Brand - Gigabyte
BrandPartCode - GV-R79XTGAMING OC-20GD
Card's length - > 280 mm
Category - Graphics Cards
Category - Root/Electronics/PC parts/Graphic cards
Category Code - VGP
Chipset - AMD Radeon RX 7900 XT
Code - GV-R79XTGAMING OC-20GD
Cooling system - Dual Slot Fansink
Description - - Powered by Radeon RX 7900 XT - Integrated with 20GB GDDR6 320-bit memory interface - WINDFORCE Cooling System - RGB Fusion - Dual BIOS - Protection metal back plate - Anti-sag bracket
Design - Bracket height - Full-Height (FH)
Design - Cooling technology - GIGABYTE WINDFORCE 3X
Design - Cooling type - Active
Design - Fan diameter - 10 cm
Design - Form factor - Full-Height/Full-Length (FH/FL)
Design - Illumination - Yes
Design - Illumination colour - Multi
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
dimensionalWeight - 1986
Dimensions - L=331 W=138 H=50 mm
DisplayPort Input/Output connectors - 2
EAN - 4719331312367
Eans - 4719331312367
Full Description Line - AMD Radeon RX 7900 XT|Graphics memory size 20 GB|GDDR6|320 bit|PCIE 4.0 16x|Memory CLK 20 Gbps|GPU boost clock 2535 MHz|7680x4320|Cooling Dual Slot Fansink|2xHDMI|2xDisplayPort|Included Accessories 1. Quick guide2. Anti-sag bracket3. Anti-sag bracket installation guide
GPU boost clock - 2535 MHz
Graphic card features - Gaming/Overclock Edition
Graphics connector - PCIE 4.0 16x
Graphics memory size - 20 GB
Graphics memory type - GDDR6
Gross Weight Kg - 3
GTIN - 4719331312367
HDMI Input/Output connectors - 2
Included Accessories - 1. Quick guide
2. Anti-sag bracket
3. Anti-sag bracket installation guide
Link - https://www.gigabyte.com/Graphics-Card/GV-R79XTGAMING-OC-20GD#kf
LongDesc - WINDFORCE COOLING SYSTEMThe WINDFORCE cooling system features three 100mm unique blade fans, alternate spinning, 9 composite copper heat pipes, a large vapor chamber directly touches the GPU, 3D active fans and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGReduce the turbulence of adjacent fans and increase airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.LARGE VAPOR CHAMBER & HEAT-PIPEThe large vapor chamber directly contacts the GPU, coupled with the composite heat pipes, which quickly transfers the heat of the GPU and VRAM to the heatsink.SCREEN COOLINGExtended heatsink allows air to pass through, providing better heat dissipation.RGB FUSIONWith 16.7M customizable color options and numerous lighting effects, you can choose any lighting effect or synchronize with other devices in GIGABYTE CONTROL CENTER.EXCELLENT IN ESSENTIALPROTECTION METAL BACK PLATEThe metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.DUAL BIOSThe factory default setting is OC mode, which provides users with the best performance. However, switching to silent mode will enjoy a quieter experience.POWER INDICATORWhen experiencing any power supply abnormality, the indicator will alert gamers by flashing light.ANTI-SAG BRACKETThe new anti-sag bracket is tailored to each graphics card. It provides the optimized reinforcement and better overall visual appearance.BUILT STRONGULTRA DURABLEUltra Durable certified highest-grade metal chokes, lower ESR solid capacitors, 2oz copper PCB, and lower RDS(on) MOSFETs, plus over-temperature design to deliver superior performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.GIGABYTE CONTROL CENTERGIGABYTE CONTROL CENTER (GCC) is a unified software for all GIGABYTE supported products. It provides an intuitive interface that allows users to adjust clock speed, voltage, fan mode and power target in real-time.AMD Radeon™ Anti-LagMinimizes input lag so you can game like a champion.AMD Radeon™ BoostDelivers extra performance and responsiveness when you need it most.AMD Radeon™ Image SharpeningImproves in-game visuals with virtually no impact to performance.AMD Radeon™ Super ResolutionIn-driver upscaler powered by FSR 1.0, elevates performance across thousands of games.AMD Noise SuppressionReduces background audio noise from your surrounding environment for clearer communication.AMD LinkConnect your phone, tablet, TV, or Windows-based PC and play your games from almost anywhere in the world.
LongProductName - 20 GB, GDDR6, 320-bit, PCI Express 4.0, 2535 MHz boost clock, 2x HDMI, 2x DisplayPort, 2x 8-pin, RGB
LongSummaryDescription - Gigabyte GAMING Radeon RX 7900 XT OC 20G. Graphics processor family: AMD, Graphics processor: Radeon RX 7900 XT. Discrete graphics card memory: 20 GB, Graphics card memory type: GDDR6, Memory bus: 320 bit. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express 4.0. Cooling type: Active, Number of fans: 3 fan(s), Illumination colour: Multi
Manufacturer Code - GV-R79XTGAMING OC-20GD
Manufacturer Name - Gigabyte
Max resolution - 7680x4320
Memory - Data transfer rate - 20 Gbit/s
Memory - Discrete graphics card memory - 20 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bus - 320 bit
Memory - Number of pipelines - 9
Memory > Discrete graphics adapter memory - 20 GB
Memory > Graphics adapter memory type - GDDR6
Memory > Memory clock speed - 20000 MHz
Memory bus - 320 bit
Memory CLK - 20 Gbps
Model - GV-R79XTGAMING OC-20GD
Name - Gigabyte Radeon RX 7900 XT GAMING OC 20G
Name - Gigabyte | GV-R79XTGAMING OC-20GD 1.0 | AMD | 20 GB | Radeon RX 7900 XT | GDDR6 | DVI-D ports quantity | HDMI ports quantity 2 | PCI-E 4.0 | Memory clock speed 20000 MHz | Processor frequency MHz
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 405.00 mm
Package features > Gross depth master carton - 725 mm
Package features > Gross height (mm) - 235.00 mm
Package features > Gross height master carton - 310 mm
Package features > Gross width (mm) - 90.00 mm
Package features > Gross width master carton - 465 mm
Package features > Net weight master carton - 16 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 202 pc(s)
Package features > Paper/Pasteboard - 350.00 g
Package features > Plastic (No PET) - 50.00 g
Package features > Tare weight (kg) - 0.40 kg
Package features > Tare weight master carton - 1.777 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEEE tax - No
Packaging content - User guide - Yes
Packaging data - Package type - Box
Packaging data - User guide - Yes
Performance - AMD FreeSync - Yes
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 2.1
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Interface type - PCI Express 4.0
Ports & interfaces > DisplayPorts quantity - 2
Ports & interfaces > HDMI ports quantity - 2
Ports & interfaces > Interface type - PCI-E 4.0
Power - Minimum system power supply - 800 W
Power - Supplementary power connectors - 2x 8-pin
Power connectors - 8+8 pin
Processor - CUDA - No
Processor - Graphics processor - Radeon RX 7900 XT
Processor - Graphics processor family - AMD
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Processor boost clock speed - 2535 MHz
Processor - Stream processors - 5376
Processor > Graphics processor - Radeon RX 7900 XT
Processor > Graphics processor family - AMD
Producer - Gigabyte
producerCode - GV-R79XTGAMING OC-20GD
ProducerCode - GV-R79XTGAMING OC-20GD
Producer product name - GV-R79XTGAMING OC-20GD 1.0
productName - Gigabyte GAMING Radeon RX 7900 XT OC 20G AMD 20 GB GDDR6
ProductName - Radeon RX 7900 XT GAMING OC 20G
productSize - Normal
Shipping Box Depth Shipping/Package Box Dimensions - 44.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 9.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 2.33 kg
Shipping Box Width Shipping/Package Box Dimensions - 23.5 cm
ShortDescription - Chipset AMD 7900XT | 20GB
Short description - GIGA VGA 20GB Radeon RX7900XT GAMING OC-20GD 2xDP/2xHDMI Radeon RX 7900 XT GAMING OC 20G
ShortSummaryDescription - Gigabyte GAMING Radeon RX 7900 XT OC 20G, Radeon RX 7900 XT, 20 GB, GDDR6, 320 bit, 7680 x 4320 pixels, PCI Express 4.0
sizeX - 445
sizeY - 235
sizeZ - 95
Stream processors - 5376
System requirements - Windows operating systems supported - Windows 10 x64
System requirements - Windows operating systems supported - Windows 10 x64, Windows 11 x64
System requirements - Windows operating systems supported - Windows 11 x64
Technical details > Gross weight - 1.07 kg
Technical details > Net weight - 0.67 kg
Technical details > Producer - Gigabyte
Title - Gigabyte GAMING Radeon RX 7900 XT OC 20G AMD 20 GB GDDR6
Unit Box Height - 0.095
Unit Box Length - 0.445
Unit Box Width - 0.235
Unit Brutto Volume - 0.009935 cubm
Unit Gross Weight - 2.33 kg
Unit Net Weight - 1.8 kg
URL - https://www.gigabyte.com/Graphics-Card/GV-R79XTGAMING-OC-20GD
Vendor Homepage - www.gigabyte.com/Graphics-Card/GV-R79XTGAMING-OC-20GD#kf
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 2320
Weight & dimensions - Depth - 331 mm
Weight & dimensions - Height - 50 mm
Weight & dimensions - Width - 138 mm
