64, 128, 152-bit WEP Security - Yes
Accessories included - EAP115 Zasilacz Zestaw montażowy Instrukcja instalacji
Antenna - Built-in
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna features - Integrated antenna
Antenna - Antenna gain level (max) - 3 dBi
Antenna - Antenna gain level (max) - 4 dBi
Antenna - Antennas quantity - 2
Antenna - Antenna type - Internal
Antenna > Antenna type - 2xInternal
Antenna Gain - 3 dB
Antenna gain - 3 dBi
Antenna Type - Built-in
ARTIKEL1 - 300MBIT/S WLAN N ACCESS POINT
ARTIKEL2 - 300 MBIT/S 2.4GHZ 802.11B/G/N
Brand - TP-Link
BrandPartCode - EAP115 V4
Breite - 0.25
Category - Root/Smarthome/Networks and communication/Access points
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
CnCode CnCode - 85176200
Code - EAP115
Color - White
Data transmission speed - 300 Mbps
Description - 300Mbps Wireless N Ceiling Mount Access Point - Free cloud centralized management and Omada app for ultra convenience and easy management - Supports Power over Ethernet (802.3af) for convenient and affordable installation - Simple mounting design for easy attachment to a wall or ceiling - Secure guest network along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies - Enterprise class Wi-Fi security help to decrease network security threats - Multi-SSID divides multiple wireless networks for different user types - Supports management vlan for an enhanced network management
Description - Bezprzewodowy punkt dostępowy z możliwością montażu na suficie, standard N 300Mb/s Oprogramowanie zarządzające pozwala na centralne zarządzenie siecią bezprzewodową Obsługa zasilania PoE Łatwość montażu na ścianie lub na suficie Uwierzytelnianie przy pomocy strony powitalnej Multi-SSID pozwala na stworzenie podsieci dla różnych użytkowników Biznesowej klasy zabezpieczenia chronią sieć WiFi przed atakami Skalowalne rozwiązanie dla klasy biznesowej
Bezprzewodowy punkt dostępowy z możliwością montażu na suficie, standard N 300Mb/s Proste centralne zarządzanie.Bez specjalistów.
Monitoruj i zarządzaj setkami urządzeń EAP w jednej lokalizacji jednocześnie. W odróżnieniu od większości sterowników sprzętowych, oprogramowanie TP-LINK EAP Controller Software nie wymaga specjalnych umiejętności ani dodatkowych opłat. Wygodna identyfikacja gości z wykorzystaniem SMS lub facebooka
Uwierzytelnianie klientów sieci bezprzewodowej poprzez stronę powitalną jest niezwykle wygodne. Metoda ta wymaga od użytkownika wykonania odpowiednich działań (takich jak np. zatwierdzenie warunków użytkowania, podania kodu SMS lub zalogowanie się do systemu) w celu uzyskania dostępu do sieci. Działania te są następnie weryfikowane przez odpowieni serwer lub bazę danych przygotowaną przez administratora sieci. Oszczędność czasu i miejsca
Omada EAP115 został zaprojektowany tak, aby instalacja na ścianie lub suficie była jak najłatwiejsza. Zasilanie PoE umożliwia szybki i wygodny montaż urządzenia bez wykorzystywania dodatkowych kabli. To dodatkowy problem którym nie musisz się martwić korzystając ze swojego scentralizowanego systemu. Jedna sieć dla dużej ilości użytkowników
Urządzenia biznesowe Omada zostały zaprojektowane tak, aby sprostać dużej ilości użytkowników na dużych obszarach bez problemów które napotykają domowe routery, takich jak np. niestabilność. Punkty dostępowe EAP są idealne dla hoteli, sklepów, szkół i restauracji.
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Certification - CE, FCC, RoHS
Design - LED indicators - Yes
Design - On/off switch - Yes
Design - Placement - Ceiling, Wall
Design - Product colour - White
Design - Reset button - Yes
dimensionalWeight - 1075
dimension depth - 235 mm
dimension height - 300 mm
Dimensions - 180*180*47.5mm
Dimensions - 189.4 × 172.3 × 29.5 mm
dimension weight - 900 g
dimension width - 75 mm
EAN - 6935364096939
ean - 6935364096939
EANCode - 6935364096939
Eans - 6935364096939
EAN_code - 6935364096939
Features - 2.4 GHz - Yes
Features - 5 GHz - No
Features - 6 GHz - No
Features - Automatic channel selection - Yes
Features - Cabling technology - 10/100Base-T(X)
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Ethernet LAN data rates - 100
Features - Frequency band - 2.4 - 2.4835 GHz
Features - Maximum data transfer rate - 300 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 300 Mbit/s
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11n
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Receiver sensitivity - 300M: -71dBm@10% PER
150M: -75dBm@10% PER
54M: -78dBm@10% PER
11M: -93dBm@8% PER
6M: -92dBm@10% PER
1M: -96dBm@8% PER
Features - Receiver sensitivity - 300M: -71dBm@10% PER150M: -75dBm@10% PER54M: -78dBm@10% PER11M: -93dBm@8% PER6M: -92dBm@10% PER1M: -96dBm@8% PER
Features - Transmitting power (CE) - 19 dBm
Features - Transmitting power (FCC) - 21 dBm
Features - Virtual LAN features - VLAN mapping
Features - VLAN support - Yes
Features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Features - Wireless isolation - Yes
Features > MU-MiMO - No
Full Description Line - Omada|EAP115|Type Wireless Access Point|Data transmission speed 300 Mbps|IEEE 802.3af|IEEE 802.11b|IEEE 802.11g|IEEE 802.11n|64, 128, 152-bit WEP|WPA - Wi-Fi Protected Access|WPA2 - Wi-Fi Protected Access|Antenna Type Built-in|Antenna Gain 3 dB|Number of antennas 2|Wireless Frequency Range 2.4-2.4835GHz|Power supply requirements PoE or external 12VDC/1.0A|Dimensions 180*180*47.5mm
Gewicht - 0.66
Gross Weight Kg - 1,14
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0845973092863
GTIN - 845973092863
GTIN - 0845973096939
GTIN - 845973096939
GTIN - 6935364096939
GTIN - 6935364096946
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0.07
HSTNUMMER - EAP115
I/O ports - 1 x 10/100 Mbit/s PoE
IEEE 802.3af Network standard - Yes
IEEE 802.11b Network standard - Yes
IEEE 802.11g Network standard - Yes
IEEE 802.11n Network standard - Yes
Laenge - 0.27
Link - https://www.tp-link.com/au/business-networking/ceiling-mount-ap/eap115/
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - An Affordable, Scalable Business Wi-Fi Solution300Mbps Wireless N Ceiling Mount Access PointCloud Centralized Management- Anytime, AnywhereOmada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.Captive PortalGuest Network with Facebook and SMS SupportCaptive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.Easy Mount Design and PoETimesaving and Flexible DeploymentThe Omada EAP115 is designed for easy installation on any wall or ceiling. The Power over Ethernet (PoE) function allows your network cables to carry electrical power so you minimize on cable clutter. It’s one more hardwiring hassle you don’t have to worry about when operating your centralized management system.Easy Management with the Omada AppFollow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
LongProductName - 300Mbps Wireless N Ceiling Mount Access Point, 2.4 - 2.4835 GHz, 9VDC/0.6A, 2.8W
LongSummaryDescription - TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point. Maximum data transfer rate: 300 Mbit/s, Maximum data transfer rate (2.4 GHz): 300 Mbit/s, Ethernet LAN data rates: 10,100,1000 Mbit/s. Security algorithms: 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK, Service Set Identifier (SSID) features: Multiple SSIDs. WAN connection: Ethernet (RJ-45), Wi-Fi. Power over Ethernet (PoE) type supported: Passive PoE, Output voltage: 12 V, Output current: 1 A. Placement: Ceiling, Wall, Product colour: White, Cable lock slot type: Kensington
Management, monitoring, configuration - Dostęp do Omada Cloud Aplikacja Omada Kontroler Omada Cloud Zarządzanie centralne: Omada Cloud-Based Controller, Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller Oprogramowanie Omada Controller Dostęp do chmury: Tak (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) Powiadomienia e-mail Wyłącznik diod Kontrola dostępu po adresach MAC SNMP: v1,v2c Dziennik systemowy: Lokalne i zdalne Telnet SSH Zarządzanie przez przeglądarkę: HTTP/HTTPS Zarządzanie VLAN
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - EAP115
Manufacturer Name - TP-LINK
Manufacturer_code - EAP115
Model name - EAP115
MPN - EAP115
name - Access Point N300 PoE EAP115
Name - TP-LINK Access Point EAP115 802.11n 2.4GHz 300 Mbit/s 10/100 Mbit/s Ethernet LAN (RJ-45) ports 1 MU-MiMO No PoE in Antenna type 2xInternal No
Name - TP-Link Auranet EAP115, Access Point
Name - TP-Link EAP115
Name - TP-LINK EAP115 für Omada -2,4GHZ/300MBPS
Network architecture - FastEthernet
Network Device Type - Wireless Access Point
Number of antennas - 2
Operating frequency - 2,4 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other features > USB ports quantity - No
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 267 mm
Package features > Gross height (mm) - 240 mm
Package features > Gross weight - 0.68 kg
Package features > Gross width (mm) - 68 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 198 pc(s)
Package features > Paper/Pasteboard - 8 g
Package features > Plastic (No PET) - 245 g
Package features > Tare weight (kg) - 0.253 kg
Package features > Volume (m3) - 0.00435744 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - AC adapter included - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of products included - 1 pc(s)
Packaging content - PoE adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 246 mm
Packaging data - Package depth - 268 mm
Packaging data - Package height - 69 mm
Packaging data - Package weight - 600 g
Packaging data - Package width - 246 mm
Packaging data - Package width - 268 mm
Performance - Minimum system requirements - Microsoft Windows 10/8/7/Vista/XP
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Frequency band - 2.4GHz
Performance > Wi-Fi data rate (max) - 300 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - WAN connection - Ethernet (RJ-45)
Ports & interfaces - WAN connection - Ethernet (RJ-45), Wi-Fi
Ports & interfaces - WAN connection - Wi-Fi
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - Output current - 0.6 A
Power - Output current - 1 A
Power - Output voltage - 9 V
Power - Output voltage - 12 V
Power - Power consumption (typical) - 2.8 W
Power - Power consumption (typical) - 5 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power supply - PoE lub zewnętrzny zasilacz 9VDC/0.6A
Power supply requirements - PoE or external 12VDC/1.0A
producer - TP-LINK
Producer - TP-Link
producerCode - EAP115
ProducerCode - EAP115
Producer product family - Access Point
Producer product name - EAP115
ProductName - 300Mbps Wireless N Ceiling Mount Access Point
productName - TP-Link 300Mbps Wireless N Ceiling Mount Access Point
productSize - Normal
RJ45 Ports - 1
Security - Uwierzytelnianie przy pomocy strony powitalnej Kontrola dostępu Filtrowanie adresów MAC Izolacja klientów sieci bezprzewodowej Mapowanie SSID do VLAN Wykrywanie nieautoryzowanych AP Obsługa 802.1X Szyfrowanie 64/128/152-bit WEP / WPA / WPA2-Enterprise,WPA-PSK / WPA2-PSK
Security - Access Control List (ACL) - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 8
Security - Security algorithms - 64-bit WEP
Security - Security algorithms - 64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Security - Security algorithms - 128-bit WEP
Security - Security algorithms - 152-bit WEP
Security - Security algorithms - HTTPS
Security - Security algorithms - SNMP
Security - Security algorithms - SSH
Security - Security algorithms - WPA
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-PSK
Security - Service Set Identifier (SSID) features - Multiple SSIDs
Security - System status alarm - Y
Security - System status alarm - Yes
Series - Omada
Shipping Box Depth Shipping/Package Box Dimensions - 27 cm
Shipping Box Height Shipping/Package Box Dimensions - 7 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 0.696 kg
Shipping Box Width Shipping/Package Box Dimensions - 25 cm
ShortDescription - Jednolite zarządzanie siecią WiFi - Centralne oprogramowanie zarządzające
Short description - TP-LINK WLAN 300MBit Access Point 2.4GHz EAP115
ShortSummaryDescription - TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point, 300 Mbit/s, 300 Mbit/s, 10,100,1000 Mbit/s, 2.4 - 2.4835 GHz, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 10/100Base-T(X)
sizeX - 235
sizeY - 305
sizeZ - 75
Software -
Special functions - Multi-SSID Do 8 SSID Wyłącznik sieci bezprzewodowej Automatyczny wybór kanału Kontrola mocy transmisji QoS(WMM) Równoważenie pasma Harmonogram restartowania Harmonogram sieci bezprzewodowej Statystyki sieci bezprzewodowej w oparciu o SSID/AP/klienta
Standards - 802.3af
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 16
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability certificates - Federal Communications Commission (FCC), CE, RoHS
Sustainability - Sustainability compliance - Yes
System Requirements - Microsoft Windows 10/8/7/Vista/XP
Technical details > Net weight - 0.427 kg
Technical_details - LAN: 1x 100Base-TX (PoE-PD) Wireless: WLAN 802.11b/g/n Transfer rate: 300Mbps (2.4GHz) Security: 64/128/152bit WEP, WPA, WPA2 Antennas: internal Connectors: not available Power consumption: 5W (operation) Dimensions: 180x180x47.50mm Special features: VLAN Warranty: three years
Title - TP-Link Omada 300Mbps Wireless N Ceiling Mount Access Point
Unit Box Height - 0.07
Unit Box Length - 0.27
Unit Box Width - 0.25
Unit Brutto Volume - 0.004725 cubm
Unit Gross Weight - 0.696 kg
Unit Net Weight - 0.4 kg
URL - https://www.tp-link.com/uk/business-networking/omada-wifi-ceiling-mount/eap115/#specifications
Vendor Homepage - www.tp-link.com/baltic/products/details/cat-5692_EAP115.html
vendpn - EAP115
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
Weight - 0,66
Weight - 0.92
weight - 910
Weight & dimensions - Depth - 172.3 mm
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Height - 29.5 mm
Weight & dimensions - Height - 47.5 mm
Weight & dimensions - Width - 180 mm
Weight & dimensions - Width - 189.4 mm
Windows 7 OS compatibility - Yes
Windows 8 OS compatibility - Yes
Windows 10 OS compatibility - Yes
Windows Vista OS compatibility - Yes
Windows XP OS compatibility - Yes
Wireless Frequency Range - 2.4-2.4835GHz
Wireless LAN features > Wi-Fi band - 802.11n
WPA - Wi-Fi Protected Access Security - Yes
WPA2 - Wi-Fi Protected Access Security - Yes
