Netgear JGS524, 24x 100/1000Mbps

Accessories included - - JGS524
- Power Cord
- Card with information about the warranty
Additional information - Strona producenta z specyfikacją
Wsparcie techniczne dla produktu
Application - Medium and large companies
ARTIKEL1 - PROSAFE 24X GIGABIT ETHERNET
ARTIKEL2 - SWITCH INCL. RACKMOUNTKIT
Brand - NETGEAR
BrandPartCode - JGS524-200EUS
Category - Network Switches
Category - Root/Smarthome/Networks and communication/Switchers
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certifications - CE mark, commercial, VCCI Class A, C-Tick, FCC Part 15 Class A, EN 55022 (CISPR 22), Class A, EN 50082-1, EN 55024
Chassis type - Rack
Data Transmission - Full Duplex
Data transmission - MAC address table - 8000 entries
Data transmission - Maximum data transfer rate - 2 Gbit/s
Data transmission - Supported data transfer rates - 10/100/1000 Mbps
Data transmission - Switching capacity - 48 Gbit/s
Depth (mm) - 207 mm
Description - NETGEAR’s JGS500 Gigabit Switch Series gives your office network a megaboost of speed and capacity that is within your budget. With up to 48 Gbps of bandwidth, these 16- and 24-port switches can blast 2000 Mbps per port while their affordable prices enable you to put them everywhere. Use it to take Gigabit Ethernet directly to the desktop! Standards-based for easy integration of 10-, 100-, and 1000-Mbps devices, these unmanaged, rack-mountable switches feature 10/100/1000 automatic speed and full/half-duplex sensing plus Auto Uplink™ on every port. Users can take advantage of the their ability to deliver large amounts of multimedia, image, and video information in no time at all. Ideal for workgroups, labs, departments, or growing offices looking for oustanding performance at a low price.
High Capacity
1000-Mbps speeds and a switching capacity of up to 48 Gbps meet the performance needs for even the most bandwidth-hungry applications. The JGS500 series are perfect for graphics, multimedia, and other applications that have to move large files across the network quickly.
Affordable
Aggressive prices enable your workgroup, department or small network to ramp up to Gigabit speeds, even all the way to the desktop.
Flexible
Each port is equipped with automatic speed and duplex sensing, plus Auto Uplink to adjust for straight-through or crossover cables to make the right link. Standards-based design makes it easy to combine 10-, 100-, and 1000-Mbps devices on your network.
Convenient
Easy to set up and easy to use, these unmanaged switches have per port LED’s for effortless network monitoring. They are compact enough for the desktop but come with a rack-mount kit. They are also compatible with PC, Macintosh, Linux, and Unix operating systems.
Design - Certification - CE, FCC 15 A, VCCI A, EN 55022 (CISPR 22) A,
EN 50082-1, EN 55024, C-Tick
Design - Product colour - Blue
Design - Rack mounting - Yes
Design - Stackable - No
Device Location - External
dimension depth - 105 mm
dimension height - 425 mm
Dimensions - 43 x 330x 207 mm
dimension weight - 2786 g
dimension width - 245 mm
ean - 606449064261
EAN - 0606449064261
EANCode - 0606449064261
Eans - 0606449064261
EAN_code - 0606449064261
Ethernet 10Base-T/100Base-TX/1000Base-T Port Connector Type - RJ-45
Ethernet 10Base-T/100Base-TX/1000Base-T Port Quantity - 24
Gewicht - 2.76
Gross Weight Kg - 2,6
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 606449064261
GTIN - 0606449064261
GTIN - 0657968318151
GTIN - 657968318151
GTIN - 4055895865070
GTIN - 4058829201838
GTIN - 5053460697599
GTIN - 5054533266063
GTIN - 5425655887809
guarantee - 0
guarantee_type - perpetual
Height (mm) - 43 mm
HERSTELLER - NETGEAR
HSTNUMMER - JGS524-200EUS
Image - https://content.it4profit.com/pimg/s/resize/160x160x160x160/110601111058098046.jpg
Image - https://content.it4profit.com/pimg/s/resize/400x300x400x300/110601111058146752.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/110601111058408811.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/110601111058516073.jpg
Installed Buffer Memory Storage Capacity - 2 MB
Laenge - 0.46
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - The affordable price of NETGEAR’s JGS524 enables you to cost-effectively deliver Gigabit Ethernet networking speeds across your entire office network – even directly to the desktop. With up to 48 Gbps of bandwidth, this 24-port switch can send 2000 Mbps per port. Network users can take advantage of the their ability to send and receive large amounts of multimedia, image and video information in no time at all. The JGS524 is ideal for teams, departments or growing offices requiring outstanding performance at a low price.-Gigabit speeds meet performance needs of bandwidth hungry applications.-Easy integration of 10, 100, and 1000 Mbps devices.-Automatic speed and full/half-duplex sensing on every port.-Auto Uplink™ on every port to ensure correct link for different cables.-LED’s make network monitoring easy.-Compact enough for desktop, but comes with a rack mount kit.-Compatible with PC, Macintosh, Linux and Unix operating systems.
LongProductName - 24-port Gigabit Rack Mountable Network Switch
LongSummaryDescription - NETGEAR JGS524. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. Rack mounting
MAC Address Table Size - 8K
MAC address table size - 8000
Management features - Quality of Service (QoS) support - Yes
Management features - Switch type - Unmanaged
Manufacturer - Netgear
Manufacturer - NETGEAR
Manufacturer Code - JGS524-200EUS
Manufacturer Name - Netgear
Manufacturer_code - JGS524-200EUS
Maximum Input Frequency - 60 Hz
Maximum Input Voltage - 240 V
Maximum Operating Ambient Temperature - 50 °C
Maximum Operating Humidity - 90 %
Maximum Power Consumption - 16 W
Mean Time Between Failures - 230000
Mean time between failures (MTBF) - 230000 h
Memory buffer - 2 MB
Minimum Input Frequency - 50 Hz
Minimum Input Voltage - 100 V
Minimum Operating Ambient Temperature - 0 °C
MPN - JGS524-200EUS
Name - 24P Netgear ProSafe JGS524v2 RM
Name - Netgear JGS524 1000/UNM/24
Name - Netgear JGS524-200EUS
name - ProSafe Unmanaged Switch 24x1GBEth Rack JGS52
Network - 10G support - No
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Networking standards - IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Network architecture - GigabitEthernet
Networking Compliant Standards - IEEE 802.3ab IEEE 802.3u IEEE 802.3x IEEE 802.3i
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 24
Number of COMBO ports - None
Number of PoE ports (PoE & PoE+) - None
Number of Ports - 24 x 10Base-T/100Base-TX/1000Base-T (Gigabit Ethernet/Fast Ethernet/Ethernet)
Number of SFP ports - None
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - - Specification:
Operating temperature: 0 ° to 50 ° C
Humidity: 90%
Storage temperature: -20 ° to 70 ° C
- Electromagnetic compatibility:
CE mark, commercial
FCC Part 15 Class A
VCCI Class A
EN 55022 (CISPR 22), Class A, EN 50082-1,
EN 55024
C-Tick
- Safety:
UL listed (UL 1950) / cUL
IEC 950/EN 60950 System Requirements
UTP Category 5 cables or better
Network card for each PC or server
Other features - Connectivity LEDs - Y
Other features - Connectivity technology - Wired
Other features - Dimensions (WxDxH) - 330 x 207 x 43 mm
Other features - Latency - 20 μs
Other features - Power requirements - 100~240V; 50-60Hz;
Pack Weight Brutto (kg) - 2.4 kg
Performance - Mean time between failures (MTBF) - 87600 h
Performance - Noise level - 40 dB
Pieces in pack - 1
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (typical) - 17.9 W
Power - Power source - AC
Power consumption - 16 W
Power Device Location - External
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply - Internal
producer - Netgear
Producer - Netgear
ProducerCode - JGS524-200EUS
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=110601052956438225&THEME=asbis&LANG=lv
ProductCategory - Tīkla produkti
ProductCode - JGS524-200EUS
ProductDescription - Switch NETGEAR 24 x 10/100/1000 Ethernet Switch Rack-mountable
ProductName - JGS524
ProductType - Network Switch
ShortDescription -
Short description - Netgear 24Port Switch 10/100/1000 JGS524
ShortSummaryDescription - NETGEAR JGS524, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting
Stck_Kart - 6
Stck_Pal - 30
Store-and-forward - No
Storno - Y
Supported protocols and standards - IEEE 802.3i 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
IEEE 802.3x
Support for Jumbo frames - No
Switch class - Unmanaged
Switching Protocol - Ethernet
Switch layer - L2
Technical_details - The affordable price of NETGEAR’s JGS524 enables you to cost-effectively deliver Gigabit Ethernet networking speeds across your entire office network – even directly to the desktop. With up to 48 Gbps of bandwidth, this 24-port switch can send 2000 Mbps per port. Network users can take advantage of the their ability to send and receive large amounts of multimedia, image and video information in no time at all. The JGS524 is ideal for teams, departments or growing offices requiring outstanding performance at a low price. -Gigabit speeds meet performance needs of bandwidth hungry applications.
-Easy integration of 10, 100, and 1000 Mbps devices.
-Automatic speed and full/half-duplex sensing on every port.
-Auto Uplink™ on every port to ensure correct link for different cables.
-LED’s make network monitoring easy.
-Compact enough for desktop, but comes with a rack mount kit.
-Compatible with PC, Macintosh, Linux and Unix operating systems. Transfer Rate LAN 10/100/1000 MBit/s LEDs Activity, 24x Lan, Speed, Power Ports RJ-45 LAN 24 Power Operating 25 watt(s) Remarks 40 dB Features 48 Gbps, 8000 MAC addresses, 2 MB Packet Buffer Product dimensions 330 x 43 x 207 mm Weight 2.4 kg
Throughput - 48 Gb/s
Title - NETGEAR JGS524 Unmanaged Gigabit Ethernet (10/100/1000) Blue
URL - https://www.netgear.co.uk/rackmountable_switch_jgs524.php
Vendor - NETGEAR
vendpn - JGS524-200EUS
Warranty - NETGEAR Lifetime Warranty
WarrantyInfo -
Warranty Products returnable - Yes
Warranty Term (month) - 99999 month(s)
Warranty validation Criteria - Serial Number
Weight - 1.72 kg
Weight - 2,79
Weight - 2.801
Weight & dimensions - Weight - 2.4 kg
Width (mm) - 330 mm
