Accessories included - WiFi EBR63 RJ45 Ethernet cable Charger Quick start guide Warranty Card
Antenna - Built-in
Antenna - Antenna design - External
Antenna - Antennas quantity - 4
Antenna > Antennas quantity - 4
Antenna > Antenna type - External
Brand - ASUS
BrandPartCode - 90IG0870-MO3C00
Category - Root/Electronics/Networks and communication/Routers
Category - Wireless Routers
Category_1 - Network and Servers
Category_2 - Network - Routers
Certificates -
Code - 90IG0870-MO3C00
Color - White
Description - AX3000 dual-band Wi-Fi 6 (802.11ax) all-in-one router, switch and security gateway, supports up to 5 SSIDs, VLAN, SDN, customized guest portal, site-to-sit VPN, class network security commercial and easy application to manage Secure and segmented network Easily configure your corporate Wi-Fi network via self-defined networks, and enhance business security with VLAN support, offering up to five SSIDs for device segregation and prioritization in different business scenarios. Customizable Guest Portal Guest portals can be tailored to your business needs with custom portal types, branding, and visual templates to suit specific business styles Backup WAN for Stable Connectivity The USB port can be used as a backup WAN by connecting it to your hotspot mobile phone to maintain a reliable internet connection Commercial-grade network security and VPN secure browsing, VPN features to connect to public Wi-Fi easily and securely, and a free ASUS AiProtection Pro subscription Adapt to any space EBR63 comes with a built-in bracket and wall mounting hole that can be adjusted to fit almost any space for space savings and greater flexibility
Design - Indication light - Yes
Design - LED indicators - Activity, LAN, Power, WAN
Design - On/off switch - Yes
Design - Product colour - White
Design - Product type - Tabletop router
Design - Wall mountable - Yes
Design > Colour of product - White
dimensionalWeight - 684
dimension depth - 75 mm
dimension height - 190 mm
Dimensions -
dimension weight - 801 g
dimension width - 245 mm
EAN - 4711387004555
ean - 4711387004555
Eans - 4711387004555
EAN_code - 4711387004555
Environment requirements -
Features - Built-in processor - Yes
Features - Flash memory - 256 MB
Features - Internal memory - 512 MB
Features - Processor cores - 4
Features - Processor frequency - 1.7 MHz
Features > Mesh Support - Yes
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
GTIN - 4711387004555
guarantee - 36
guarantee_type - normal
I/O ports - 1 x 10/100/1000Base-T RJ-45 port (WAN)
I/O ports - 1 x USB 2.0
I/O ports - 1 x USB 3.0
I/O ports - 4 x 10/100/1000 Mbit/s LAN / DMZ
LongDesc - ASUS ExpertWiFi EBR63All in One Access Point with Router, Switch and Security GatewayYour Business WiFi Expert Within ReachThe ASUS ExpertWiFi EBR63 is an all in one access point with router, switch and security gateway functionalities. It offers a fast, secure, and scalable network with rich features tailored for small-to-midsized businesses. Whether used independently or integrated with other ASUS ExpertWiFi solutions, the EBR63 can easily adapt to your business network needs.For remote employees or those running small businesses, ExpertWiFi provides stable and reliable internet connections. And with comprehensive VPN protocols, users can access their networks with site-to-site VPNs for encrypted office or home network connections, easily and securely.ExpertWiFi provides an all-new platform for innovative business services. Brand information and advertising can be promoted via a Guest Portal, to engage with your customers in different ways.ExpertWiFi networking products are prepared to scale to the customers’ needs. The ExpertWiFi series can support up to 12 node connections, so a businesses can greatly expand the size of its network when using ExpertWiFi devices.To make sure all data and information is secured, the ExpertWiFi series offers commercial-grade network security through a free subscription to ASUS AiProtection Pro and Safe Browsing features.Speed up your businessA superfast business all in one access point for stable downloading and smooth video calls.Connect your business to the max4X greater dual-band network capacity with support for WiFi 6, which can lower latency when demand is high.Start your business network with one deviceSetting up a commercial network typically requires a significant investment in a complicated set of networking products and management fees. However, the ExpertWiFi EBR63 can empower you to easily build a cost-effective commercial network, making it an ideal choice for small businesses on a limited budget. Essential networking features are combined into one device, and we offer comprehensive software features without any subscription fees, so your business can get an edge on the competition. And as your business grows, you can easily extend your network with other ASUS ExpertWiFi products.Stable business operationExpertWiFi supports virtual local area network (VLAN) management. VLAN management enables an easy, fast and flexible way to segment the network wired and wirelessly. You can dedicate an Ethernet port that provides additional security for your business.The EBR63 provides reliable and stable internet access for business owners. With dual WAN support, you can set the USB port as a backup WAN by connecting it to your mobile phone with a hotspot. No complicated setup is needed — just plug it in and use it.Easy settings for your businessSeparate profiles and usageA Self-Defined Network (SDN) provides up to five SSIDs to separate and prioritize devices for various business usages and network alternatives. Network segments can be made for employees, guest portals, guest networks, scheduled networks, IoT networks and VPN networks.Scenario explorerThe scenario explorer can guide network novices through the network setup process. Just click on a scenario that suits your business the most, and it will customize your router’s settings to complete the process in just a few steps.Create your styleGuest portals can be tailored to meet your business needs, with custom portal types, branding and visual templates to fit particular business styles and to engage with customers in different ways.Manage all devices at onceExpertWiFi series lets business owners with multiple offices or workplaces connect all network devices under one administrator account. In addition, they can easily manage various network devices in the ASUS ExpertWiFi mobile app anywhere, anytime.Extendable and scalableExpertWiFi networking products are prepared to scale to the customer’s needs, whether it’s a small business or a medium-sized office. With support for up to 12 node connections, companies can significantly expand their network size by adding more ExpertWiFi devices. Additionally, the EBR63 can support up to 100 active devices.*The ASUS ExpertWiFi series is compatible with all ASUS AiMesh products, but supported features may vary based on model.Control your business network all in one appWith the ASUS ExpertWiFi app, you can set up and manage your business network easily and conveniently.Commercial-grade network securitySite-to-site VPNSite-to-site VPNs are useful for companies that prioritize private, protected traffic. They are particularly helpful for organizations that have multiple locations spread out over great distances, such as chain stores and overseas branch offices. Using a site-to-site VPN can quickly help you build up your private network to connect all these places and to share information or resources between intranets from different locations.Protect your businessesASUS AiProtection Pro leverages powerful cybersecurity solutions and cloud data centers from Trend Micro ™ to shield your business and all connected devices from cyber threats — with no subscription fee!One-tap security scanCheck your security level with one tap, instead of fiddling with complicated settings.Multi-functional hardwareAdaptable to any spaceThe ExpertWiFi EBR63 comes with a built-in bracket and wall mount holes that can be adjusted to fit into almost any location for space-saving and more flexibility. The bracket also doubles as a cable organizer, making it easy to keep your workspace clean and organized.Versatile connectivityASUS ExpertWiFi EBR63 features two USB ports, enabling easy connection of business devices like printers and POS machines for seamless resource sharing. Additionally, the USB ports can serve as a backup internet provider with your mobile hotspot, by just plugging it into your smartphone, ensuring an always-on business network.Sustaining an Incredible FutureEnvironmental Certification*ASUS ExpertWiFi is stringently tested to meet the requirements of world-leading sustainability certifications. These tests include a comprehensive database of up-to date criteria, independent verification and a structured system for continuous improvement.Eco-friendly PackagingAll ExpertWiFi products come with environmentally friendly packaging sourced from FSC-certified responsible forestry, and they benefit from more active management of the use of chemicals in the production process, to improve the recycling of packaging and substances, and to reduce environmental impact.
LongProductName - AX3000 Dual-Band WiFi 6 (802.11ax) All in One Access Point with Router, Switch and Security Gateway, supports up to 5 SSIDs, VLAN, SDN, customized guest portal, site-to-sit VPN, commercial-grade network security and easy management app
LongSummaryDescription - ASUS EBR63 – Expert WiFi. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 2402 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Cabling technology: 10/100/1000Base-T(X). Security algorithms: SSH, WPS. Product type: Tabletop router, Product colour: White, LED indicators: Activity, LAN, Power, WAN
Management, monitoring, configuration -
Management features - Bandwidth control - Yes
Management features - Intelligent Mesh technology - Yes
Management features - MU-MIMO technology - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - WPS push button - Yes
Manufacturer - Asus
Manufacturer_code - 90IG0870-MO3C00
Model - EBR63
Name - ASUS EBR63
name - ASUS EBR63 Router WiFi AX3000 ExpertWiFi
Name - ASUS ExpertWIFI Mesh EBR63, Mesh Router (white)
Name - Asus | Dual Band WiFi 6 AX3000 Router (PROMO) | EBR63 | 802.11ax | 2402 Mbit/s | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 4 | Mesh Support Yes | MU-MiMO Yes | No mobile broadband | Antenna type External | 2
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Media server - Yes
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11ax
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Port forwarding - Yes
Network - Port triggering - Yes
Network - Support Samba (storage) - Yes
Network - VPN support - VPN Client L2PT
VPN Client Open VPN
VPN Client PPTP
VPN Client WireGuard
VPN Server IPSec
VPN Server Open VPN
VPN Server PPTP
VPN Server WireGuard
VPN Fusion
Support Surfshark
Network architecture - GigabitEthernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Other features - Port 4 x RJ45 for Gigabits BaseT for LAN
Other features > Ethernet LAN (RJ-45) ports - 4
Other features > USB ports quantity - 2
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 385.00 mm
Package features > Gross depth master carton - 276.50 mm
Package features > Gross height (mm) - 250.00 mm
Package features > Gross width (mm) - 123.00 mm
Package features > Gross width master carton - 168.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 73 pc(s)
Package features > Paper/Pasteboard - 50.00 g
Package features > PET - 1 g
Package features > Plastic (No PET) - 11.00 g
Package features > Tare other - 2 g
Package features > Tare weight (kg) - 0.06 kg
Package features > TI weight (kg) - 0 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick start guide - Yes
Packaging content - Warranty card - Yes
Packaging data - Number of products included - 1 pc(s)
Packaging data - Package depth - 188 mm
Packaging data - Package height - 73 mm
Packaging data - Package type - Box
Packaging data - Package weight - 740 g
Packaging data - Package width - 241 mm
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Performance > Wi-Fi data rate (max) - 2402 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB port - Yes
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 110 - 240 V
Power - External power adapter - Yes
Power - Output current - 2 A
Power - Output voltage - 12 V
Power - Power source type - DC
Power supply - AC input: 110V ~ 240V (50 ~ 60Hz) DC output: 12V with max. current 2A
producer - Asus
Producer - Asus
producerCode - EBR63
ProducerCode - EBR63
Producer product family - Dual Band WiFi 6 AX3000 Router (PROMO)
Producer product name - EBR63
productName - ASUS EBR63 – Expert WiFi wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
ProductName - EBR63 – Expert WiFi
productSize - Normal
Protocols - DHCP server - Yes
Security - AiProtection VPN WiFi Encryption WPS Let's Encrypt DNS-over-TLS SSH Firewall Maximum firewall keyword filter: 64 Maximum firewall network services filter: 32 Maximum firewall URL filter: 64
Security - DMZ support - Yes
Security - Filtering - Yes
Security - Firewall - Yes
Security - Guest access - Yes
Security - MAC address filtering - Yes
Security - Network address translation (NAT) - Yes
Security - Schedule access - Yes
Security - Security algorithms - SSH
Security - Security algorithms - SSH, WPS
Security - Security algorithms - WPS
Security - URL filtering - Yes
ShortDescription -
ShortSummaryDescription - ASUS EBR63 – Expert WiFi, Wi-Fi 6 (802.11ax), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, White, Tabletop router
sizeX - 240
sizeY - 75
sizeZ - 190
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
System Requirements -
Technical details > Gross weight - 2.53 kg
Technical details > Net weight - 2.47 kg
Technical details > Producer - Asus
Title - ASUS EBR63 – Expert WiFi wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
Type - xDSL
URL - https://www.asus.com/networking-iot-servers/business-network-solutions/asus-expertwifi/asus-expertwifi-ebr63/
vendpn - EBR63
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
Warranty - 36
Warranty - 36 month(s)
WarrantyInfo -
warrantyLength - 36
warrantyType - G
Weight - 0,80
Weight - 436 g
weight - 810
Weight & dimensions - Depth - 127 mm
Weight & dimensions - Height - 146 mm
Weight & dimensions - Weight - 436 g
Weight & dimensions - Width - 225 mm
Wireless LAN features - Modulation - 1024-QAM
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Wireless LAN features - WLAN data transfer rate (first band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 2402 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 2402 Mbit/s
Wireless LAN features > Wi-Fi band - 802.11ax
Wireless LAN features > Wi-Fi standards - 802.11a/b/g/n/ac/ax
