Corsair FRAME 4500X LX-R RGB iCUE LINK, Panoramic Tempered Glass, White

category - Cases & Modding
Chassis type - Midi Tower
code - CC-9011317-WW
Color - White
Compatible power supply standard - ATX
Computer case backlight - RGB
Cooling - Bottom fans installed - 1x 120 mm
Cooling - Rear fans installed - 1x 140 mm
Cooling - Side fans installed - 2x 140 mm
Cooling - Side radiator sizes supported - 360
Cooling - Top fans installed - 2x 140 mm
Cooling - Top radiator sizes supported - 360 mm
Description - FRAME 4500X LX-R RGB iCUE LINK Mid-Tower PC Case - White Single-piece curved front and side panels InfiniRail fan mounting system for easier builds Dual 360 mm radiator support 3 iCUE LINK LX-R RGB 120 mm reverse-blade fans included GPU anti-sag bracket Compatible with motherboards with reversed connectors Included iCUE LINK system hub provides full digital control of connected devices PANORAMIC GLASS SIDE PANEL
A single piece of curved tempered glass allows an unobstructed view of your build, with no seams or sharp edges blocking the interior. The curved glass wraps around the front and side of the case for a clear display of your components. The tempered glass side panel is laminated with an almost invisible safety film, providing both protection and noise reduction. CORSAIR INFINIRAIL FAN MOUNTING SYSTEM
This multi-point steel fan mounting system provides unparalleled flexibility for top-mounted fans. Simply slide the rail to install 120 mm or 140 mm fans exactly where needed, ensuring targeted airflow without the limitations of fixed mounting. LX-R REVERSE-BLADE FANS INCLUDED
The iCUE LINK LX-R RGB intake fans with reverse blades offer single-cable connectivity, unobstructed RGB lighting, and quiet cooling. Fresh air is drawn in through the ventilated side into the spacious mid-tower, delivering effective cooling and high airflow for maximum performance. The included color-matched iCUE LINK system hub makes it easy to add more LINK fans to your system, supporting up to 24 devices on a single hub. VENTILATED SIDE AND TOP PANELS
Optimized for airflow, the top and side panels provide maximum ventilation for fans installed in both locations. Side-mounted intake fans draw cool air from outside the case, while top-mounted fans (sold separately) exhaust hot air to maintain a cool interior. CABLE-FREE DESIGN
Compatible with ASUS BTF, MSI Project Zero, and GIGABYTE Project Stealth motherboards, featuring multiple cutouts and mounting points to keep cables organized, even in hidden areas. DIY-FRIENDLY FEATURES
The FRAME 4500X includes practical features to simplify PC building: VERTICAL GPU MOUNT READY
Display your graphics card front and center with easy vertical installation, no tools or bracket required (riser cable sold separately). GPU ANTI-SAG BRACKET
Keeps your GPU stable, preventing stress on the PCIe slot. REUSABLE SCREW BOX
Store all necessary screws safely in the included box, so you never lose an important fastener. MULTIPLE COOLING OPTIONS
Customize your cooling setup with space for up to ten 120 mm fans and multiple mounting options for dual 360 mm radiators simultaneously. SPACIOUS INTERIOR
The FRAME 4500X provides ample room to house and cool even the most ambitious PC builds. FAN SUPPORT
Ensure peak performance with solid airflow surrounding your components from all sides. RADIATOR SUPPORT
Multiple mounting locations allow for liquid cooling installation, providing quiet operation and low operating temperatures. MODERN FRONT I/O PANEL
Easy access to modern ports, including one USB 3.2 Gen 2 Type-C, two USB 3.2 Gen 1 Type-A ports, and integrated 3.5 mm audio and microphone jacks.
Design - Form factor - Midi Tower
Design - Maximum CPU cooler height - 18.5 cm
Design - Maximum PSU length - 25 cm
Design - Number of 2.5" bays - 2
Design - Number of 3.5" bays - 1
Design - Product colour - White
Design - Type - PC
Designation - CE+WEEE
dimensionalWeight - 21436
dimension depth - 560 mm
dimension height - 330 mm
Dimensions - 478 x 499 x 246 mm
dimension weight - 11500 g
dimension width - 580 mm
Drive bays 2.5'' intern. - 2
Drive bays 3.5'' intern. - 1
ean - 0840440402800
ean - 840440402800
Fans installed - 3 x 120 mm RGB (side)
Form-factor - ATX
Form-factor - E-ATX
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x mic/headphone (combo)
Front panel connectors - 1 x UB1 x USB 3.2 Gen 2 Type-CavS 3.2 Gen 2 Type-C
Front panel connectors - 2 x USB 3.2 Gen1
Front panel connectors - Power
guarantee - 24
guarantee_type - normal
Maximum CPU cooling height - 185 mm
Maximum length of the graphics card - 460 mm
Maximum length of the power supply - 250 mm
Maximum number of fans - 10
name - Case FRAME 4500X LXR RGB White Mid Tower ATX
name - Corsair FRAME 4500X LX-R RGB PC-Gehäuse, Midi-Tower, E-ATX, Tempered Glass - weiß
No. of drive bays - 3
Number of fans installed - 3
Number of slots for expansion cards - 7
Ooptional water cooling - 1 x 120 mm (back)
Ooptional water cooling - 1 x 140 mm (back)
Ooptional water cooling - 1 x 240 mm (góra)
Ooptional water cooling - 1 x 240 mm (side)
Ooptional water cooling - 1 x 280 mm (góra)
Ooptional water cooling - 1 x 280 mm (side)
Ooptional water cooling - 1 x 360 mm (side)
Ooptional water cooling - 1 x 360 mm (top)
Optional fans - 1 x 120 mm or 1 x 140 mm (rear)
Optional fans - 3 x 120 mm lub 1 x 140 mm (bottom)
Optional fans - 3 x 120 mm or 2 x 140 mm (side)
Optional fans - 3 x 120 mm or 2 x 140 mm (top)
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 2
Ports & interfaces - USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity - 1
producer - Corsair
producerCode - CC-9011317-WW
productName - Corsair 4500X LX-R RGB Tempered Glass Mid-Tower, White Midi Tower
productSize - Normal
Side panel - Tempered Glass
sizeX - 330
sizeY - 580
sizeZ - 560
vendpn - CC-9011317-WW
warrantyLength - 24
warrantyType - G
Weight - 11.68 kg
weight - 11200
Weight & dimensions - Depth - 542 mm
Weight & dimensions - Height - 556 mm
Weight & dimensions - Width - 250 mm
