Accessories included - LR350 wireless router Charger USB to DC power cable SIM adapter (Nano, Micro) Quick Installation Guide
Aero2 support - No
Antenna - Fixed external
Antenna - Antenna design - External
Antenna - Antennas quantity - 4
Antenna - Antenna type - 2x2
Antenna gain - 5 dBi
Category - Root/Electronics/Networks and communication/Routers
Color - Black
Data transmission - EDGE
Data transmission - LTE
Data transmission - UMTS
Description - 4G LTE wireless router and 300Mbps Wi-Fi Totolink LR350 is a 4G LTE 300 Mb/s wireless router that complies with the advanced 802.11n standards and offers Wi-Fi speeds up to 300 Mb/s. The router provides convenient access to the 4G network, while sharing the 4G LTE network with multiple Wi-Fi devices, so that all Wi-Fi devices can access the network wherever you are. The most important features of the Totolink LR350 router: Compliant with IEEE 802.11b/g/n standards Convenient 4G access - share your 4G LTE network with multiple Wi-Fi devices and achieve download speeds of up to 150Mbps and upload speeds of up to 50Mbps 2.4GHz wireless speed up to 300Mbps Powerful, integrated antennas ensure stable wireless connections and better coverage Support LTE-FDD, LTE-TDD, WCDMA, GSM network type No setup required, just insert a SIM card and turn it on to enjoy a fast wireless connection Provides WPA/WPA2 security Support router mode, 4G mode It supports IP, MAC, URL filtering and port forwarding Support power supply via USB to DC power cable Super-fast 4G LTE speed and 2.4GHz Wi-Fi Thanks to LTE technology, the LR350 achieves download speeds of up to 150 Mb/s and upload speeds of up to 50 Mb/s. Supports Internet sharing up to 300Mbps in the 2.4GHz band. Plug and Play Just insert the SIM card, connect the power supply and start using the 4G LTE network. You can also use the Totolink LR350 router in the traditional way, connecting it to the network using an RJ45 cable. 4 external high-gain antennas - stronger WiFi signal Totolink LR350 is equipped not only with two WiFi antennas, but also with two external 4G antennas. The 4G signal is stronger and more stable. Videos won't stutter and outdoor live streams will be smoother. You can enjoy a high-quality 4G network anytime and anywhere. Low power consumption, flexible power mode Thanks to the ultra-low power consumption design, the Totolink LR350 4G router can be connected to the power bank's USB port with the supplied high-quality USB-DC power cable, so you can continue to surf the Internet. Keep your 4G network stable and online all the time.
Design - Housing material - Plastic
Design - Indication light - Yes
Design - LED indicators - System
Design - Product colour - Black
Design - Product type - Desktop/pole router
Design - Wall mountable - Yes
dimensionalWeight - 370
dimension depth - 45 mm
dimension height - 185 mm
Dimensions - 143 x 95 x 37,25 mm
dimension weight - 324 g
dimension width - 200 mm
ean - 6952887470404
Eans - 6952887470404
Environment requirements - Operating temperature: 0°C ~ 40°C Storage temperature: -40°C ~ 70°C Operating humidity: 10% ~ 90% non-condensing Storage humidity: 5% ~ 90% non-condensing
GSM network - 850 MHz
GSM network - 900 MHz
GSM network - 1800 MHz
GSM network - 1900 MHz
guarantee - 24
guarantee_type - normal
I/O ports - 1 x SIM card slot
I/O ports - 1 x WAN (RJ-45)
I/O ports - 2 x 10/100 Mbit/s
LTE network - 700 MHz
LTE network - 800 MHz
LTE network - 850 MHz
LTE network - 1700 MHz
LTE network - 1800 MHz
LTE network - 1900 MHz
LTE network - 2100 MHz
LTE network - 2300 MHz
LTE network - 2500 MHz
LTE network - 2600 MHz
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - Web-based setup wizard - Yes
Management features - WPS push button - Yes
Mobile network - 4G standard - LTE-TDD & LTE-FDD
Mobile network - Mobile network generation - 4G
Mobile network - Short Message Service (SMS) - Yes
Model - LR350
name - Router LTE LR350
Name - TOTOLINK LR350
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN interface type - Fast Ethernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - WPS/Reset button Data transfer speed: 2.4GHz to 300Mbps
Packaging content - AC adapter included - Yes
Packaging content - Cables included - DC
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - USB port - No
Power - Output current - 0.8 A
Power - Output voltage - 9 V
Power - Power source type - DC
Power supply - 9 V DC / 0.8 A
producer - Totolink
Producer - TotoLink
producerCode - LR350
ProducerCode - LR350
productName - Totolink LR350 | WiFi Router | 2.4GHz, 4G LTE, 3x RJ45 100Mbps, 1x SIM
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Security - WPA/WPA2 Mixed
Security - DMZ support - Yes
Security - MAC address filtering - Yes
Security - Parental control - Yes
ShortDescription -
SIM card - Micro
SIM card - Nano
SIM card - Standard
sizeX - 185
sizeY - 50
sizeZ - 200
Software -
Special functions - Home: WAN Information, LAN Information, System Information WAN Type: Static IP, DHCP, PPPoE, 4G Wireless features: Multiple SSIDs, MAC authentication, WPS Firewall: MAC address filtering, IP/port filtering, URL filtering, DMZ Management: Password, system setup, time setup, firmware upgrade, system log Device capacity: Maximum 32 users
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
System Requirements -
Type - GSM 3G/4G
UMTS network - 850 MHz
UMTS network - 900 MHz
UMTS network - 1700 MHz
UMTS network - 1900 MHz
UMTS network - 2100 MHz
vendpn - LR350
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - Yes
WAN connection - WAN connection type - RJ-45
warrantyLength - 24
warrantyType - G
weight - 350
Weight & dimensions - Depth - 143 mm
Weight & dimensions - Height - 37.2 mm
Weight & dimensions - Width - 95 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi band - Single-band (2.4 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - WLAN data transfer rate (max) - 300 Mbit/s
