Antenna - Antenna design - External
Antenna - Antennas quantity - 2
Antenna > Antennas quantity - 2
Antenna > Antenna type - 2xExternal 5dBi
Brand - ASUS
BrandPartCode - 90-IG29002M01-3PA0
Category - Wireless Routers
Code - 90-IG29002M03-3PA0-
Design - LED indicators - LAN, Power, WAN
Design - Product colour - Black, Metallic
Design > Illumination - PWR x 1LAN x 4WAN x 1
dimensionalWeight - 570
EAN - 4719543397275
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - No
Features > Product type - Router
Gross weight - 0.462 kg
GTIN - 610839397273
GTIN - 0610839397273
GTIN - 4719543397275
GTIN - 8594157007187
GTIN - 8595149005808
Link - http://www.asus.com/Networks/Wireless_Routers/RTN12E/#specifications
Link - https://www.asus.com/Networking/RTN12E/specifications/
LongDesc - ASUS RT-N12E supports 802.11 b/g/n and has 300 Mbps high speed. With CD free easy installation and stable data transmission, RT-N12E is the basic solution for wireless internet setup. It also contents Green WLAN technology so it consumes less power during stand by mode.Plug-n-Surf Installation3-steps is all you need to set up the router. You don't need a CD for installation.Save the planet and your pocketCompared with generic Wireless-N routers, ASUS ECO-WiFi CPU reduces 72%* of energy consumption and utility cost.Extended Network CoverageThe RT-N12E features a 5dBi high-gain antenna that boosts the wireless signal, thereby extending coverage range.Network Map-Manual Free ManagementStraight-forward design to help users to:- Display the whole network status and clearly provide WAN/LAN status- Securely connect to your wireless network and prevent intruders from using it- Manage your network in minutes- Try our EZ UI softwareWPS Function& WPA/WPA2 EncryptionWEP encryption is not enough for Wi-Fi connection nowadays, and intruders may access your Internet flagrantly. Using WPS function and WPA/WPA2 encryption can firmly secure your home networks and protect the private resources.
LongProductName - RT-N12E - QoS, 5 x RJ45, WAN, LAN, 2.4, DHCP server, WAN DHCP client
LongSummaryDescription - ASUS RT-N12E. Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s, Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n). Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: 128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS. Product colour: Black, Metallic, LED indicators: LAN, Power, WAN. Antenna design: External
Management features - Web-based management - Yes
Mobile network - 3G - No
Mobile network - 4G - No
Name - Router | RT-N12E | 802.11n | 300 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 4 | Mesh Support No | MU-MiMO No | No mobile broadband | Antenna type 2xExternal 5dBi | No USB | 36 month(s)
Network - Cabling technology - 10/100Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Ethernet LAN interface type - Fast Ethernet
Network - Networking standards - IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 45 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Filtering description - Port, IP, URL, MAC adress
Other features - Input current - 0.5 A
Other features - Mobile network connection - No
Other features - WLAN data transfer rates supported - 1,2,5.5,6,9,11,12,18,24,36,48,54,300 Mbit/s
Other features > Ethernet LAN (RJ-45) ports - 4
Other features > USB ports quantity - No USB
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 255 mm
Package features > Gross depth master carton - 520 mm
Package features > Gross height (mm) - 187 mm
Package features > Gross height master carton - 225 mm
Package features > Gross width (mm) - 60 mm
Package features > Gross width master carton - 315 mm
Package features > Net weight master carton - 4.62 kg
Package features > Packing quantity - 10.00 pc(s)
Package features > Palette Qty - 460 pc(s)
Package features > Paper/Pasteboard - 18 g
Package features > Plastic (No PET) - 2.00 g
Package features > Tare weight (kg) - 0.02 kg
Package features > Tare weight master carton - 0.627 kg
Package features > Volume (m3) - 0.0028611 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Networking standards - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IPv4
Performance > Wi-Fi data rate (max) - 300 Mbit/s
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces > Interface type - Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 110 - 240 V
Power - Power over Ethernet (PoE) - Yes
Power > Power - AC Input : 110V~240V(50~60Hz)DC Output : 12 V with max. 0.5 A current W
producerCode - RT-N12E
Producer product family - Router
Producer product name - RT-N12E
productName - Router | RT-N12E | 802.11n | 300 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 4 | Mesh Support No | MU-MiMO No | No mobile broadband | Antenna type 2xExternal 5dBi | No USB | 36 month(s)
ProductName - RT-N12E
productSize - Normal
Protocols - DHCP client - Yes
Security - Filtering - Yes
Security - MAC address filtering - Yes
Security - Network address translation (NAT) - Yes
Security - Security algorithms - 128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Security - Stateful Packet Inspection (SPI) - Yes
ShortSummaryDescription - ASUS RT-N12E, Wi-Fi 4 (802.11n), Ethernet LAN, Black, Metallic
sizeX - 200
sizeY - 285
sizeZ - 50
Technical details > Net weight - 0.442 kg
Technical details > Other features - Repeater/AP, IPTV support, Plug-n-Play, ASUSWRT graphic interface, EZ QoS, IPv6, DDWRT open source support
Technical details > Producer - Asus
Technical details > Warranty - 36 month(s)
Title - ASUS RT-N12E wireless router Fast Ethernet Black, Metallic
URL - https://www.asus.com/Networks/Wireless_Routers/RTN12E/#overview
WAN connection - Ethernet WAN - Yes
Warranty - 36
WarrantyInfo -
warrantyLength - 24
warrantyType - G
weight - 610
Weight & dimensions - Depth - 168 mm
Weight & dimensions - Height - 30 mm
Weight & dimensions - Weight - 210 g
Weight & dimensions - Width - 124 mm
Weight & dimensions > Weight - 210 g
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wireless LAN features - WLAN data transfer rate (max) - 300 Mbit/s
Wireless LAN features > Wi-Fi band - 802.11n
Wireless LAN features > Wi-Fi standards - 802.11n
