Netgear Switch VSM4320C 16xSFP28 4xQSFP

Accessories included - M4350-16V4C (VSM4320C) Przewód zasilający Kabel USB konsoli typu C Standardowy zestaw wsporników do montażu w szafie typu Rack Zestaw dłuższych wsporników do montażu wpuszczanego 4 x Gumowe podnóżki do montażu na blacie stołu Podręcznik instalacji
Application - Medium and large companies
ARTIKEL1 - 24-PORT 25G MANAGED SWITCH
ARTIKEL2 - M4350-16V4C 16XSFP28 4XQSFP28
Brand - NETGEAR
BrandPartCode - VSM4320C-100NES
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Certificates - CE: EN 55032:2012+AC:2013/CISPR 32:2012, EN 61000-3-2:2014, Class A, EN 61000-3-3:2013, EN 55024:2010 VCCI : VCCI-CISPR 32:2016, Class A RCM: AS/NZS CISPR 32:2013 Class A CCC: GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A) FCC: 47 CFR FCC Part 15, Class A, ANSI C63.4:2014 ISED: ICES-003:2016 Issue 6, Class A, ANSI C63.4:2014 BSMI: CNS 13438 Class A CB report / certificate IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013 UL listed (UL 1950)/cUL IEC 950/EN 60950 CE LVD: EN 60950-1: 2006 + A11:2009 + A1:2010 + A12:2011 + A2:2013 RCM (AS/NZS) 60950.1:2015 CCC (China Compulsory Certificate): GB4943.1-2011; YD/T993-1998; GB/T9254-2008 (Class A) BSMI: CNS 14336-1
Certificates - Compliance certificates - BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Chassis type - Rack
Console port - Yes
Data transmission - Jumbo frames - 12000
Data transmission - Jumbo frames support - Yes
Data transmission - Latency (10 Gbps) - 2.71 µs
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 256 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 1600 Gbit/s
Data transmission - Throughput - 1190.4 Mpps
Description - M4350-16V4C 16xSFP28 25G i 4xQSFP28 100G zarządzalny przełącznik VSM4320C
16 porty 25GBASE-X SFP28 z 4 łączami nadrzędnymi 100GBASE-X QSFP28 Wewnętrzny zasilacz 420 W. Jedno gniazdo do zasilania modułowego (redundancja 1+1) Można użyć dowolnego APS600Wv3, APS1200Wv2 lub APS2000Wv2 Układanie wirtualnych obudów zapewnia nieprzerwane przekazywanie (NSF) i bezbłędne przełączanie awaryjne Zestaw funkcji warstwy 3 zawiera routing statyczny, oparty na zasadach i dynamiczny NETGEAR IGMP Plus, interfejs użytkownika AV i kontroler włączania przyspieszają instalację AV Ograniczona dożywotnia gwarancja na sprzęt firmy NETGEAR ProSAFE Dożywotnia usługa wymiany sprzętu następnego dnia roboczego Dostępny jest SKU zgodny z TAA. Skontaktuj się z przedstawicielem handlowym Moc i przepustowość
Platforma do łączenia w stos od jednego Gigabit do 100 Gigabit, wszystko w zakresie 15,75 cali (40 cm) głębokości.
Przełomowy interfejs graficzny AV
Uproszczony interfejs użytkownika ułatwia przypisywanie profili konfiguracyjnych do każdego portu.
Multicast w jednej chwili
NETGEAR IGMP Plus zapewnia funkcjonalność multiemisji od razu po wyjęciu z pudełka dla większości aplikacji AV over IP.
Elegancki, cichy design
Mniejszy hałas wentylatora i ucha montażowe dołączone do montażu w szafie serwerowej.
Konfiguracja automatyczna
Funkcja Auto-trunk i auto-LAG automatycznie łączy się z innymi przełącznikami M4350 (i M4250).
Szybka, łatwa konfiguracja dla profesjonalistów AV
Uproszczony interfejs umożliwia przypisanie domyślnych ustawień AV lub profili AV określonych przez użytkownika do poszczególnych portów za pomocą zaledwie kilku kliknięć.
Skup się na wydarzeniu, a nie na hałasie wentylatora
Większość modeli ma tryb cichy, który znacznie zmniejsza hałas wentylatora.
Przeznaczony do AV OVER IP zaraz po wyjęciu z pudełka
Dzięki wbudowanemu protokołowi NETGEAR IGMP Plus nie jest wymagana żadna konfiguracja, aby zapewnić bezproblemowe przesyłanie obrazu przez IP. Włącz multicasting zaraz po wyjęciu z pudełka.
Design - Airflow direction - Front-to-back airflow
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimension depth - 600 mm
dimension height - 95 mm
Dimensions - 440 x 43.2 x 400 mm
dimension weight - 10400 g
dimension width - 575 mm
ean - 606449165074
EAN - 0606449165074
EANCode - 0606449165074
Environment requirements - Teperatura otoczenia podczas pracy: 0° - 50°C Wilgotność otoczenia podczas pracy: 90% wilgotności względnej, bez kondensacji Temperatura przechowywania: - 20° - 70°C Wilgotność przechowywania: 95% wilgotności względnej, bez kondensacji
Fan - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 1190.4 Mpps
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0606449165074
GTIN - 606449165074
guarantee - 0
guarantee_type - perpetual
HERSTELLER - NETGEAR
HSTNUMMER - VSM4320C-100NES
Jumbo frame size - 12 KB
L2 features - IEEE 802.1Q VLAN Tagging Auto-Trunk Protocol Based VLANs: IP subnet; ARP; IPX Subnet based VLANs MAC based VLANs Voice VLAN Private Edge VLAN Private VLAN IEEE 802.1x Guest VLAN RADIUS based VLAN assignment via .1x RADIUS based Filter ID assignment via .1x MAC-based .1x Unauthenticated VLAN Double VLAN Tagging Enabling dvlan-tunnel makes interface Global ethertype (TPID) Interface ethertype (TPID) Customer ID using PVID GARP with GVRP/GMRP Multiple Registration Protocol (MRP) Multicast VLAN Registration Protocol (MVRP) MVR (Multicast VLAN registration)
L3 features - L3 Services - Multicast Routing: IGMP Proxy MLD Proxy Any Source Multicast (ASM) Source Specific Multicast (SSM) Multicast streams routing between subnets, VLANs Multicast static routes (IPv4, IPv6) Neighbor discovery PIM-DM (Multicast Routing - dense mode) PIM-DM (IPv6) PIM-SM (Multicast Routing - sparse mode) PIM-SM (IPv6) PIM multi-hop RP support PIM Timer Accuracy PIM-SM Unhandled Events IPMC replication (hardware support)
L3 Services - DHCP: DHCP IPv4 / DHCP IPv6 Client DHCP IPv4 / DHCP IPv6 Server (Stateless, Stateful) DHCP Snooping IPv4 / IPv6 BootP Relay IPv4 / IPv6 DHCP Relay IPv4 / IPv6 DHCP Relay Option 82 circuit-id and remote-id for VLANs Multiple Helper IPs Auto Install (DHCP options 66, 67, 150 and 55, 125) L3 Services - Routing: Static Routing / ECMP Static Routing IPv4/IPv6 Multiple next hops to a given destination Load sharing, Redundancy Default routes Static Reject routes Port Based Routing VLAN Routing 802.3ad (LAG) for router port VRRP IPv4 Pingable VRRP interface VRRP Route/Interface Tracking Loopback Interfaces Tunnel interfaces IPv4 / IPv6 Configured 6to4 tunnels Automatic 6to4 tunnels 6to4 Border Router RIP IPv4 RIPv1/RIPv2 Route Redistribution SMTPE ST 2110: Boundary Clock mode (BC) Grandmaster Clock mode (GM) PTP profiles for: SMPTE 2059-2 (video/audio), AES67 (Audio), AES-R16-2016 (Interoperability) Single-step PTP to AV endpoints Single-step/ two-step to the GrandMaste
LongDesc - POWER AND THROUGHPUTEdge to core stackable platform, from 1 Gigabit to 100 Gigabit, all within 15.75in (40cm) of depth.Groundbreaking AV GUIA simplified user interface makes it easy to assign configuration profiles to each port.Multicast in an InstantNETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.Sleek, Quiet DesignLess fan noise, and mounting ears included for rack mounting.Automatic ConfigurationAuto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.FAST, EASY CONFIGURATION FOR AV PROSA streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.FOCUS ON THE EVENT NOT FAN NOISEMost models have quiet mode which greatly reduces fan noise.DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOXWith built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
LongProductName - 16 x 25G SFP28, 4 x 100G QSFP28, 440 x 400 x 43.2 mm, 7.15 kg
LongSummaryDescription - NETGEAR M4350-16V4C. Switch type: Managed, Switch layer: L3. Full duplex. MAC address table: 16000 entries, Switching capacity: 1600 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power connector: AC-in jack. Rack mounting
MAC address table size - 16000
Management, monitoring, configuration - Management ACL (MACAL), Max Rules: 64 Out of band Management Radius accounting TACACS+ Malicious Code Detection
Management features - ARP inspection - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer - NETGEAR
MPN - VSM4320C-100NES
Multicast features - Multicast Listener Discovery (MLD) snooping - Y
Multicast features - Multicast support - Yes
Name - 24-PORT 25G MANAGED SWITCH
name - Switch VSM4320C 16xSFP28 4xQSFP
Network - 6to4 tunnel - Yes
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - IPv4 routes - 512
Network - IPv6 routes - 256
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u
Network - Number of VLANs - 4093
Network - Policy-based routing - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - MAC address-based VLAN, Private VLAN, Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of QSFP28 ports - 4
Number of VLAN groups - 4000
Operational conditions - Non-operating altitude - 0 - 3000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Porty zarządzania: RJ-45 Port konsolowy USB-C 2 x USB-A
Other features - Power supply - 420 W
Other functions -
Packaging content - Cables included - AC, USB Type-C
Packaging content - Quick start guide - Yes
Packaging content - Rack mount kit - Yes
Packaging data - Included power plug types - EU, UK, NA
Packet buffer - 256 MB
Performance - Built-in processor - Yes
Performance - Flash memory - 512 MB
Performance - Internal memory - 4096 MB
Performance - Memory type - DDR4-SDRAM
Performance - Processor frequency - 1800 MHz
Performance - Processor model - ARM Cortex-A57
Performance - sFlow - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - No
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - QSFP28 ports quantity - 4
Ports & interfaces - SFP28 ports quantity - 16
Power - Power consumption (typical) - 143.4 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 420 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply -
Power supply - Internal
producer - Netgear
ProductName - M4350-16V4C
Protocols - GARP VLAN Registration Protocol (GVRP) - Yes
Protocols - Management protocols - SNMP V1, V2, V3
Protocols - Routing protocols - OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
QoS - Auto-VoIP
Access Lists: L2 MAC, L3 IP and L4 Port ACLs Ingress Egress Time-based 802.3ad (LAG) for ACL assignment Binding ACLs to VLANs ACL Logging Support for IPv6 fields DiffServ QoS: Edge Node applicability Interior Node applicability 802.3ad (LAG) for service interface Support for IPv6 fields Ingress/Egress EEE 802.1p COS: 802.3ad (LAG) for COS configuration WRED (Weighted Deficit Round Robin) Strict Priority queue technology Single Rate Policing: Committed Information Rate Committed Burst Size Excessive Burst Size DiffServ feature applied to class ma
Security - Successive Tiering (DOT1X; MAB; Captive Portal) DHCP Snooping Dynamic ARP Inspection IP Source Guard Network Storm Protection, DoS Broadcast, Unicast, Multicast DoS Protection Denial of Service Protection (control plane) Denial of Service Protection (data plane) DoS Attacks Protection CPU Rate Limiting ICMP throttling
Security - Access Control List (ACL) - Yes
Security - Access Control List (ACL) egress - 1023
Security - Access Control List (ACL) ingress - 511
Security - Authentication - Guest VLAN, MAC-based authentication
Security - Authentication type - RADIUS, TACACS+
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
Security - DoS attack prevention - Yes
Security - IGMP proxy - Yes
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Security - MAC address filtering - Yes
Security - Password protection - Yes
Security - Queue scheduling algorithms - Strict Priority Queue (SPQ), Weighted random early detection (WRED)
Security - Root protection - Yes
Security - Static port security - Yes
SFP28 ports - 16
ShortSummaryDescription - NETGEAR M4350-16V4C, Managed, L3, Full duplex, Rack mounting
Stackability - Yes
Stck_Kart - 1
Stck_Pal - 10
Storno - Y
Supported protocols and standards -
Support for Jumbo frames - Yes
Sustainability - Sustainability compliance - Yes
Switch class - Managed
Switch layer - L3
Throughput - 1600 Gb/s
Title - NETGEAR M4350-16V4C Managed L3 Black
URL - https://www.netgear.com/business/wired/switches/fully-managed/vsm4320c/
vendpn - VSM4320C-100NES
VLAN - Static Dynamic Voice MAC GVRP/GMRP Double VLAN mode Private VLANs
WarrantyInfo - Limited Lifetime
Weight - 7.15 kg
Weight & dimensions - Depth - 400 mm
Weight & dimensions - Height - 43.2 mm
Weight & dimensions - Weight - 7.15 kg
Weight & dimensions - Width - 440 mm
