10/100/1000/2500 Mbps ports - 4
Accessories included -
Application - Medium and large companies
ARTIKEL1 - 28-P SMART MANAGED POE+ SWITCH
ARTIKEL2 - GIGABIT STACKABLE 4X10G 4X2.5
Brand - D-Link
BrandPartCode - DGS-1520-28MP/E
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Certificates - CE Class A FCC Class A IC Class A RCM Class A VCCI Class A BSMI Class A
Chassis type - Rack
Console port - Yes
Data transmission - Forwarding rate - 104.16 Mpps
Data transmission - Jumbo frames - 12288
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16384 entries
Data transmission - Static route - Yes
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 140 Gbit/s
Description - Smart L3 Managed Stackable Switches DGS-1520 Series Stacking Physically stacking up to 8 switches for expansion and redundancy. Touchless installation Seamless multi-site deployment with automatic configuration download. Large PoE budget Power over Ethernet (PoE) budget up to 370W allows you to power multiple devices. 10G connections Four 10-gigabit ports for stacking or uplinking. Multi-gigabit PoE ports Four 2.5G PoE ports, ideal for Gigabit Wi-Fi 6 access points. Redundant power An optional redundant power supply ensures uninterrupted operation. Advanced L2 and L3 features Easily adapt to network changes with selectable Q-in-Q, VRRP, RIP and OSPF features. Limited Lifetime Guarantee Register your product to take advantage of Lifetime Limited's lifetime warranty. A new dimension in Managed Smart Switches Expandable network with high-performance 10-gigabit stackable switches to increase productivity and uptime. x8 Eight connected switches form a redundant stack with up to 384 gigabit ports. 188Gbps High throughput data transfer between connected devices at up to 188 Gbps. x4 Four 2.5G PoE ports (PoE models), ideal for Wi-Fi 6 access points. High availability Simplification of management and cabling increases the efficiency and reliability of the network. Physical stacking up to 8 switches with a total bandwidth of 80G. Designed with Wi-Fi 6 in mind The multi-gigabit 2.5G ports on the DGS-1520 series PoE switches eliminate potential bottlenecks in connecting to WiFi 6 gigabit access points. Touchless deployments For multi-site network expansion, the latest firmware and network configurations for the DGS-1520 series switches can be downloaded without the need to involve on-site IT personnel, making deployments easier and faster. Advanced L2 and L3 features Advanced, selected software features - Q-in-Q, VRRP, RIP and OSPF enable adaptation to changes in the network. For businesses with increasing bandwidth and network expansion requirements, the DGS-1520 series switches are a cost-effective upgrade option with 10-gigabit connections for network infrastructure. Hybrid staking Stack up to eight DGS-1520 switches using 10GBASE-T copper and/or SFP+ fiber ports. Hybrid stacking support increases cabling capability and lower cost by using copper instead of fiber. Simplified management Centrally manage multiple large networks with wired or wireless devices using D-View 7 to reduce cost and maintenance. There is also a D-Link Network Assistant (DNA) available to simplify setup and management of smaller networks.
Design - Form factor - 1U
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimension depth - 105 mm
dimension height - 480 mm
Dimensions - 441 x 308.5 x 44 mm
dimension weight - 6100 g
dimension width - 520 mm
ean - 790069472008
EAN - 0790069472008
EANCode - 0790069472008
Environment requirements - Operating temperature: -5 - 50°C Storage temperature: -40 - 70°C Operating Humidity: 10% - 95% RH Storage humidity: 5% - 95% RH
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 104.16 Mpps
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0790069472008
GTIN - 790069472008
guarantee - 0
guarantee_type - perpetual
HERSTELLER - D-LINK
HSTNUMMER - DGS-1520-28MP/E
Jumbo frame size - 12 KB
L2 features - MAC Address Table: 16,384 entries Jumbo Frames up to 12,288 Bytes 802.1AX/802.3ad Link Aggregation: Max. 32 groups per device, 8 ports per group Loopback Detection Flow mirroring: Supports Ingress Mirroring only VLAN Mirroring RSPAN L2 Protocol Tunneling Ethernet Ring Protection Switching (ERPS) v1/v2 Flow Control: 802.3x Flow Control HOL Blocking Prevention Spanning Tree Protocols: 802.1D STP 802.1w RSTP 802.1s MSTP BPDU Filtering Root Guard Loop Guard Port Mirroring: Supports One-to-One, Many-to-One Supports Mirroring for both Tx/Rx Supports 4 mirroring groups L2 Multicasting IGMP Snooping: IGMP v1/v2/v3 Snooping Supports 512 IGMP groups Host-based IGMP Snooping Fast Leave Supports 128 static IGMP groups Per VLAN IGMP Snooping Data Driven Learning IGMP Snooping Querier Report Suppression MLD Snooping: MLD v1/v2 Snooping Support 256 MLD Groups Host-based MLD Snooping Fast Leave Supports 64 static MLD groups MLD Snooping Querier Per VLAN MLD Snooping MLD Proxy Reporting
L3 features - IPv4 ARP Entries: 8192 256 Static ARP IPv6 ND Entries:4096 128 Static ND Entries IP Interface: Supports 16 interfaces Gratuitous ARP Loopback Interface Proxy ARP: Support local ARP proxy VRRP v2/v3 IP Helper L3 Routing Supports 1024 hardware routing entries shared by IPv4/IPv6: 1 entry consumed by each IPv4 route 2 entries consumed by each IPv6 route Supports up to 4096 hardware L3 forwarding entries shared by IPv4/IPv6: 1 entry consumed by each IPv4 route 2 entries consumed by each IPv6 route IPv4/IPv6 Static Route: Max. 512 IPv4 entries Max. 256 IPv6 entries Equal-Cost Multi-Path Route (ECMP) Weighted-Cost Multi-Path Route (WCMP) IPv4/IPv6 Default Route Policy-based Route (PBR) Null Route Route Preference Route Redistribution RIPv1/v2/ng OSPF: OSPF v2/v3 OSPF passive interface Stub/NSSA area Supports Equal-Cost Multi-Path Route (ECMP) Text/MD5 authentication L3 Multicasting: IGMP v1/v2/v3 IGMP Proxy MLD v1/v2 MLD proxy DVMRP v3 PIM Sparse-Dense Mode (PIM-SDM) PIM-SM/DM/SSM for IPv4/IPv6
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The DGS-1520 Series, a new generation of Lite Layer 3 Stackable Smart Managed Switches, includes four 10 GB ports for uplink or stacking up to a total of eight switches with a total of 80 Gigabit stacking bandwidth. Designed for effortless multi-site network deployments with Zero Touch Provisioning, the DGS-1520 Series is also powerful enough for server and storage applications. For unrestricted Wi-Fi 6 edge device capabilities, PoE models offer four 2.5 GB Base-T ports for Multi-Gigabit connectivity. For SMBs with expanding networks and significant bandwidth growth, the DGS-1520 effortlessly adds highly cost-effective 10 GB connectivity to ensure seamless aggregation between access and core layers.- Stackable Smart GigabitStack up to eight switches for high-density Gigabit aggregation- Zero Touch ProvisioningEffortless multi-site deployment- Multi-Gigabit PortsFour 2.5 GB Base-T ports for Wi-Fi 6 APs (PoE models)- Flexible Stacking or Uplink10 GB Base-T and/or SFP+ (fiber) ports for stacking or uplink- High CapacityUp to 188 Gbps switching capacity per switch- PoE CapableUp to 370 W PoE output per switch- Power RedundancyConnect with DPS-520 for power redundancy (non-PoE models)- Advanced ManageabilitySupports dynamic routing and selective Q-in-Q taggingHigh AvailabilityThe DGS-1520 Series brings reliable, yet affordable, Gigabit connectivity with four 10-Gigabit ports (two 10G Base-T and two 10G SFP+) for high-speed uplink or stacking. Boost your network performance, simplify your network infrastructure, improve bandwidth and reduce cabling complexity.Zero Touch ProvisioningZero Touch provisioning is perfect for multi-site network expansions. Simply preconfigure your network settings in a centralized location, then install the DGS-1520 switches for effortless deployments.Multi-Gigabit SupportMulti-Gigabit ports on the DGS-1520 Series switch (PoE models only) support 100 MB / 1 GB / 2.5 GB speeds to maximize various device capabilities, such as Wi-Fi 6 (802.11ax) access points, which can often exceed single Gigabit speeds.Powerful Stacking CapabilityStack up to eight DGS-1520 switches with a total of 80 GB stacking bandwidth using hybrid mode (copper and/or fiber), increasing flexibility, scalability, and cost effectiveness for SMBs.Minimize Outages with Power RedundancyFor a more resilient network infrastructure, connect up to four DGS-1520 switches (non-PoE models only) with the DPS-520 PoE redundant power supply system through the management port and actively back-up four devices to significantly reduce power redundancy costs.Auto Discovery: Automatically detect power requirements of connected PD devices. RPS Port Priority: Enables administrators to define RPS failover policy.Status Reporting: Administrators can connect via web browser to remotely monitor DPS-520 status.Low Network Latency, High PoE BudgetHigh Gigabit-port density with up to 188 GB total switching capacity, and up to 30 W per port with 370 W total PoE budget to power your PoE-enabled devices.Enhanced Manageability for Peace of MindD-View 7For more complex network infrastructures, D-View 7, a centralized management platform, can be installed for in-depth network management and maintenance to optimize network availability, reliability, security, and resilience.D-Link Network AssistantBuilt upon a highly-intuitive user interface, the D-Link Network Assistant (DNA) simplifies device configuration using the D-Link Discovery Protocol, auto-detecting supported devices and displaying them for port-level configurations.
LongProductName - Layer 3 Stackable Smart Managed Switch, 20x 10/100/1000 Base-T PoE Ports, 4x 2.5G Base-T PoE Ports, 2x 10G Base-T Ports, 2x 10G SFP+ Ports, 140 Gbps
LongSummaryDescription - D-Link DGS-1520-28MP/E. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 20. MAC address table: 16384 entries, Switching capacity: 140 Gbit/s. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
MAC address table size - 16384
Management, monitoring, configuration - Cable Diagnostics Optical Transceiver Digital Diagnostic Monitoring (DDM) Command Line Interface (CLI) Telnet Server/Client for IPv4/IPv6 TFTP Client for IPv4/IPv6 DNS Client for IPv4/IPv6 Secure FTP Server/Client for IPv4/IPv6 SNMP Traps System Log for IPv4/IPv6 Syslog Server sFlow Multiple Images & Configurations RMON v1: Supports 1,2,3,9 groups RMON v2: Supports ProbeConfig group LLDP/LLDP-MED BootP/DHCP Client DHCP Auto-Configuration/Auto Image DHCP/DHCPv6 Local Relay DHCP Relay Option 60/61/62/125 Flash File System D-Link Discover Protocol (DDP) Debug command Support IPv4/v6 SNTP Server NTPv3/v4 Password recovery/encryption DHCP server: Support for IPv4/IPv6 address assignment Command Logging SMTP DHCPv6 Prefix Delegation (PD) Ping/ Traceroute for IPv4/IPv6 Microsoft Network Load Balancing (NLB) PD Alive (PoE Models Only) Zero Touch Provisioning (ZTP) SNMP: Support v1/v2c/v3 Support for IPv4/IPv6 access Web-based GUI: Support IPv4/IPv6 access Support SSL (HTTPS)
Management features - Switch layer - L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - D-Link
Maximum number of units per stack - 8
Mean time between failures (MTBF) - 333946 h
MPN - DGS-1520-28MP/E
Multicast features - Multicast Listener Discovery (MLD) snooping - v1/v2
Name - D-Link DGS-1520-28MP/E 28-Port GBit PoE Smart Mgt Stack Switch
name - Switch Smart DGS-1520-28MP 20GE PoE 4x2.5GE 2x10GE 2SFP+
Network - 10G support - Yes
Network - Auto MDI/MDI-X - Yes
Network - Flow control support - Yes
Network - Head-of-line (HOL) blocking - Yes
Network - Link aggregation - Yes
Network - Spanning tree protocol - Yes
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 20
Number of 10Gb ports - 2
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - 24
Number of QSFP+ ports - None
Number of SFP+ ports - 2
Number of SFP56 ports - None
Number of SFP ports - None
Number of VLAN groups - 4000
Operational conditions - Heat dissipation - 1545.8 BTU/h
Other features - PoE Budget: 370W, 740W (with RPS)
Other functions - Physical Stacking: 10GBase-T and SFP+ Up to 8 units per stack Stacking throughput up to 80 Gbps Ring/chain topology support Virtual Stacking: Managing one D-Link IP address (SIM) Up to 32 units per virtual stack
Performance - Mean time between failures (MTBF) - 333946 h
Performance - Noise level - 57.1 dB
Performance - Physical stacking (units) - 8
Performance - Virtual stacking (units) - 32
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 4
Ports & interfaces - 10G Ethernet (copper) ports quantity - 2
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 20
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Fiber optic connector - SFP+
Ports & interfaces - Fiber ports quantity - 2
Ports & interfaces - SFP+ module slots quantity - 2
Power - Power consumption (max) - 453.3 W
Power consumption - 453.3 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 20
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 370 W
Power supply - 100 - 240 VAC
Power supply - Internal
producer - D-Link
ProductName - DGS-1520-28MP/E
Protocols - GARP VLAN Registration Protocol (GVRP) - Yes
Protocols - Routing protocols - OSPF, RIP, RIPng, VRRP
QoS - 802.1p 8 queues per port Queue Handling: Strict Priority Weighted Round Robin (WRR) Strict + WRR Weighted Deficit Round Robin (WDRR) Congestion Control: Weighted Random Early Detection (WRED) 802.1Qbb Priority-based FlowControl (PFC) [10G ports only] Policy Map: Remark 802.1p priority Remark IP precedence/DSCP Rate limiting Time based QoS CoS based on: Switch port Inner/Outer VID Inner/Outer 802.1p Priority MAC address Ether type IP address DSCP ToS/IP preference Protocol type TCP/UDP port IPv6 traffic class IPv6 flow label Bandwidth Control: Port-based (ingress/egress, min. granularity 8 Kbps) Flow-based (ingress/egress, min. granularity 8 Kbps) Per queue bandwidth control (min. granularity 8 Kb/s) Three Color Marker: CIR/PIR minimum granularity: 8 kbps trTCM srTCM
Security - Port Security: Supports up to 64 MAC addresses per port Broadcast/Multicast/Unicast Storm Control D-Link Safeguard Engine DHCP Server Screening IP Source Guard DHCP Snooping IPv6 Snooping Dynamic ARP Inspection (DAI) DHCPv6 Guard IPv6 Route Advertisement (RA) Guard IPv6 ND Inspection Duplicate Address Detection (DAD) ARP Spoofing Prevention: Max. 64 entries L3 Control Packet Filtering Unicast Reverse Path Forwarding (URPF) Traffic Segmentation BPDU Attack Protection DOS Attack Prevention SSL: Supports TLS 1.0/1.1/1.2 Supports IPv4/IPv6 access SSH: Supports SSH v2 Supports IPv4/IPv6 access
Security - BPDU filtering/protection - Yes
Security - IGMP snooping - Yes
Security - Loop protection - Yes
ShortSummaryDescription - D-Link DGS-1520-28MP/E, Managed, L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, 1U
Stackability - Yes
Stck_Kart - 1
Stck_Pal - 0
Storno - N
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper) IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper) IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic IEEE 802.3az Energy-Efficient Ethernet (EEE) IEEE 802.3x Flow Control IEEE 802.3ae 10 Gigabit Ethernet IEEE 802.3af/at
Support for Jumbo frames - Yes
Switch class - SMART
Switch layer - L2
Switch layer - L2+
Switch layer - L3
Throughput - 140 Gb/s
Title - D-Link DGS-1520-28MP/E network switch Managed L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
URL - https://www.dlink.com/en/products/dgs-1520-series-layer-3-stackable-smart-managed-switch
vendpn - DGS-1520-28MP/E
VLAN - Max. 4K VLAN groups Max. 1~4094 VIDs GVRP: Max. 4K dynamic VLAN groups Double VLAN (Q-in-Q): Port-based Q-in-Q Selective Q-in-Q 802.1Q Auto Surveillance VLAN Port-based VLAN 802.1v Protocol-based VLAN Voice VLAN MAC-based VLAN Subnet-based VLAN VLAN translation Multicast VLAN (ISM VLAN for IPv4/IPv6) Asymmetric VLAN Private VLAN VLAN Trunking Super VLAN
WarrantyInfo -
Weight - 4.29 kg
Weight & dimensions - Weight - 4.29 kg
