Startech DP21-3M-DP40-CABLE 3M 8K DISPLAYPORT 2.1 CABLE

ARTIKEL1 - DP21-3M-DP40-CABLE
ARTIKEL2 - 3M 8K DISPLAYPORT 2.1 CABLE
Brand - StarTech.com
BrandPartCode - DP21-3M-DP40-CABLE
Breite - 0
Category - DisplayPort Cables
EANCode - 0065030920568
Features - AWG wire size - 30
Features - Cable length - 3 m
Features - Cable material - Copper
Features - Cable shielding - Aluminum mylar foil
Features - Cable type - Round cable
Features - Channels quantity - 32 channels
Features - Connector 1 - DisplayPort
Features - Connector 1 form factor - Straight
Features - Connector 1 gender - Male
Features - Connector 2 - DisplayPort
Features - Connector 2 form factor - Straight
Features - Connector 2 gender - Male
Features - Connector contacts plating - Nickel
Features - Data transfer rate - 40 Gbit/s
Features - DisplayPort version - 2.1
Features - Display Stream Compression (DSC) - Yes
Features - Display Stream Compression (DSC) version - 1.2a
Features - Fire-resistance rating - VW-1
Features - HDCP - Yes
Features - HDCP version - 2.2
Features - High Dynamic Range (HDR) supported - Yes
Features - Jacket material - Thermoplastic elastomer (TPE)
Features - Latching connectors - Yes
Features - Maximum refresh rate - 240 Hz
Features - Maximum resolution - 7680 x 4320 pixels
Features - Multi-Stream Transport (MST) - Yes
Features - Product colour - Black
Features - Supported graphics resolutions - 2560 x 1440, 3840 x 2160, 7680 x 4320
GRUPPE1 - Cables
GRUPPE2 - AUDIO / VIDEO CABLE
GTIN - 0065030920568
GTIN - 065030920568
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - DP21-3M-DP40-CABLE
Laenge - 0
Logistics data - Master (outer) case height - 210 mm
Logistics data - Master (outer) case length - 320 mm
Logistics data - Master (outer) case width - 500 mm
Logistics data - Products per master (outer) case - 30 pc(s)
LongDesc - Facilitate higher refresh rates and 8K 60Hz video on UHBR10-enabled DisplayPort devicesConnect an 8K/4K UHD DisplayPort monitor to a host computer or MST hub, using this VESA-Certified DisplayPort 2.1 DP40 Cable. This cable facilitates high bandwidth video and multi-channel audio and is ideal for 8K workstations, high performance GPUs, and dedicated AV applications including media production and content creation.Seamless CompatibilityFor seamless operation between DisplayPort-enabled devices, the DisplayPort 2.1 Cable is VESA Certified for guaranteed DP 2.1 and backward compatibility (DP 2.0/1.4/1.2). It supports G-Sync and FreeSync, enhancing Variable Refresh Rate (VRR) performance for optimal picture quality between high-capacity GPUs and supported displays.Durable DesignThis DisplayPort cable features a flexible TPE outer jacket that is tested to withstand 600 bending cycles at -/+60 degrees, and routes easily around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching nickel-plated DP connectors attach securely to prevent accidental disconnection. The connectors are rated to operate beyond 10,000 insertions.Supported DisplayPort 2.1 Features:This DP40 DisplayPort cable supports the following DP 2.1 features:• Resolutions up to 8K 60Hz w/DSC, using a compatible DP source and display• UHBR10 supports high refresh rates including 4K 120Hz and 1440p 240Hz• High-Bandwidth Digital Content Protection (HDCP) 2.2 for a secure connection between source and display• High Dynamic Range 10 (HDR10) for higher contrast ratio and vibrant picture quality• Display Stream Compression (DSC) 1.2a for maximum resolution output• Multi-Stream Transport (MST) for daisy-chaining multiple monitors• 32 Uncompressed Digital Audio Channels• Backward compatible with previous DP versionsThis DP 2.1 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.The StarTech.com Advantage
LongProductName - StarTech.com 3m (10ft) DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz w/DSC 1.2a
LongSummaryDescription - StarTech.com 3m (10ft) DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz/4K 144Hz w/DSC 1.2a, 40Gbps, DP 2.1 Cable, UHD Monitor Cord, M/M. Cable length: 3 m, Connector 1: DisplayPort, Connector 2: DisplayPort. Cable diameter: 8.2 mm, Weight: 275 g. Package width: 220 mm, Package depth: 200 mm, Package height: 41 mm. Master (outer) case width: 500 mm, Master (outer) case length: 320 mm, Master (outer) case height: 210 mm
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 45 °C
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Packaging data - Package depth - 200 mm
Packaging data - Package height - 41 mm
Packaging data - Package weight - 287 g
Packaging data - Package width - 220 mm
ProductName - 3m (10ft) DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz/4K 144Hz w/DSC 1.2a, 40Gbps, DP 2.1 Cable, UHD Monitor Cord, M/M
ShortSummaryDescription - StarTech.com 3m (10ft) DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz/4K 144Hz w/DSC 1.2a, 40Gbps, DP 2.1 Cable, UHD Monitor Cord, M/M, 3 m, DisplayPort, DisplayPort, Male, Male, 7680 x 4320 pixels
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - StarTech.com 3m (10ft) DisplayPort 2.1 Cable, VESA Certified DP40 DisplayPort Cable w/UHBR10/HDR/HDCP 2.2, 8K 60Hz/4K 144Hz w/DSC 1.2a, 40Gbps, DP 2.1 Cable, UHD Monitor Cord, M/M
URL - https://www.startech.com/en-us/DP21-3M-DP40-CABLE
WarrantyInfo - Lifetime
Weight & dimensions - Cable diameter - 8.2 mm
Weight & dimensions - Weight - 275 g
