10Base-T / 100Base-TX Ports - 2
Accessories included -
ARTIKEL1 - FE SINGLE-MODE SC FIBERCONVERTE
ARTIKEL2 - WDM BI-DIRECTIONAL
Brand - TP-Link
BrandPartCode - TL-FC111A-20
Breite - 0
Cable distance - 20km
Category - Network Media Converters
Category - Root/Electronics/Networks and communication/Network accessories/Accessories and switch modules
Category 1 - Netzwerk
Category 2 - Netzwerkartikel
Category Code - MCO
Category_1 - Network and Servers
Category_2 - Network - Network Accessories
Certificates - Certification - FCC, CE
Certificates - Compliance certificates - RoHS
Code - FC111A-20
Color - Black
Description -
Description - Complies with 802.3u 10/100Base-TX, 100Base-FX standards Auto-negotiation of Half-Duplex/Full-Duplex transfer mode 9/125 μm SMF (Single-Mode Fiber) Bidirectional WDM communication on a single fiber Ranges up to 20km (12.4 miles) Work with TL-FC111B-20 as a pair
Designation - CE+WEEE
dimension depth - 60 mm
dimension height - 170 mm
Dimensions - 94.5 x 73 x 27 mm
dimension weight - 340 g
dimension width - 200 mm
EAN - 6935364010980
ean - 6935364010980
EANCode - 6935364010980
Eans - 6935364010980
EAN_code - 6935364010980
Features - Internal - No
Features - LED indicators - Activity, Link, Power
Features - Product colour - Black
Gewicht - 0
GRUPPE1 - Network
GRUPPE2 - Media Converters
GTIN - 0845973010089
GTIN - 845973010089
GTIN - 6935364010966
GTIN - 6935364010980
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - FC111A-20
Inputs - 1 x Ethernet
Laenge - 0
Link - https://www.tp-link.com/us/business-networking/accessory/tl-fc111a-20/
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - What This Product DoesTL-FC111A-20 is a 100M media converter, providing a 100M RJ-45 port and a 100M SC fiber port, which can convert between electrical and optical signals. And long-distance data transmission through optical fiber can be applied to commercial scenarios such as park security monitoring and wireless networking.How This Product WorksTL-FC111A-20 adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance of up to 20km (12.4 miles) over only one fiber, which saves half of the cable deployment cost for customers. TL-FC111A-20 transmits data at 1550nm wavelength and receives data at 1310nm wavelength on optical fiber. The TL-FC111A-20 works in the other end as a pair by receiving data at wavelength 1550nm and sending data at wavelength 1310nm.Other FeaturesBesides, this media converter can be used as a standalone device (no rack required) or used with TP-Link’s TL-FC1420 rack for auto MDI/MDI-X in TX port in which duplex mode is automatically negotiated.
LongProductName - SC, RJ-45, 100Base-FX, 94.5x73x27 mm
LongSummaryDescription - TP-Link 10/100 Mbps WDM Media Converter. Maximum data transfer rate: 100 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3i, IEEE 802.3u, Ethernet LAN data rates: 10,100 Mbit/s. Maximum transfer distance: 20000 m, Fiber mode structure: Single-mode, Fiber cable diameters supported (core/cladding): 9/125 µm. LED indicators: Activity, Link, Power, Product colour: Black. Fiber optic connector: SC, Connectivity technology: Wired. Output voltage: 5 V, Output current: 0.6 A
Manufacturer - TP-Link
Manufacturer_code - TL-FC111A-20
MPN - FC111A-20(UN)
name - FC111A-20 Media Converter 10/100 WDM
Name - TP-Link Omada Nek FC111A-20 Fiber Converter
Name - TP-Link TL-FC111A-20
Name - TP-Link TL-FC111A-20, media converter
Name - TP-LINK | 10/100 Mbps WDM Media Converter | TL-FC111A-20 | 1 x SC Fiber Port | 10/100 Mbps RJ45 Port
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3, Cat4, Cat5, Cat5e
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-T
Network - Duplex system - Full, Half
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Fiber ethernet cabling technology - 100BASE-FX
Network - Flow control support - Yes
Network - Maximum data transfer rate - 100 Mbit/s
Network - Networking standards - IEEE 802.3, IEEE 802.3i, IEEE 802.3u
Networking > Auto MDI/MDI-X - Yes
Networking > Converter input interface - 1 x SC Fiber Port
Networking > Converter output interface - 10/100 Mbps RJ45 Port
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - ŚRODOWISKO PRACY: Dopuszczalna temperatura pracy 0C - 50 st. C Dopuszczalna temperatura przechowywania -40C - 70 st. C Dopuszczalna wilgotność powietrza 10% - 90% RH, bez kondensacji Dopuszczalna wilgotność przechowywania 5% - 90% RH, bez kondensacji
Outputs - 1 x SC Simplex
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 204.00 mm
Package features > Gross height (mm) - 65.00 mm
Package features > Gross width (mm) - 165.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Paper/Pasteboard - 100.00 g
Package features > Plastic (No PET) - 50.00 g
Package features > Tare weight (kg) - 0.15 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging data - Package depth - 204 mm
Packaging data - Package height - 65 mm
Packaging data - Package weight - 360 g
Packaging data - Package width - 165 mm
Performance - Fiber cable diameters supported (core/cladding) - 9/125 µm
Performance - Fiber mode structure - Single-mode
Performance - Maximum transfer distance - 20000 m
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Fiber optic connector - SC
Ports & interfaces - Fiber ports quantity - 1
Power - Output current - 0.6 A
Power - Output voltage - 5 V
producer - TP-LINK
Producer - TP-Link
ProducerCode - TL-FC111A-20
Producer product family - 10/100 Mbps WDM Media Converter
Producer product name - TL-FC111A-20
ProductName - 10/100 Mbps WDM Media Converter
Product Net Weight - 0 kg
ShortDescription -
ShortSummaryDescription - TP-Link 10/100 Mbps WDM Media Converter, 100 Mbit/s, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, 10,100 Mbit/s, 10BASE-T, 100BASE-T, 100BASE-FX, Full, Half
Special functions - Konwerter to urządzenie wolnostojące, ale może być także montowanie w szafie rack TP-Link, aby udostępniać funkcję automatycznego krosowania MDI/MDI-X na porcie TX, na którym szybkości połączeń są automatyczne negocjowane w trybie dupleksu.
Stck_Kart - 30
Stck_Pal - 0
Storno - N
Technical details > Gross weight - 0.36 kg
Technical details > Net weight - 0.21 kg
Technical details > Other features - This media converter can be used as a standalone device (no rack required) or used with TP-Link’s TL-FC1420 rack for auto MDI/MDI-X in TX port in which duplex mode is automatically negotiated
Technical details > Producer - TP-LINK
Technical_details - TL-FC111A-20 is a 100M media converter with a 100M RJ-45 port and a 100M SC fiber optic port, which can convert between electrical and optical signals. Long-distance data transmission via fiber optic can be applied to commercial scenarios such as parking security monitoring and wireless networking.Item No.: 1707963 Type network adapter EAN 6935364010980 Manufacturer no. TL-FC111A-20 Desktop design Network connections RJ-45 1x (of which: 1x 10/100) Features Auto MDI/MDIX Feature up to 20km range
Title - TP-Link 10/100 Mbps WDM Media Converter
Unit Box Height - 0.065
Unit Box Length - 0.204
Unit Box Width - 0.168
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 0 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/uk/business-networking/accessory/tl-fc111a-20/
Usage - Fiber
Vendor Homepage - www.tp-link.com/us/business-networking/accessory/tl-fc111a-20/
vendpn - FC111A-20
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
Weight - 1
Weight & dimensions - Depth - 73 mm
Weight & dimensions - Height - 27 mm
Weight & dimensions - Width - 94.5 mm
