Startech FIBER TO RJ45 MEDIA CONVERTER MEDIA CONVERTER DONGLE SMF/MMF

ARTIKEL1 - FIBER TO RJ45 MEDIA CONVERTER
ARTIKEL2 - MEDIA CONVERTER DONGLE SMF/MMF
Brand - StarTech.com
BrandPartCode - D01ML55U-FIBER-MEDIA
Breite - 0
Category - Network Media Converters
Certificates - Compliance certificates - Trade Agreements Act (TAA)
EANCode - 0065030909815
Features - Housing material - Metal, Plastic
Features - Internal - No
Features - International Protection (IP) code - IP20
Features - LED indicators - Activity, Link, Power
Features - Product colour - Black, Silver
Gewicht - 0.09
GRUPPE1 - Network
GRUPPE2 - Media Converters
GTIN - 0065030909815
GTIN - 065030909815
HERSTELLER - STARTECH
Hoehe - 0
HSTNUMMER - D01ML55U-FIBER-MEDIA
Laenge - 0
Logistics data - Master (outer) case height - 126 mm
Logistics data - Master (outer) case length - 290 mm
Logistics data - Master (outer) case width - 340 mm
Logistics data - Products per master (outer) case - 24 pc(s)
LongDesc - Convert and extend a Gigabit RJ45 Ethernet connection over single or multimode LC fiberThis compact Gigabit Fiber to Ethernet Media Converter enables Cat6 or similar cabling to be upgraded to an EMI-free fiber connection. The TAA-compliant adapter is designed with a convenient built-in USB cable for power, making it a perfect choice when external power options are unavailable.Simplified InstallationThe unmanaged fiber media converter features a plug-and-play design that does not require additional software or settings to be changed. The metal housing features an IP20 rating and is an all-in-one construction with integrated LC fiber and RJ45 ports. The RJ45 side features a metal tab to ensure a reliable and secure fit and prevent accidental disconnections.Network FeaturesThe LC slot is compatible with Single-Mode (10km) and Multimode (800m) fiber cables up to 1Gbps. A spring-loaded tab protects the port when not in use. The converter supports LFPT (Link Fault Pass-Through), allowing IT administrators to monitor and assess network connectivity at a glance based on the LED behavior.CompatibilityThis LAN-to-fiber converter is ideal for upgrading computers, switches, routers, or other equipment from copper to fiber. It suits various applications, including field deployments, industrial automation, telecommunications, broadcasting, data centers, and remote networking. Experience reliable connectivity with EMI immunity over long distances with this compact (3.2×0.8×0.7in/82.39x20x17.5mm) and power-efficient (2.5W max) dongle.The StarTech.com Advantage
LongProductName - StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, TAA, USB Powered
LongSummaryDescription - StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, USB Powered, Compact Design, Metal Housing, Micro Mini, TAA. Maximum data transfer rate: 1000 Mbit/s, Converter input interface: 1000Base-T, Converter output interface: 1000Base-LX. Maximum transfer distance: 1000 m, Wavelength: 1310 nm, Fiber mode structure: Multi-mode, Single-mode. LED indicators: Activity, Link, Power, Product colour: Black, Silver, Housing material: Metal, Plastic. Fiber optic connector: LC, Connectivity technology: Wired. Power consumption (max): 2.5 W
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Chipset - Marvell - 88E1512
Network - Converter input interface - 1000Base-T
Network - Converter output interface - 1000Base-LX
Network - Duplex system - Full
Network - Ethernet interface type - Fast Ethernet, Gigabit Ethernet
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Maximum data transfer rate - 1000 Mbit/s
Network - Networking standards - IEEE 802.3ab, IEEE 802.3z
Operational conditions - Operating relative humidity (H-H) - 5 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Packaging content - User guide - Yes
Packaging data - Package depth - 80 mm
Packaging data - Package height - 32 mm
Packaging data - Package weight - 80 g
Packaging data - Package width - 136 mm
Performance - Fiber mode structure - Multi-mode, Single-mode
Performance - Maximum transfer distance - 1000 m
Performance - Wavelength - 1310 nm
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Fiber optic connector - LC
Ports & interfaces - Fiber ports quantity - 1
Power - Power consumption (max) - 2.5 W
Power - Power over Ethernet (PoE) - No
ProductName - Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, USB Powered, Compact Design, Metal Housing, Micro Mini, TAA
ShortSummaryDescription - StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, USB Powered, Compact Design, Metal Housing, Micro Mini, TAA, 1000 Mbit/s, 1000Base-T, 1000Base-LX, IEEE 802.3ab, IEEE 802.3z, Fast Ethernet, Gigabit Ethernet, 10,100,1000 Mbit/s
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - StarTech.com Gigabit Fiber to RJ45 Ethernet Media Converter Dongle, Optical Singlemode 10km/Multimode 800m, USB Powered, Compact Design, Metal Housing, Micro Mini, TAA
URL - https://www.startech.com/en-us/D01ML55U-FIBER-MEDIA
WarrantyInfo - 2-Year Warranty
Weight & dimensions - Depth - 20 mm
Weight & dimensions - Height - 18 mm
Weight & dimensions - Weight - 49 g
Weight & dimensions - Width - 82 mm
