Accessories included - - Cable tester
- BNC and RJ11 converter
Cable locator - No
Category Code - CBL
Color - Gray
Connectors - BNC
Connectors - RJ-11
Connectors - RJ-45
Description - Digital network cable tester GET THE RIGHT TOOL Spot the wiring problems instantly on the big screen Suitable for Cat 5E, 6E, coaxial, and telephone cable Measures the cable length Suitable for single person use Long battery life Indicates wiring problems in Cat 5E, 6E, coaxial and telephone cables: open circuit, short circuit, jumper wire, reverse connection Measures the cable length and determines the distance to the open circuit The length measurement accuracy up to 97% via built-in calibration Self-checks and automatically compensates any change in battery capacity or ambient temperature Up to 50 working hours of the battery life
Description - Digital Network Cable Tester NCT-3
Designation - CE+WEEE
dimensionalWeight - 465
dimension depth - 140 mm
dimension height - 60 mm
Dimensions - 180 x 80 x 40 mm
Dimensions - 180 x 80 x 40mm
dimension weight - 379 g
dimension width - 250 mm
ean - 8716309065689
Environment requirements - - Operating temperature: from -10 to 60 °C
Features - Cable type - STP/UTP
Features - Display type - LCD
Features - Measuring cable length - Yes
Features - Product colour - Grey
Features - Supported connectors - RJ-45
guarantee - 24
guarantee_type - normal
Logistics data - Master (outer) case gross weight - 9.4 kg
Logistics data - Products per master (outer) case - 20 pc(s)
Media - Coaxial cble
Media - Twisted-pair cable
name - Digital Network Cable Tester
Operational conditions - Operating temperature (T-T) - -10 - 60 °C
Other features - - Up to 50 working hours of the battery life
- Power supply: 4 x 1.5 V DC AA batteries (not included)
- Power consumption: up to 16 mA
- Display: 4 x 16 character LCD screen, 61.6 x 25.2 mm
- Tester port: tester RJ45 master port (M), tester LOOPBACK RJ45 port (L), far-end recognizer - RJ45 port (R)
- Max cable length: up to 1350 m
- Automatic shut-down: after 30 minutes
Packaging data - Package depth - 255 mm
Packaging data - Package height - 60 mm
Packaging data - Package length - 6 cm
Packaging data - Package weight - 430 g
Packaging data - Package width - 150 mm
Power - Batteries / rechargeable AA
Power - Battery type - AA
Power - Battery voltage - 1.5 V
Power - Number of batteries supported - 4
Power - Operating voltage - 6 V
producer - Gembird
producerCode - NCT-3
productName - CABLE TESTER /UTP/STP NCT-3 GEMBIRD
Product Net Weight - 0.25 kg
productSize - Normal
Safety warning - Warnings - Avoid contact with conductive parts.
Safety warning - Warnings - Do not use in damp conditions or near water.
Safety warning - Warnings - Store away from sources of heat and open flame.
sizeX - 250
sizeY - 150
sizeZ - 62
Special functions - - Indicates wiring problems in Cat 5E, 6E, coaxial and telephone cables: open circuit, short circuit, jumper wire, reverse connection
- Measures the cable length and determines the distance to the open circuit
- The length measurement accuracy up to 97% via built-in calibration
- Self-checks and automatically compensates any change in battery capacity or ambient temperature
Unit Box Height - 0.06
Unit Box Length - 0.255
Unit Box Width - 0.15
Unit Calculated Volume - 0.002295 cubm
Unit Calculated Weight - 0.397 kg
Units per Shipping Box - 1
Vendor Homepage - http://gembird.com/item.aspx?id=6568
vendpn - NCT-3
Warranty - 24 months
warrantyLength - 24
warrantyType - G
Weight - 0.25 kg
weight - 410
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Dimensions (WxDxH) - 180 x 80 x 40 mm
Weight & dimensions - Height - 40 mm
Weight & dimensions - Weight - 250 g
Weight & dimensions - Width - 80 mm
