Accessories included - - IB-158SSK-B pocket
- 2 keys
- 8 screws
Brand - ICY BOX
BrandPartCode - 15800
Category - Drive Bay Panels
Category_1 - Hard Drives and Pendrives
Category_2 - Mobile HDD Racks
Color - Black
Connectors - SATA
Description - B-158SSK-B Pocket for 3.5" SATA hard drives
Functions:
- Fast installation and disk replacement without drivers
- Supports all 3.5" SATA 1.5/3.0/6.0 Gb/s hard drives with a height of up to 2.54 cm (1")
- Installation in the bay 5.25"
- Aluminum housing provides better cooling
- Supports Hot Swap and Easy Swap
- The lock protects against unauthorized access. The construction without a fan ensures quiet operation
- 12V power connector for an additional fan
Cooling aluminum
The mobile pocket IB-129SSK-B has an efficient passive cooling system. The housing made of aluminum dissipates heat very well, thus ensuring quiet and stable operation without the need for fan assembly.
No carrier = twice as fast
Due to the fact that we do not have to mount the hard disk to any housing only directly to the pocket, the assembly is completely without any tools. Thanks to this, we are able to save up to twice as much time. The only thing required is the 5.25 "bay. It supports SATA hard drives with SATA I, II and III speeds.
Fanless = quiet operation
Our pocket is made entirely of aluminum, the front and back of the pocket (assembly part) is made of hard plastic to ensure full protection. Aluminum is very durable, although it is very light. The main feature of aluminum is that it perfectly dissipates heat, thanks to which the device's operation is completely silent. Optionally, you can connect a 12V fan (not included).
Do not worry = closed!
To keep the hard drive always protected, a lock has been added. In this way, an unauthorized person will not be able to reach your data. The LED indicator provides information on the access and activity of the hard disk.
Designation - CE+WEEE
dimension depth - 195 mm
dimension height - 50 mm
Dimensions - 179 x 145 x 41 mm
dimension weight - 380 g
dimension width - 155 mm
ean - 4250078188193
EAN_code - 4250078188193
Features - Data transfer rate - 6 Gbit/s
Features - HDD interface - SATA, SATA II, SATA III
Features - HDD size - 3.5"
Features - Hot-swap - Yes
Features - Key lock - Yes
Features - LED indicators - HDD, Power
Features - Material - Aluminium
Features - Number of HDDs supported - 1
Features - Product colour - Black
Features - Size (imperial) - 13.3 cm (5.25")
Features - Supported storage drive heights - 25.4 mm
Features - Type - Carrier panel
Form factor (width) - 3,5'' (LFF)
GTIN - 4250078188193
GTIN - 5425655999960
guarantee - 24
guarantee_type - normal
HDD interface - SATA I - 1,5 Gb/s
HDD interface - SATA II - 3 Gb/s
HDD interface - SATA III - 6 Gb/s
Logistics data - Harmonized System (HS) code - 84733080
Logistics data - Master (outer) case gross weight - 8.85 kg
Logistics data - Master (outer) case height - 257 mm
Logistics data - Master (outer) case length - 324 mm
Logistics data - Master (outer) case width - 410 mm
Logistics data - Products per master (outer) case - 20 pc(s)
LongDesc - No tray = double the speedThe fact that the HDD does not need to be screwed to a tray makes the HDD installation much faster. A 5.25" bay is needed on the PC. SATA HDDs are supported SATA I/II/III.No fan = whisper silentThis mobile rack is made almost completely from aluminium, only the front and back panels are made of hard plastic. Aluminium is very stable, very light and on top of everything else, it dissipate heat perfectly. That is why no fan is needed in order to protect the HDDs. In case still wished, a 12V fan can be installed (not delivered in the package).No worries = lockedIn order that the HDD will stay protected at all times, a lock was added. In this way, no unauthorized person will be able to reach your data. An LED indicator provides information regarding HDD access and activity.
LongProductName - Mobile rack for 1x HDD for 1x 5.25" bay with lock
LongSummaryDescription - ICY BOX IB-158SK-B. Size (imperial): 13.3 cm (5.25"), Type: Carrier panel, Product colour: Black. Width: 145 mm, Depth: 179 mm, Height: 41 mm. Package width: 152 mm, Package depth: 198 mm, Package height: 48 mm. Quantity per pack: 1 pc(s), Number of lock keys included: 2 pc(s). Products per master (outer) case: 20 pc(s), Master (outer) case width: 410 mm, Master (outer) case length: 324 mm
Manufacturer - Icy Box
Manufacturer_code - 15800
Name - ICY BOX IB-158SK-B - mobile rack 3.5 inch SATA
name - ICY BOX IB-158SSK-B 3,5'' HDD SATA
Other features -
Packaging content - Number of lock keys included - 2 pc(s)
Packaging content - Number of screws - 8
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 198 mm
Packaging data - Package height - 48 mm
Packaging data - Package weight - 400 g
Packaging data - Package width - 152 mm
Ports & interfaces - External SATA ports quantity - 2
producer - IcyBox
ProductName - IB-158SK-B
ShortSummaryDescription - ICY BOX IB-158SK-B, 13.3 cm (5.25"), Carrier panel, Black, 3.5", SATA, SATA II, SATA III, Aluminium
Stuff - Aluminum
System requirements - Linux operating systems supported - Yes
System requirements - Mac compatibility - Yes
System requirements - Mac operating systems supported - Yes
System requirements - Windows operating systems supported - Yes
Title - ICY BOX IB-158SK-B 13.3 cm (5.25") Carrier panel Black
Type - Internal enclosure
URL - https://icybox.de/en/product.php?id=341
vendpn - IB-158SSK-B
WarrantyInfo -
Weight - 0,37
Weight - 310 g
Weight & dimensions - Depth - 179 mm
Weight & dimensions - Height - 41 mm
Weight & dimensions - Weight - 310 g
Weight & dimensions - Width - 145 mm
