ARTIKEL1 - CISCO MA-SFP-10GB-LR SFP+
ARTIKEL2 - CISCO MERAKI MA-SFP-10GB-LR SFP+
Brand - StarTech.com
BrandPartCode - MASFP10GBLR
Breite - 0.1
Category - Network Transceiver Modules
Certificates - Compliance certificates - CE, RoHS
EANCode - 0065030872119
Features - Hot-swap - Yes
Features - Housing material - Aluminium
Features - Mean time between failures (MTBF) - 2104865 h
Features - Product colour - Silver
Gewicht - 0.05
GRUPPE1 - Network
GRUPPE2 - Media Converters
GTIN - 0065030872119
GTIN - 065030872119
HERSTELLER - STARTECH
Hoehe - 0.04
HSTNUMMER - MASFP10GBLR
Laenge - 0.12
Logistics data - Country of origin - China
Logistics data - Harmonized System (HS) code - 85369010
Logistics data - Master (outer) case height - 200 mm
Logistics data - Master (outer) case length - 300 mm
Logistics data - Master (outer) case width - 250 mm
Logistics data - Products per master (outer) case - 3 pc(s)
LongDesc - 10 Gbps | Single Mode Fiber | LC | 10 km (6.2 mi) | Lifetime WarrantyThe MASFP10GBLR is a Cisco Meraki MA-SFP-10GB-LR compatible fiber transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 10GbE connectivity over fiber cable, for 10GBASE-LR compliant networks, with a maximum distance of up to 10 km (6.2 mi).Technical Specifications:• Wavelength: 1310nm• Maximum Data Transfer Rate: 10 Gbps• Type: Single Mode Fiber• Connection Type: LC Connector• Maximum Transfer Distance: 10 km (6.2 mi)• MTBF: 2,104,865 hours• Power Consumption: Less than 1.2 Watts• Digital Diagnostics Monitoring (DDM): YesThis SFP+ fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.StarTech.com SFPsAll StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.The StarTech.com Advantage
LongProductName - StarTech.com Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module - 10GBASE-LR - 10GbE SMF Optic Transceiver - Gigabit Ethernet SFP+ - LC 10km 1310nm DDM Cisco Meraki MS225, MX400 (MASFP10GBLR)
LongSummaryDescription - StarTech.com Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Transceiver Module - 10GBASE-LR~Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber SMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM Cisco Meraki MS225, MX400, MS250. SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Product colour: Silver, Housing material: Aluminium, Mean time between failures (MTBF): 2104865 h. Power consumption (typical): 1.2 W. Compliance certificates: CE, RoHS. Width: 13.9 mm, Depth: 58.4 mm, Height: 12.6 mm
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 120 mm
Packaging data - Package height - 30 mm
Packaging data - Package weight - 53 g
Packaging data - Package width - 90 mm
Performance - Digital Diagnostics Monitoring (DDM) - Yes
Performance - Duplex system - Full
Performance - Fiber optic connector - LC
Performance - Interface type - SFP+
Performance - Maximum data transfer rate - 10000 Mbit/s
Performance - Maximum transfer distance - 10000 m
Performance - Networking standards - IEEE 802.3ae
Performance - SFP transceiver standard - LR
Performance - SFP transceiver type - Fiber optic
Performance - Single-mode fiber (SMF) supported - Yes
Performance - Wavelength - 1310 nm
Power - Power consumption (typical) - 1.2 W
ProductName - Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Transceiver Module - 10GBASE-LR~Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber SMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM Cisco Meraki MS225, MX400, MS250
ShortSummaryDescription - StarTech.com Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Transceiver Module - 10GBASE-LR~Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber SMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM Cisco Meraki MS225, MX400, MS250, Fiber optic, 10000 Mbit/s, SFP+, LC, LR, 10000 m
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - StarTech.com Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Transceiver Module - 10GBASE-LR~Cisco Meraki MA-SFP-10GB-LR Compatible SFP+ Module - 10GBASE-LR - 10GbE Single Mode Fiber SMF Optic Transceiver - 10GE Gigabit Ethernet SFP+ - LC 10km - 1310nm - DDM Cisco Meraki MS225, MX400, MS250
URL - https://www.startech.com/en-us/MASFP10GBLR
WarrantyInfo - Lifetime
Weight & dimensions - Depth - 58.4 mm
Weight & dimensions - Height - 12.6 mm
Weight & dimensions - Weight - 22 g
Weight & dimensions - Width - 13.9 mm
