TP-LINK AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point

Antenna - Antenna direction type - Omni-directional
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antenna type - Internal
Brand - TP-Link
BrandPartCode - EAP245 V3
Category - Wireless Access Points
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - RoHS
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - LED indicators - Power
Design - Placement - Ceiling, Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 1016
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Ethernet LAN data rates - 100
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 1750 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 450 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1300 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.1x
Features - Networking standards - IEEE 802.3af
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power - 27 dBmW
Features - Transmitting power (CE) - 20 - 23 dBm
Features - Transmitting power (FCC) - 24 dBm
Features - Virtual LAN features - SSID-based VLAN assignment
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features - Wireless isolation - Yes
GTIN - 0845973092962
GTIN - 845973092962
GTIN - 0845973096663
GTIN - 845973096663
GTIN - 6935364096663
GTIN - 6935364096687
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Superior Wi-Fi Speeds and PerformanceQCA enterprise class chipsets, dedicated high-power amplifier and professional antenna along with the latest generation 802.11ac Wave 2 MU-MIMO technology, ensure superior 1750 Mbps Wi-Fi speeds and long-range coverage over 2.4GHz and 5GHz wireless bands.Seamless Roaming802.11k/802.11v seamless roaming switches clients automatically to the access point with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.Secure Guest Network with Facebook W-Fi and SMS LoginGuest Network provides secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.Multiple PoE Options for Easy InstallationEAP245 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE adapter. The addition of elegant appearance and simple mounting design for easy attachment to a wall or ceiling further makes deployment effortless and flexible.Free Cloud Centralized Management- Anytime, AnywhereOmada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.Easy Management with the Omada AppFollow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smartphone or tablet.
LongProductName - 2.4/5Ghz, 802.11a/b/g/n/ac, 1300Mbps, 2x Gigabit Ethernet, 12.3W, PoE
LongSummaryDescription - TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1750 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management features - Syslog - Yes
Management features - Web-based management - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - Cables included - AC
Packaging content - Mounting kit - Yes
Packaging content - PoE adapter included - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 340 mm
Packaging data - Package height - 65 mm
Packaging data - Package weight - 1.18 kg
Packaging data - Package width - 228 mm
Performance - Compatible operating systems - Microsoft Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - Output current - 1.5 A
Power - Output voltage - 12 V
Power - Power consumption (typical) - 12.7 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Active PoE
Power - Power over Ethernet (PoE) type supported - Active PoE, Passive PoE
Power - Power over Ethernet (PoE) type supported - Passive PoE
producerCode - TL-EAP245
ProductName - AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point
productName - TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point
productSize - Normal
Protocols - Management protocols - HTTP/HTTPS
Safety warning - Warnings - Avoid direct contact with water.
Safety warning - Warnings - Do not expose to prolonged moisture.
Safety warning - Warnings - Electronic products should be recycled at specialist electronic waste collection facilities.
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Port-based Network Access Control (PNAC) - Yes
Security - Security algorithms - 64-bit WEP
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Security algorithms - 128-bit WEP
Security - Security algorithms - 152-bit WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2
Security - Security algorithms - WPA2-PSK
Security - Service Set Identifier (SSID) features - Multiple SSIDs
ShortSummaryDescription - TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point, 2.4 GHz, 5 GHz, 1750 Mbit/s, 64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, 10,100,1000 Mbit/s
sizeX - 340
sizeY - 65
sizeZ - 230
Sustainability - Sustainability compliance - Yes
Title - TP-Link Omada AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point
URL - https://www.tp-link.com/en/products/details/EAP245_V3.html#overview
WarrantyInfo -
warrantyLength - 60
warrantyType - G
weight - 980
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Height - 47.5 mm
Weight & dimensions - Width - 180 mm
