayPort KVM Switch, Single 4K 60Hz Monitor, 6x USB Ports, Hotkey Switching, TAA Compliant
LongSummaryDescription - StarTech.com 4-Port DisplayPort KVM Switch, Single 4K 60Hz Monitor, 6x USB Ports, Push-Button & Hotkey Switching, DisplayPort 1.2, OS Independent, TAA Compliant. Keyboard port type: USB, Mouse port type: USB, Video port type: DisplayPort. HD type: 4K Ultra HD, Maximum resolution: 4096 x 2160 pixels, Data transfer rate (max): 5 Gbit/s. Product colour: Black, Housing material: Metal, Mean time between failures (MTBF): 130000 h. Power source: DC, Input voltage: 100 - 240, 12 V, Input current: 1 A. Compliance certificates: RoHS, Trade Agreements Act (TAA)
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -10 - 60 °C
Other features - Colour depth - 10 bit
Other features - Display resolution at frequency - 3840x2160 @ 60hz
3840x2160 @ 30hz
2560x1600 @ 60hz
2560x1600 @ 30hz
2560x1440 @ 60hz
2048x1536 @ 60hz
2048x1536 @ 30hz
1920x1440 @ 60hz
1920x1200 @ 60hz
1920x1080 @ 60hz
1680x1050 @ 60hz
1600x1200 @ 60hz
1600x1024 @ 60hz
1600x900 @ 60hz
1440x1080 @ 60hz
1366x768 @ 60hz
1360x768 @ 60hz
1280x1024 @ 60hz
1280x960 @ 60hz
1280x800 @ 60hz
1280x768 @ 60hz
1280x720 @ 60hz
1176x664 @ 60hz
1152x864 @ 60hz
1024x768 @ 60hz
800x600 @ 60hz
Other features - IP control - No
Packaging content - Quick installation guide - Yes
Packaging content - Rubber feet - Yes
Packaging data - Package depth - 246 mm
Packaging data - Package height - 88 mm
Packaging data - Package weight - 1.2 kg
Packaging data - Package width - 297 mm
Performance - Audio channels - 2.0
Performance - Chipset - GL3523
Performance - Data transfer rate (max) - 5 Gbit/s
Performance - HDCP - Yes
Performance - HDCP version - 1.4
Performance - HD type - 4K Ultra HD
Performance - Maximum resolution - 4096 x 2160 pixels
Performance - Plug and Play - Yes
Performance - Scan interval - 3,8,15,30 s
Ports & interfaces - Audio connections - Yes
Ports & interfaces - Console DisplayPorts ports quantity - 1
Ports & interfaces - Console ports - 3.5mm headphone, DisplayPort, USB A
Ports & interfaces - Console USB ports quantity - 4
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 4
Ports & interfaces - DisplayPort version - 1.2
Ports & interfaces - Headphone outputs - 4
Ports & interfaces - Keyboard port type - USB
Ports & interfaces - Mouse port type - USB
Ports & interfaces - Number of computers controlled - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity - 2
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity - 4
Ports & interfaces - USB hub - Yes
Ports & interfaces - Video port type - DisplayPort
Power - Compatible power plug types - AU, EU, UK, US
Power - Input current - 1 A
Power - Input voltage - 100 - 240, 12 V
Power - Output current - 3 A
Power - Power consumption (typical) - 36 W
Power - Power plug type - Type M
Power - Power source - DC
ProductName - 4-Port DisplayPort KVM Switch, Single 4K 60Hz Monitor, 6x USB Ports, Push-Button & Hotkey Switching, DisplayPort 1.2, OS Independent, TAA Compliant
ShortSummaryDescription - StarTech.com 4-Port DisplayPort KVM Switch, Single 4K 60Hz Monitor, 6x USB Ports, Push-Button & Hotkey Switching, DisplayPort 1.2, OS Independent, TAA Compliant, 4096 x 2160 pixels, 4K Ultra HD, Rack mounting, 36 W, Black
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Sustainability - Compliance certificates - RoHS, Trade Agreements Act (TAA)
Sustainability - Sustainability compliance - Yes
Title - StarTech.com 4-Port DisplayPort KVM Switch, Single 4K 60Hz Monitor, 6x USB Ports, Push-Button & Hotkey Switching, DisplayPort 1.2, OS Independent, TAA Compliant
URL - https://www.startech.com/en-us/P4AD122-KVM-SWITCH
WarrantyInfo - 2 Years
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 1 kg
Weight & dimensions - Width - 130 mm
