Dahua CS4228-24GT-240 2xSFP 26xRJ45 POE

10G support Network - No
AC input frequency Power - 47/63 Hz
AC input voltage Power - 100 - 240 V
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 26
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - Dahua Technology
BrandPartCode - CS4228-24GT-240
Category - Network Switches
Category Code - SWI
Cloud-managed Management features - Yes
CnCode - 85176200
Data transmission - Forwarding rate - 41.66 Mpps
Data transmission - Jumbo frames - 15360
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Switching capacity - 56 Gbit/s
Depth Weight & dimensions - 220 mm
Description - Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standardsMeets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standardsManages PoE power consumption and PoE power on/off. Supports Intelligent PoEA wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof
Design - Housing material - Steel
Design - Product colour - Black
Design - Rack mounting - Yes
DHCP features Security - DHCP client
Flow control support Network - Yes
Forwarding rate Data transmission - 41.66 Mpps
Height Weight & dimensions - 44 mm
Housing material Design - Steel
Input current Power - 4 A
Installed SFP modules quantity Ports & interfaces - 2
Jumbo frames Data transmission - 15360
Jumbo frames support Data transmission - Yes
LongDesc -
LongProductName - CS4228-24GT-240 - 28-Port Cloud Managed Desktop Gigabit Switch with 24-Port PoE
LongSummaryDescription - Dahua Technology CS4228-24GT-240. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 26, Installed SFP modules quantity: 2. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE.... Power over Ethernet (PoE). Rack mounting
MAC address table Data transmission - 8000 entries
Management features - Cloud-managed - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Model name - CS4228-24GT-240
Network - 10G support - No
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Number of VLANs - 32
Network - Virtual LAN features - Port-based VLAN
Network - VLAN support - Yes
Networking standards Network - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs Network - 32
Operating relative humidity (H-H) Operational conditions - 5 - 95%
Operating temperature (T-T) Operational conditions - -10 - 55 °C
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Package depth Packaging data - 342 mm
Package height Packaging data - 90 mm
Package weight Packaging data - 3.15 kg
Package width Packaging data - 540 mm
Packaging data - Package depth - 342 mm
Packaging data - Package height - 90 mm
Packaging data - Package weight - 3.15 kg
Packaging data - Package width - 540 mm
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 26
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Installed SFP modules quantity - 2
Power - AC input frequency - 47/63 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 4 A
Power - Power consumption (max) - 265 W
Power - Power source - AC/DC/PoE
Power consumption (max) Power - 265 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 24
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 240 W
Power over Ethernet (PoE) ports quantity Power over Ethernet (PoE) - 24
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power source Power - AC/DC/PoE
Product colour Design - Black
ProductName - CS4228-24GT-240
Rack mounting Design - Yes
Security - DHCP features - DHCP client
ShortSummaryDescription - Dahua Technology CS4228-24GT-240, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Storage relative humidity (H-H) Operational conditions - 5 - 95%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Summary - Dahua Technology CS4228-24GT-240. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 26, Installed SFP modules quantity: 2. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE.... Power over Ethernet (PoE). Rack mounting
Switching capacity Data transmission - 56 Gbit/s
Switch layer Management features - L2
Switch type Management features - Managed
Title - Dahua Technology CS4228-24GT-240 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 240 W
Unit Box Height - 0.09
Unit Box Length - 0.54
Unit Box Width - 0.34
Unit Calculated Volume - 0.01652 cubm
Unit Calculated Weight - 3.25 kg
Units per Shipping Box - 1
URL - https://transmission.dahuasecurity.com/en/product-list/Business/CloudManagementSolution/NetworkSwitch/CS4228-24GT-240
Vendor Homepage - https://transmission.dahuasecurity.com/en/product-list/Business/CloudManagementSolution/NetworkSwitch/CS4228-24GT-240
Virtual LAN features Network - Port-based VLAN
VLAN support Network - Yes
Warranty - 36 months
WarrantyInfo -
Web-based management Management features - Yes
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 2.5 kg
Weight & dimensions - Width - 440 mm
Weight Weight & dimensions - 2.5 kg
Width Weight & dimensions - 440 mm
