Accessories included - Access Point EAP610-Outdoor Passive PoE Adapter Power cable Mounting kits Waterproof Kits Waterproof antenna Installation manual
Antenna - Built-in
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antenna type - Internal
Antenna > Antenna type - Internal
Antenna gain - 5 dBi
ARTIKEL1 - AX1800 OUTDOOR WI-FI 6 AP
ARTIKEL2 - DUAL-BAND OMADA SDN
Brand - TP-Link
BrandPartCode - EAP610-OUTDOOR
Breite - 0.25
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Code - EAP610-Outdoor
Color - White
Data transmission speed - 1800 Mbps
Description - AX1800 Indoor/Outdoor WiFi 6 Access Point - Superior WiFi 6 Speeds: Delivers dual-band speeds of up to 1.8 Gbps powered by the latest WiFi 6 technology† - Higher Network Efficiency: Enjoy faster speeds on more devices with less lag via OFDMA and MU-MIMO - Long-Range Coverage: Dedicated high-power amplifier and professional antennas with IP67 weatherproof enclosure - Omada Mesh Technology: Enables wireless connectivity between access points for extended range and flexible deployment** - Stay Smooth with Fast Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points** - Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management
Description - Wireless Outdoor Access Point, AX1800 standard Superior WiFi 6 speed: Simultaneous dual-band operation offers speeds of up to 1.8Gbps High connection performance: Guarantee higher network performance and lower latency with OFDMA and MU-MIMO. Long Range: Dedicated high power amplifier and professional antennas inside an IP67 sealed enclosure. Omada Mesh: The ability for access points to interconnect wirelessly to maintain long network coverage and location freedom. Fast Roaming: Users can stream data across the property and their devices will switch between access points. Centralized Cloud Management: Integration with Omada SDN allows for cloud-based access and remote management. Dual-band WiFi 6 connectivity With the latest WiFi 6 technology, the access point offers speeds of up to 1.8Gbps and higher throughput in situations where multiple users are connected. At swimming pools, coffee shops, or amusement parks. Long range Professional antennas and high power amplifiers using WiFi 6 technology ensure strong and wide WiFi coverage in a variety of outdoor environments. Connect multiple devices OFDMA and MU-MIMO significantly improve performance when multiple users are connected simultaneously. Integration with Omada SDN platform The Omada Software Defined Networking (SDN) platform integrates network devices such as Access Points, switches and routers to provide 100% centralized cloud-based management and a highly scalable network managed from a single interface. Easy pairing, fewer wires Based on Mesh technology, Omada EAPs require no additional cables, by wirelessly forwarding your WiFi signal for easy installation in locations where cables are difficult to bring. Network performance optimisation Intelligent optimisation selects the best path between EAP access points, and Self-healing ensures that they stay online even when one access point stops working.
Design - International Protection (IP) code - IP67
Design - LED indicators - Yes
Design - Placement - Pole, Wall
Design - Product colour - White
dimensionalWeight - 1200
dimension depth - 65 mm
dimension height - 320 mm
Dimensions - 280,4 × 106,5 × 56,8 mm
Dimensions - 280.4×106.5×56.8 mm
dimension weight - 1384 g
dimension width - 240 mm
EAN - 6935364010232
ean - 6935364010232
EANCode - 6935364010232
EAN_code - 6935364010232
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Ethernet LAN data rates - 100
Features - Ethernet LAN data rates - 1000
Features - Frequency band - 2.4 - 5 GHz
Features - Maximum data transfer rate - 1800 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1201 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Number of users - 250 user(s)
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features - Wireless isolation - Yes
Features > MU-MiMO - Yes
Full Description Line - Omada|EAP610-Outdoor|Data transmission speed 1800 Mbps|IEEE 802.11a|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|IEEE 802.11ax|Wireless Frequency Range 2.4 GHz, 5 GHz|Dimensions 280.4×106.5×56.8 mm
Gewicht - 1.48
Gross Weight Kg - 0,69
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Broadba
GTIN - 0845973073145
GTIN - 845973073145
GTIN - 6935364010232
GTIN - 6935364010249
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0.07
HSTNUMMER - EAP610-OUTDOOR
I/O ports - 1 x 10/100/1000 Mbit/s
IEEE 802.11ac Network standard - Yes
IEEE 802.11a Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Laenge - 0.32
Link - https://www.tp-link.com/us/business-networking/omada-sdn-access-point/eap610-outdoor/v1.20/
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Performance-Driven WiFi 6 for Demanding Outdoor EnvironmentsDual-Band WiFi 6 ConnectivityPowered by the latest WiFi 6 technology, the AP delivers speeds of up to 1.8 Gbps, providing higher data rates on both 5 GHz and 2.4 GHz bands for demanding multi-user scenarios, such as outdoor swimming pools, cafés, and amusement parks.Long-Range CoverageProfessional antennas equipped with high-power amplifiers utilize WiFi 6 technology to provide strong and expansive wireless coverage to various outdoor environments.Connect Numerous DevicesOFDMA and MU-MIMO greatly improve multi-user efficiency to provide simultaneous connections for dozens of clients in large open areas.Seamless Integration into Omada SDN PlatformThe Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.Easy Pairing, Less WiringWith Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.Optimized Network PerformanceIntelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.Always Stay Smooth with Fast RoamingEnsures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.IP67 Weatherproof Enclosure for Outdoor EnvironmentsEAP610-Outdoor is totally resistant to dust ingress, shock, vibration, and moisture, withstanding the most extreme environments.Versatile Mounting SolutionsOur mounting kits provide flexible installation, whether inside or outside.Multiple PoE Options for Easy InstallationThe AP supports both 802.3at PoE+ and Passive PoE power supply. It can be either powered by a PoE switch or the provided PoE adapter for convenient deployment.Easy Management with the Omada AppFollow the configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
LongProductName - 2.4 GHz (574 Mbps), 5 GHz (1201 Mbps), 802.11ax/ac/n/g/b/a, 1x Gigabit Ethernet (RJ-45), 280.4 x 106.5 x 56.9 mm
LongSummaryDescription - TP-Link Omada EAP610-Outdoor. Maximum data transfer rate: 1800 Mbit/s, Maximum data transfer rate (2.4 GHz): 574 Mbit/s, Maximum data transfer rate (5 GHz): 1201 Mbit/s. Security algorithms: WEP, WPA, WPA2, WPA3. Management protocols: SNMP v1/v2c. Management platform: Omada. Placement: Pole, Wall, Product colour: White, International Protection (IP) code: IP67
Management, monitoring, configuration - Omada Application Cloud Access: Yes (via OC300, OC200, Cloud-based Omada Controller, or Omada Software Controller) E-mail notifications Access control by MAC address SNMP: v1, v2c System log SSH Browser-based management L3 management Multi-site management VLAN management Central management: Omada Cloud-based Controller Omada Controller Hardware (OC300) Omada Controller Hardware (OC200) Omada Software Controller
Management features - Management platform - Omada
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - EAP610-OUTDOOR
Manufacturer Name - TP-LINK
Manufacturer_code - EAP610-Outdoor
Model name - EAP610-Outdoor
MPN - EAP610-OUTDOOR
Name - TP-Link EAP610-Outdoor, Access Point (white)
Name - TP-LINK EAP610-Outdoor - 2,4GHZ/574MBPS - 5GHZ/1201MBPS - Wifi-6
name - TP-Link EAP610-OUTDOOR Access Point AX1800
Name - TP-LINK | EAP610-Outdoor | AX1800 Indoor/Outdoor WiFi 6 Access Point | 802.11ax | 2.4 GHz/5 GHz | 1201+574 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO Yes | PoE in | Antenna type Internal
Network architecture - GigabitEthernet
Networking > Wi-Fi - Yes
Number of antennas - 2
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -30 - 70 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 65 mm
Package features > Gross height (mm) - 323 mm
Package features > Gross width (mm) - 240 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 171 pc(s)
Package features > Paper/Pasteboard - 90.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Volume (m3) - 0.0050388 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 1 pc(s)
Packaging content - PoE adapter included - Yes
Packaging data - Package depth - 325 mm
Packaging data - Package height - 67 mm
Packaging data - Package weight - 1.29 kg
Packaging data - Package width - 241 mm
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Frequency band - 2.4 GHz/5 GHz
Performance > Wi-Fi data rate (max) - 1201+574 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - Power over Ethernet (PoE) - Yes
Power supply -
producer - TP-LINK
producerCode - EAP610-OUTDOOR
Producer product family - AX1800 Indoor/Outdoor WiFi 6 Access Point
Producer product name - EAP610-Outdoor
ProductName - EAP610-Outdoor
productName - TP-Link Omada EAP610-Outdoor 1800 Mbit/s White Power over Ethernet (PoE)
productSize - Normal
Protocols - Management protocols - SNMP v1/v2c
Security - Welcome page authentication Access control MAC address filtering Wireless client isolation SSID to VLAN mapping Detection of unauthorized APs 802.1X support Encryption WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - WEP
Security - Security algorithms - WEP, WPA, WPA2, WPA3
Security - Security algorithms - WPA
Security - Security algorithms - WPA2
Security - Security algorithms - WPA3
Series - Omada
Shipping Box Depth Shipping/Package Box Dimensions - 51 cm
Shipping Box Height Shipping/Package Box Dimensions - 37 cm
Shipping box quantity - 10
Shipping Box Weight Shipping/Package Box Dimensions - 15.7 kg
Shipping Box Width Shipping/Package Box Dimensions - 35 cm
Short description - TP-LINK WLAN AX1800 Access Point Dualband EAP610-Outdoor
ShortSummaryDescription - TP-Link Omada EAP610-Outdoor, 1800 Mbit/s, 574 Mbit/s, 1201 Mbit/s, 10,100,1000 Mbit/s, 2.4 - 5 GHz, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
sizeX - 320
sizeY - 250
sizeZ - 75
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 10
Stck_Pal - 10
Storno - Y
System Requirements - Microsoft Windows XP Vista Windows 7 Windows 8 Windows10 Windows11 Linux
Technical details > Gross weight - 1.471 kg
Technical details > Net weight - 1.371 kg
Technical details > Other features - Pole/Wall Mounting (Kits included)
Technical details > Producer - TP-LINK
Title - TP-Link Omada EAP610-Outdoor 1800 Mbit/s White Power over Ethernet (PoE)
Unit Box Height - 0.07
Unit Box Length - 0.32
Unit Box Width - 0.24
Unit Brutto Volume - 0.006605 cubm
Unit Gross Weight - 1.57 kg
Unit Net Weight - 1.2 kg
URL - https://www.tp-link.com/en/business-networking/omada-sdn-access-point/eap610-outdoor/#overview
Vendor Homepage - www.tp-link.com/us/business-networking/omada-sdn-access-point/eap610-outdoor/
vendpn - EAP610-Outdoor
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo - 2 year
warrantyLength - 24
warrantyType - G
Weight - 1,47
Weight - 1.48
weight - 1440
Weight & dimensions - Depth - 106.5 mm
Weight & dimensions - Height - 56.9 mm
Weight & dimensions - Width - 280.4 mm
Windows 7 OS compatibility - Yes
Windows 8 OS compatibility - Yes
Windows 10 OS compatibility - Yes
Windows Vista OS compatibility - Yes
Windows XP OS compatibility - Yes
Wireless Frequency Range - 2.4 GHz, 5 GHz
Wireless LAN features > Wi-Fi band - 802.11ax
