Ubiquiti UniFi Aggregation, 8xSFP

10G support Network - Yes
Access Control List (ACL) - Yes
AC input frequency Power - 50 - 60 Hz
AC input voltage Power - 100 - 240 V
Basic switching RJ-45 Ethernet ports type Ports & interfaces - No
brand - Ubiquiti
Broadcast storm control - Yes
Cables included Packaging content - AC
category - Mājas un biroju tīkli > Komutatori > SFP komutatori
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certification - CE, FCC, IC
Certification Certificates - CE, FCC, IC
Code - USW-Aggregation
Data transmission - Forwarding rate - 119.04 Mpps
Data transmission - Switching capacity - 160 Gbit/s
Data transmission - Throughput - 80 Gbit/s
Depth Weight & dimensions - 120 mm
Description - Managed layer 2 aggregation switch sporting (8) 10G SFP+ ports for high capacity link aggregation. The UniFi Aggregation Switch is a managed Layer 2 switch with eight 10G SFP+ ports. Featuring a compact 4.7" depth and fanless design, it supports high-bandwidth links to provide link aggregation for higher capacity and increased availability.(8) 10G SFP+ Ports160 Gbps switching capacity1.3" Touchscreen with AR switch managementFanless, 4.7" depth compact enclosure1U Rackmountable (kit included)
Description - UBIQUITI 8-PORT, LAYER 2 SWITCH MADE FOR 10G SFP+ CONNECTIONS
Design - Certification - CE, FCC, IC
Design - Form factor - 1U
Design - Housing material - Galvanized steel
Design - LED indicators - System
Design - Product colour - Silver
Design - Rack mounting - Yes
Design > Form factor - Rackmountable
dimensionalWeight - 2620
Dimensions W x D x H, mm - 442 x 120 x 43.7
EAN - 810010074331
EAN - 0810010074331
EAN_code - 0810010074331
Fanless Performance - Yes
Flow control support - Yes
Form factor Design - 1U
Forwarding performance, Mpps - 119.04
Forwarding rate Data transmission - 119.04 Mpps
Gross Weight Kg - 2,7
Harmonized System (HS) code Logistics data - 85176990
height - 0.25 m
Height - 245.000000
Height Weight & dimensions - 43.7 mm
Housing material Design - Galvanized steel
IGMP snooping - Yes
Jumbo Frames support - Yes
LED indicators Design - System
length - 0.52 m
Length - 520.000000
Logistics data - Harmonized System (HS) code - 85176990
MAC address filtering - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features > Switch layer - Layer 2
Management features > Switch type - Managed L2
Manufacturer - Ubiquiti
Manufacturer Code - USW-AGGREGATION
Manufacturer Name - Ubiquiti Networks
ManufacturerPartNumber - USW-AGGREGATION
Manufacturer_code - USW-Aggregation
Model name - USW-Aggregation
mpn - USW-Aggregation
MPN - USW-AGGREGATION
Name - GSwitch
Name - Ubiquiti USW-Aggregation GE / 8SFP + / UNM /
Name - Ubiquiti | UniFi 8Port 10 Gigabit SFP+ Aggregation Switch | USW-Aggregation | Managed L2 | Rackmountable | Gigabit Ethernet (copper) ports quantity 8 | SFP+ ports quantity 8 x 1/10G SFP+ | Power supply type Internal
Network - 10G support - Yes
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -5 - 40 °C
Operating temperature range (T-T), °C - - 5 - 40
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Other features > Power supply type - Internal
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 520 mm
Package features > Gross depth master carton - 274 mm
Package features > Gross height (mm) - 121 mm
Package features > Gross height master carton - 258 mm
Package features > Gross width (mm) - 245 mm
Package features > Gross width master carton - 540 mm
Package features > Net weight master carton - 6.79 kg
Package features > Packing quantity - 2 pc(s)
Package features > Palette Qty - 90 pc(s)
Package features > Paper/Pasteboard - 89.55 g
Package features > Plastic (No PET) - 9.95 g
Package features > Tare weight (kg) - 0.995 kg
Package features > Tare weight master carton - 0.649 kg
Package features > Volume (m3) - 0.0154154 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Cables included - AC
Packaging data - Rack mount kit - Yes
PDF - http://www.blobs.lt/products/3/1/8/2/4/3/7651236eb3ecf3b03cad68045ec2aa20/original.pdf
Performance - Fanless - Yes
PeriodofWarranty - 1 Y
Port mirroring - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - No
Ports & interfaces - SFP+ module slots quantity - 8
Ports & interfaces > Gigabit Ethernet (copper) ports quantity - 8
Ports & interfaces > Predominant port type - SFP+ (10 Gbps Fiber)
Ports & interfaces > SFP+ ports quantity - 8 x 1/10G SFP+
Ports quantity - 8
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 30 W
Power - Power supply included - Yes
Power consumption (max) Power - 30 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Support - No
Power supply included Power - Yes
producerCode - USW-Aggregation
Producer product family - UniFi 8Port 10 Gigabit SFP+ Aggregation Switch
Producer product name - USW-Aggregation
Product colour Design - Silver
productName - Ubiquiti USW-AGGREGATION network switch Managed L2 1U Silver
productSize - Normal
Rack mounting Design - Yes
Rack mount kit Packaging content - Yes
SFP+ module slots quantity Ports & interfaces - 8
SFP+ slots quantity - 8
Short description - Ubiquiti Switch UniFi 8xSFP+ 10GBit Managed 19" Rack-Mountable, 1,3" Touchscreen
sizeX - 420
sizeY - 130
sizeZ - 240
Summary - Ubiquiti USW-AGGREGATION. Switch type: Managed, Switch layer: L2. Switching capacity: 160 Gbit/s. Rack mounting, Form factor: 1U
Switching capacity, Gbit/s - 160
Switching capacity Data transmission - 160 Gbit/s
Switch layer - 2
Switch layer Management features - L2
Switch type - Ethernet
Switch type Management features - Managed
Technical details > Gross weight - 3.395 kg
Technical details > Net weight - 2.4 kg
Technical details > Other features - Built-in 36W AC/DC power supply can support copper Ethernet UF-RJ45-10G modules (sold separately) in all eight ports.
Technical details > Producer - Ubiquiti
Throughput Data transmission - 80 Gbit/s
title - Ubiquiti UniFi Switch Aggregation
Unit Box Height - 0.263
Unit Box Length - 0.536
Unit Box Width - 0.065
Unit Calculated Volume - 0.009163 cubm
Unit Calculated Weight - 3.78 kg
Units per Shipping Box - 2
Vendor Homepage - https://store.ui.com/collections/unifi-network-switching/products/unifi-switch-aggregation
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Weight - 3,40
Weight - 3.4
weight - 3.8 kg
Weight - 3.400000
weight - 3390
Weight & dimensions - Depth - 120 mm
Weight & dimensions - Height - 43.7 mm
Weight & dimensions - Weight - 2.65 kg
Weight & dimensions - Width - 442.4 mm
Weight, g - 2600
Weight Weight & dimensions - 2.65 kg
width - 0.13 m
Width - 120.000000
Width Weight & dimensions - 442.4 mm
