Antenna - Antenna gain level (max) - 6.5 dBi
ARTIKEL1 - UNIFIED AC1200 ACCESS POINT
ARTIKEL2 - 802.11A/B/G/N/AC DUALBAND
Brand - D-Link
BrandPartCode - DWL-6610AP
Category - Wireless Access Points
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Design - Certification - CE
EN 301 893 V1.7.1 (2012-06) (DFS/TPC)
EN 300 328 V1.8.1 (2012-06)
FCC
IC
cUL
LVD
UL2043
C-Tick
BSMI
NCC
Design - Housing material - Plastic
Design - On/off switch - Yes
Design - Reset button - Yes
EAN - 790069416835
EANCode - 0790069416835
EAN_code - 0790069416835
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Maximum data transfer rate - 1200 Mbit/s
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Features - Quality of Service (QoS) support - Yes
Features - VLAN support - Yes
Gewicht - 1.19
Gross Weight Kg - 1,22
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0790069416828
GTIN - 790069416828
GTIN - 0790069416835
GTIN - 790069416835
GTIN - 0790069416842
GTIN - 790069416842
HERSTELLER - D-LINK
HSTNUMMER - DWL-6610AP
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - Next Generation ConnectivityHarness the power of Wireless AC and take advantage of combined wireless speeds of up to 1200 Mbps,perfect for high demand business applicationsEnhanced Level of PerformanceExperience faster and stable performance as well greater coverage with beamforming, and bettermanaged traffic with band steeringUnparalleled Flexibility and ScalabilityUsed as a standalone wireless access point, self-configuring cluster or managed centrally via a D-LinkWireless Controller or Unified Switch
LongProductName - 802.11b/g/n/ac, 2.4 / 5 GHz, 1 x Gigabit Ethernet RJ-45, PoE+
LongSummaryDescription - D-Link DWL-6610AP. Maximum data transfer rate: 1200 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3,.... Security algorithms: AES, HTTPS, SSH, TKIP, WPA, WPA2. Management protocols: SNMP. Output voltage: 12 V, Output current: 2 A, Power consumption (max): 16.6 W. Housing material: Plastic, Certification: CE EN 301 893 V1.7.1 (2012-06) (DFS/TPC) EN 300 328 V1.8.1 (2012-06) FCC IC cUL LVD UL2043 C-Tick...
Management features - Web-based management - Yes
Manufacturer - D-Link
Manufacturer Code - DWL-6610AP
Manufacturer Name - D-Link
Manufacturer_code - DWL-6610AP
Name - D-Link DWL-6610AP PoE/AC1200/AP
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 65 °C
Packaging data - Package depth - 235 mm
Packaging data - Package height - 90 mm
Packaging data - Package weight - 1.06 kg
Packaging data - Package width - 243 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - Output current - 2 A
Power - Output voltage - 12 V
Power - Power consumption (max) - 16.6 W
Power - Power over Ethernet (PoE) - Yes
ProductName - DWL-6610AP
Protocols - Management protocols - SNMP
Security - MAC address filtering - Yes
Security - Security algorithms - AES, HTTPS, SSH, TKIP, WPA, WPA2
Short description - D-Link WLAN AC1200 Access-Point PoE+ DWL-6610AP
ShortSummaryDescription - D-Link DWL-6610AP, 1200 Mbit/s, 10,100,1000 Mbit/s, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3,..., AES, HTTPS, SSH, TKIP, WPA, WPA2, SNMP, 12 V
Stck_Kart - 6
Stck_Pal - 6
Storno - Y
Technical details - Master (outer) cases per pallet (air) - 24 pc(s)
Technical details - Master (outer) cases per pallet (sea) - 42 pc(s)
Technical details - Pallet gross length - 110 cm
Technical details - Pallet gross weight (air) - 200.6 kg
Technical details - Pallet gross weight (sea) - 332.5 kg
Technical details - Pallet gross width - 120 cm
Technical details - Pallet height (air) - 123.5 cm
Technical details - Pallet height (sea) - 2.06 m
Technical details - Products per pallet (air) - 144 pc(s)
Technical details - Products per pallet (sea) - 252 pc(s)
Technical details - Products per shipping (inner) case - 6 pc(s)
Technical details - Shipping (inner) case gross weight - 7.3 kg
Technical details - Shipping (inner) case height - 27.5 cm
Technical details - Shipping (inner) case length - 56.5 cm
Technical details - Shipping (inner) case net weight - 6.39 kg
Technical details - Shipping (inner) case width - 34.3 cm
Technical_details - LAN: 1x 1000Base-T (PoE PD) Wireless: WLAN 802.11a/b/g/n/ac, simultaneous Transfer rate: 300Mbps (2.4GHz), 867Mbps (5GHz) Security: 64/128/156bit WEP, WPA, WPA2 Antennas: internal Power consumption: not specified (operation) Dimensions: 159x159x69mm
Title - D-Link DWL-6610AP wireless access point 1200 Mbit/s Power over Ethernet (PoE)
URL - https://www.dlink.com/uk/en/support/product/dwl-6610ap-wireless-ac1200-dual-band-unified-access-point
WarrantyInfo -
Weight - 1,22
Weight & dimensions - Depth - 158.8 mm
Weight & dimensions - Height - 69.4 mm
Weight & dimensions - Weight - 500 g
Weight & dimensions - Width - 158.8 mm
