10/100/1000M LAN Ports - 1
64, 128, 152-bit WEP Security - Yes
Accessories included - EAP225 Adapter pasywnego PoE Kabel zasilający Zestaw montażowy Instrukcja instalacji
Antenna - Built-in
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 5
Antenna - Antenna type - Internal
Antenna > Antenna type - 5xInternal
Antenna gain - 5 dBi
Antenna Type - Built-in
ARTIKEL1 - AC1350 WLAN ACCESS POINT POE
ARTIKEL2 - DUAL BAND
Brand - TP-Link
BrandPartCode - EAP225
Category - Root/Electronics/Networks and communication/Access points
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Code - EAP225
Color - White
Data transmission speed - 1200 Mbps
Description - AC1200 Wireless Dual Band Gigabit Ceiling Mount Access Point Simultaneous 300Mbps on 2.4GHz and 867Mbps on 5GHz totals 1200Mbps Wi-Fi speeds Free EAP Controller Software lets administrators easily manage hundreds of EAPs Support Power over Ethernet(802.3af) for convenient and affordable installation Captive portal provides a convenient method for guest authentication Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections
Description - Gigabitowy, bezprzewodowy punkt dostępowy z możliwością montażu na suficie AC1350 Rozgłaszanie sieci w paśmie 2,4GHz o prędkości 450 Mb/s oraz w paśmie 5GHz o prędkości 867Mb/s, co daje 1317 Mb/s łącznie w dwóch pasmach Centralne zarządzanie siecią bezprzewodową z chmury i aplikacja Omada umożliwiają łatwe i wygodne użytkownie Zasilanie poprzez PoE (802.3af) oraz obsługa pasywanego PoE pozwalają na dowolne umiejscowienie urządzenia Wiele metod uwierzytelniania dostępu (SMS/Facebook Wi-Fi/Voucher itp.) Technologia MU-MIMO umożliwia zwielokrotnienie szybkości jednoczesnej wymiany danych pomiędzy punktami dostępowymi a wieloma urządzeniami końcowymi Technologia transmisji kierunkowej zapewnia optymalne działanie urządzenia i stabilne połączenia
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - LED indicators - Power, WLAN
Design - On/off switch - Yes
Design - Placement - Ceiling, Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 1086
dimension depth - 80 mm
dimension height - 240 mm
Dimensions - 205,5 × 181,5 × 37,1 mm
dimension weight - 1200 g
dimension width - 310 mm
EAN - 6935364096915
ean - 6935364096915
EANCode - 6935364096915
Eans - 6935364096915
EAN_code - 6935364096915
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Cabling technology - 10/100/1000Base-T(X)
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Maximum data transfer rate - 1350 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 450 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 867 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power (CE) - 23 dBm
Features - Transmitting power (FCC) - 24 dBm
Features - Virtual LAN features - VLAN mapping
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features > MU-MiMO - Yes
Full Description Line - Omada|EAP225|Type Wireless Access Point|Data transmission speed 1200 Mbps|IEEE 802.11a|IEEE 802.11g|IEEE 802.11n|IEEE 802.11ac|1x10/100/1000M|64, 128, 152-bit WEP|WPA - Wi-Fi Protected Access|WPA2 - Wi-Fi Protected Access|Antenna Type Built-in|Wireless Frequency Range 2.4GHz and 5GHz|Included Accessories Power Adapter,Mounting Kits,Installation Guide
Gross Weight Kg - 1,5
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 6935364096915
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
HSTNUMMER - EAP225
I/O ports - 1 x 10/100/1000 Mbit/s
IEEE 802.11ac Network standard - Yes
IEEE 802.11a Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Included Accessories - Power Adapter,
Mounting Kits,
Installation Guide
Link - https://www.tp-link.com/au/business-networking/ceiling-mount-ap/eap225/
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Superior Wi-Fi Speeds with MU-MIMO TechnologyOutfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP225 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.Cloud Centralized Management- Anytime, AnywhereOmada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.Facebook check-in and SMS authentication expands your social influence in secured waysCaptive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.Multiple PoE Options for Easy InstallationEAP225 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE injector, making deployment effortless and flexible.Easy Management with the Omada AppFollow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.Meet Our New Hero Product!The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.
LongProductName - 802.3af/at PoE, 12.6W, 2.4GHz: 4dBi x 3, 5GHz: 5dBi x 2, 2.4GHz and 5GHz, FCC, RoHS
LongSummaryDescription - TP-Link Omada EAP225. Maximum data transfer rate: 1350 Mbit/s, Maximum data transfer rate (2.4 GHz): 450 Mbit/s, Maximum data transfer rate (5 GHz): 867 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK, Service Set Identifier (SSID) features: Multiple SSIDs. Power over Ethernet (PoE) type supported: Passive PoE, Output voltage: 12 V, Output current: 1.5 A. Placement: Ceiling, Wall, Product colour: White, Cable lock slot type: Kensington. Antenna type: Internal, Antenna direction type: Omni-directional, Antenna features: Integrated antenna
Management, monitoring, configuration - Oprogramowanie EAP Controller Powiadomienia e-mail Wyłącznik diod Kontrola dostępu po adresach MAC SNMP v1,v2c Dziennik systemowy Lokalny/zdalny Telnet Zarządzanie przez przeglądarkę HTTP/HTTPS L3 Management Multi-site Management Management VLAN
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - EAP225
Manufacturer Name - TP-LINK
Manufacturer_code - EAP225
Mobile network - SIM card slot - No
Model name - EAP225
MPN - EAP225
name - Access Point EAP225 AP Gb PoE AC1350
Name - TP-Link Auranet EAP225, Access Point
Name - TP-Link EAP225
Name - TP-LINK EAP225 für Omada -2,4GHZ/450MBPS - 5GHZ/876MBPS
Name - TP-LINK | EAP225 | Access Point | 802.11ac | 2.4GHz/5GHz | 450+867 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO Yes | PoE in | Antenna type 5xInternal
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Number of antennas - 3
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 65 mm
Package features > Gross height (mm) - 228 mm
Package features > Gross weight - 0.785 kg
Package features > Gross width (mm) - 340 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 171 pc(s)
Package features > Paper/Pasteboard - 9 g
Package features > Plastic (No PET) - 259 g
Package features > Tare weight (kg) - 0.268 kg
Package features > Volume (m3) - 0.0050388 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - AC adapter included - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 1 pc(s)
Packaging content - PoE adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 340 mm
Packaging data - Package height - 65 mm
Packaging data - Package type - Box
Packaging data - Package weight - 910 g
Packaging data - Package width - 228 mm
Performance - Compatible operating systems - Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Frequency band - 2.4GHz/5GHz
Performance > Wi-Fi data rate (max) - 450+867 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - Output current - 1.5 A
Power - Output voltage - 12 V
Power - Power consumption (typical) - 10.15 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power supply - PoE 802.3af lub pasywne PoE
producer - TP-LINK
Producer - TP-Link
producerCode - EAP225
ProducerCode - EAP225
Producer product family - Access Point
Producer product name - EAP225
ProductName - EAP225
productName - TP-LINK | EAP225 | Access Point | 802.11ac | 2.4GHz/5GHz | 450+867 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO Yes | PoE in | Antenna type 5xInternal
productSize - Normal
Security - Uwierzytelnianie przy pomocy strony powitalnej Kontrola dostępu Filtrowanie adresów MAC Izolacja klientów sieci bezprzewodowej Mapowanie SSID do VLAN Wykrywanie nieautoryzowanych AP Obsługa 802.1X
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 152-bit WEP, SSID, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Service Set Identifier (SSID) features - Multiple SSIDs
Series - Omada
Shipping Box Depth Shipping/Package Box Dimensions - 34 cm
Shipping Box Height Shipping/Package Box Dimensions - 6.5 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.033 kg
Shipping Box Width Shipping/Package Box Dimensions - 23 cm
ShortDescription - Jednolite zarządzanie siecią WiFi - Centralne oprogramowanie zarządzające
Short description - TP-LINK WLAN AC1350 Access Point Dualband EAP225
ShortSummaryDescription - TP-Link Omada EAP225, 1350 Mbit/s, 450 Mbit/s, 867 Mbit/s, 10,100,1000 Mbit/s, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af, 10/100/1000Base-T(X)
sizeX - 230
sizeY - 315
sizeZ - 75
Software -
Special functions - Multi-SSID Do 16 SSID, 8 dla każdego pasma Wyłącznik sieci bezprzewodowej Automatyczny wybór kanału Kontrola mocy transmisji QoS(WMM) Sterowanie pasmem Równoważenie obciążenia pasma MU-MIMO Airtime Fairness Beamforming Kontrola przepustowości Harmonogram resetu Harmonogram sieci bezprzewodowej Statystyki sieci bezprzewodowej w oparciu o SSID/AP/klienta
Standards - 802.3af
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 10
Stck_Pal - 20
Storno - Y
Sustainability - Sustainability certificates - CE, Federal Communications Commission (FCC), RoHS
Sustainability - Sustainability compliance - Yes
System Requirements -
Technical details > Net weight - 0.517 kg
Technical details > Producer - TP-LINK
Technical_details - LAN: 1x 1000Base-T (PoE-PD) Wireless: WLAN 802.11a/b/g/n/ac, simultaneous Transfer rate: 300Mbps (2.4GHz), 867Mbps (5GHz) Security: 64/128/152bit WEP, WPA, WPA2 Antennas: internal Connectors: not available Power consumption: 10W (operation) Dimensions: 180x180x48mm Special features: VLAN
Title - TP-Link Omada EAP225 wireless access point 1350 Mbit/s White Power over Ethernet (PoE)
Unit Box Height - 0.065
Unit Box Length - 0.34
Unit Box Width - 0.23
Unit Brutto Volume - 0.005083 cubm
Unit Gross Weight - 1.03 kg
Unit Net Weight - 0.7 kg
URL - https://www.tp-link.com/us/business-networking/ceiling-mount-access-point/eap225/
Vendor Homepage - www.tp-link.com/baltic/products/details/cat-5692_EAP225.html
vendpn - EAP225
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 0,97
Weight - 1.004
weight - 1245
Weight & dimensions - Depth - 181.5 mm
Weight & dimensions - Height - 37.1 mm
Weight & dimensions - Width - 205.5 mm
Windows 7 OS compatibility - Yes
Windows 8 OS compatibility - Yes
Windows 10 OS compatibility - Yes
Windows Vista OS compatibility - Yes
Windows XP OS compatibility - Yes
Wireless Frequency Range - 2.4GHz and 5GHz
Wireless LAN features > Wi-Fi band - 802.11ac
WPA - Wi-Fi Protected Access Security - Yes
WPA2 - Wi-Fi Protected Access Security - Yes
